Model No. WLTL29010
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guaran-
tee complete satisfaction through
direct assistance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manu-
al for future reference.
®
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo WLTL29010
Summary of Contents for Weslo WLTL29010
- Page 1 ® Model No. WLTL29010 USER'S MANUAL Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, we will guaran- tee complete satisfaction through direct assistance from our factory.
-
Page 2: Table Of Contents
120 volts AC and 15 amps. To purchase a surge suppressor, 7. The treadmill should not be used by persons see your local WESLO dealer or call 1-800- weighing more than 250 pounds. 999-3756 and order part number 146148. - Page 3 13. Never move the walking belt while the power must be able to safely lift 45 pounds (20 kg) in is turned off. Do not operate the treadmill if order to raise, lower, or move the treadmill. the power cord or plug is damaged, or if the treadmill is not working properly.
-
Page 4: Before You Begin
The model you’re not exercising, the CADENCE 340 CS can be number of the treadmill is WLTL29010. The serial folded up, re-quiring less than half the floor space of number can be found on a decal attached to the tread- other treadmills. -
Page 5: Assembly
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dis- pose of the packing materials until assembly is completed. In addition to the included allen wrench, assembly requires a phillips screwdriver, an adjustable wrench and scissors Note: The underside of the treadmill walking belt is coated with high-performance lubricant. - Page 6 3. Hold the Console Base (87) near the right Handrail (4). Make a loop with the indicated plastic tie and insert the two Wires (53) through the loop. Pull only enough Wire to connect the Wires to the two connectors in the Plastic Console Base (87).
-
Page 7: Operation And Adjustment
To purchase a surge suppressor, see your local Metal Screw WESLO dealer or call toll-free 1-800-999-3756 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge suppressor (TVSS). The surge suppres-... - Page 8 DIAGRAM OF THE CONSOLE Monitor Displays Speed Control If there is a thin sheet of clear Clip plastic on the console, remove it. the negative (–) ends of the batteries touching the CAUTION: springs. Close the battery cover, push up on the tab, Before operating the and then push the tab forward as shown.
- Page 9 • Distance—This mode shows the total number of Insert the key fully into the power switch. miles you have walked or run. Inserting the key will If desired, the displays can be reset by pressing not turn on the dis- the ON/RESET button.
-
Page 10: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower or move the treadmill. 1. - Page 11 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left thumb, press the storage latch and hold it. Pivot the treadmill until the frame and foot rail are past the storage latch.
-
Page 12: Maintenance And Trouble-Shooting
MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge suppressor (TVSS). The surge suppressor must have a UL suppressed voltage rating of 400 volts or less and a minimum surge dissipation of 450 joules.
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES speed control on the console to FAT BURN to help you maintain the proper intensity level. (See page 9.) WARNING: Before beginning this or any exercise program, consult your Aerobic Exercise physician. This is especially important for individuals over the age of 35 or individuals If your goal is to strengthen your cardiovascular sys- with pre-existing health problems. - Page 15 WORKOUT GUIDELINES zone for longer than 20 minutes.) Breathe regularly and deeply as you exercise—never hold your breath. Each workout should include the following three parts: A Cool-down A Warm-up Finish each workout with 5 to 10 minutes of stretching Start each workout with 5 to 10 minutes of stretching to cool down.
- Page 16 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
- Page 17 PART LIST—Model No. WLTL29010 R0701A Key No. Qty. Description Key No. Qty. Description Handrail Bolt Motor Tension Nut Handrail Star Washer Upright Endcap Console Screw Right Foot Rail Handrail Platform Screw Console Insert Screw Front Roller Adj. Bolt Key/Clip Wire Harness...
- Page 18 EXPLODED DRAWING—Model No. WLTL29010 R0701A...
-
Page 19: Ordering Replacement Parts
• The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAWING in the center of this manual). WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
