Page 1: Operating Instructions
Waist-High Stand-On Scale Models 6855, 6855KGEU 6856 & 6856KGEU Operating Instructions CARDINAL SCALE MFG. CO. PO BOX 151 • WEBB CITY, MO 64870 1930-M458-O1 Rev B Printed in USA PH (417) 673-4631 • FAX (417) 673-5001 03/04 Web Site - http://www.detectoscale.com... -
Page 3: Specifications
WAIST-HIGH STAND-ON SCALE Thank you for purchasing our model 6855 (6855KGEU) or 6856 (6856KGEU) Waist-High Stand-On Scale. It has been manufactured with quality and reliability at our factory in Webb City, MO USA. Your scale has been tested before leaving our factory to insure accuracy and dependability for years to come. -
Page 5: Unpacking Instructions
UNPACKING INSTRUCTIONS • Remove staples or cut along bottom of carton. Lift carton off pallet. • Check for any damage incurred in shipping. If scale has been damaged, place a claim with the carrier. It is the responsibility of the purchaser to file all claims for any damages or loss incurred during transit. - Page 6 OPERATING INSTRUCTIONS 1. Install six (6) “C” size Alkaline batteries or if ordered with the Indicator scale, plug the power supply module into an appropriate power receptacle. Plug the small connector end of the power supply cord into the power jack located in the bottom right corner at the back of the indicator.
-
Page 7: Height Rod Instructions
Height Rod Instructions Height Rod Hole Location • Please check Height Rod hole locations before installing Height Rod. • Some models may require holes to be 1” from edge drilled. of column to center of hole • Please follow the measurements for drilling holes if necessary. -
Page 8: Part Identification
PART IDENTIFICATION... - Page 9 PART IDENTIFICATION ITEM PART DESCRIPTION 6855 6856 NUMBER 1930-D330-0A WEIGHBRIDGE ASSY 1930-D445-OA WEIGHBRIDGE ASSY (6856) 1930-C338-08 MAT W/ADHESIVE 1930-C452-08 MAT W/ADHESIVE (6856) 6007-0034 HEX HEAD SCREW 5/16-18 UNC-2A X 3/4” 6024-0050 LOCK WASHER 5/16” 6013-0275 HEX NUT 5/16-18 UNC-2B 1930-C143-0A...
