Your laser level has been engineered and manufactured to Ryobi's high standards for depend-
ability, ease of operation, and operator safety. When properly cared for, it will give you years of
rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the
operator's manual before using this product.
Thank you for buying a Ryobi product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
AIRgrip
RLAG113S
LASER LEVEL
™
1
Advertisement
Related Manuals for Ryobi AIRgrip RLAG113S
Summary of Contents for Ryobi AIRgrip RLAG113S
- Page 1 LASER LEVEL ™ RLAG113S Your laser level has been engineered and manufactured to Ryobi’s high standards for depend- ability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ........................ Safety Rules ........................3-4 Symbols ..........................5 Features........................... 6-7 Assembly ..........................8 Operation........................9-4 Maintenance ........................ 5-6 Troubleshooting ........................ 7 Parts Ordering / Service ....................8 iNTROdUCTiON This laser level has many features for making its use more pleasant and enjoyable. -
Page 3: Safety Rules
SAFETY RULES n Do not place the laser level in a position WARNING! that may cause anyone to stare into the laser beam intentionally or unintention- READ AND UNDERSTAND ALL IN- ally. Serious eye injury could result. STRUCTIONS. Failure to follow all n Do not operate the laser level around instructions listed below, may result in children or allow children to operate the... - Page 4 SAFETY RULES n Avoid exposing the laser level to shock, n Save these instructions. Refer to them continuous vibration or extreme hot or frequently and use them to instruct others cold temperatures. Damage to the tool who may use this laser level. If you loan and/or serious injury to the user could someone this laser level, loan them these result.
-
Page 5: Symbols
Call thoroughly and understand completely the 1300 361 505 for your nearest RYOBI operator’s manual. Save this operator’s AUTHORIZED SERVICE CENTER. manual and review frequently for con- tinuing safe operation and instructing others who may use this product. -
Page 6: Features
FEATURES PRODUCT SPECIFICATIONS Recommended Use......................Indoor Length of Laser Line ............Up to 40 12m, Horizontal or Vertical Laser ....................Class II, <1mW, 630-660nm Power Supply ..................2 AA, 1.5 Volt Batteries Battery Life — Laser Only ........40 Hours Continuous Use—Alkaline Batteries Battery Life —... - Page 7 FEATURES case Multi-FuNctiON Base velcrO ® strap push piNs Fig. KNOW yOUR LASER LEvEL MULTi-FUNCTiON BASE See Figures 1 - 2. The multi-function base allows your laser level to be used on irregularly shaped walls or ob- Before attempting to use this product, famil- jects, as well as on a tripod.
-
Page 8: Assembly
ASSEMBLY UNPACKING WARNING: This product has been shipped completely assembled. If any parts are missing, do not operate this n Carefully remove the tool and any accesso- tool. Please return to the place of purchase ries from the box. Make sure that all items or call 1300 361 505 for assistance. -
Page 9: Operation
OPERATiON Place the battery cover plate back onto WARNiNG: the laser level and slide down to secure. Do not allow familiarity with tools to BatterY cOver plate make you careless. Remember that a careless fraction of a second is sufficient to inflict serious injury. - Page 10 OPERATiON TURNiNG ON/OFF NOTE: The multi-function base is not used when mounting by vacuum grip. See Figure 4. Place the laser level on the surface you Press the switch located on the right side of want it secured to and push in slightly to the laser level to turn it ON and OFF.
- Page 11 OPERATiON ROUGH SURFACE AdAPTOR Release the laser level when you hear a change in motor sound. See Figure 6. USiNG MULTi-FUNCTiON BASE Using the rough-surface adaptor, you can use the laser level’s AIRgrip feature to positon the ™ See Figure 7. unit on many non-smooth surfaces, including Velcro strap, push pin, and tripod mounting...
- Page 12 OPERATiON objects such as pipes, x4s, x6s, or metal Align push pin with angled hole located on grates. one side of laser level base and push in to secure. Attach the strap to one side of the laser level base by threading it through the loop ...
- Page 13 OPERATiON AdjUSTiNG THE LASER LiNE ridge marks on the laser head with one of the arrow marks on the body of the laser, See Figure 8. then rotate the laser head in the desired The laser level will project a straight line across direction until the next ridge is aligned with an obstruction or interference, as well as around the same arrow mark.
- Page 14 OPERATiON OPERATiNG THE LASER LEvEL Turn on the laser. See Figures 9 - 10. Rotate the laser head to position the laser line where needed. Place the level in the area where you want the laser line projected. ...
- Page 15 Laser Radiation Do not stare into beam Class II Laser Product Max. Power Output <1mW Wavelength 630-660nm Environmental Protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
-
Page 16: Maintenance
MAINTENANCE ALWAYS BE AWARE of the location where the laser light is emitted when using the level. AL- WAYS MAKE SURE that any bystanders in the vicinity of use are made aware of the dangers of looking directly into the laser beam. DA N G E R DA N G E R Avoid direct exposure to the beam... - Page 17 MAINTENANCE CAUTION! IMPORTANT! CAUTION Class II Laser Product This is a Class 2 laser tool and is manufactured to comply with Laser radiation emitted from tool international safety rule EN 60825 - 1 January 2008. Max. Power Output <1mW Areas should be marked with a Warning Sign. Wavelength 630-660nm The use with optical instructments as magnifier, telescopes or theodolites LASER RADIATION EMITTED...
- Page 18 Please call 1300 361 505 for the nearest Ryobi Authorized Service Center. You can also check our web site at www.ryobitools.com for a complete list of Authorized Service Centers.
