OPERATING MANUAL
BEDIENUNGSANLEITUNG
MODE D'EMPLOI
MANUAL DE FUNCIONAMIENTO
MANUALE DI ISTRUZIONI
ΕΓ ΕΙΡΙ∆Ι
ΛΕΙΤ ΥΡΓΙΑΣ
O
M
PERATING
ANUAL
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
VRF SYSTEM
MANUAL DE INSTRUÇÕES
INDOOR UNIT
Cassette Type
AUXB07L
AUXB09L
AUXB12L
AUXB14L
AUXB18L
AUXB24L
AUXA30L
AUXA36L
AUXA45L
AUXA54L
AUXD18L
AUXD24L
KEEP THIS MANUAL
FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED
P/N9369313035-04
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AirStage AUXB07L
Summary of Contents for AirStage AUXB07L
- Page 1 MODE D’EMPLOI MANUAL DE FUNCIONAMIENTO MANUALE DI ISTRUZIONI ΕΓ ΕΙΡΙ∆Ι ΛΕΙΤ ΥΡΓΙΑΣ PERATING ANUAL РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ VRF SYSTEM MANUAL DE INSTRUÇÕES INDOOR UNIT Cassette Type AUXB07L AUXB09L AUXB12L AUXB14L AUXB18L AUXB24L AUXA30L AUXA36L AUXA45L AUXA54L AUXD18L AUXD24L KEEP THIS MANUAL...
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ........1 OPERATING TIPS ........... 4 NAME OF PARTS ........... 2 CLEANING AND CARE .......... 5 MANUAL AUTO OPERATION ....... 3 TROUBLESHOOTING ..........7 ADJUSTING THE DIRECTION OF SPECIFICATIONS ........... 8 AIR CIRCULATION ..........3 SAFETY PRECAUTIONS G Before using the appliance, read these “PRECAUTIONS”... -
Page 3: Name Of Parts
NAME OF PARTS AUXB 07/09/12/14/18/24 AUXD 18/24 AUXA 30/36/45/54 (optional) 4 Operating Control Panel and Indicator Lamps 1 Air Filter 5 FILTER Indicator Lamp (Red) 2 Air Flow Direction Flaps It lights on if the filter became dirty. 3 Air Intake Grille Clean the filter referring to “CLEANING AND CARE”. -
Page 4: Manual Auto Operation
MANUAL AUTO OPERATION Use the MANUAL AUTO operation in the event the remote control unit is lost or otherwise unavailable. Do not press the MANUAL AUTO button with wet hands or pointed objects, otherwise an electric CAUTION! shock or malfunction may occur. Starting Operation Press the MANUAL AUTO button on the operating control panel. -
Page 5: Operating Tips
OPERATING TIPS Operation and Performance About priority state and standby state ● Multiple indoor units can be connected within the same system. Depending on the system, choice of operating mode are limited. Cooling priority state When the other indoor units within the same system operate in cooling or dry mode, heating can not be selected at the same time. -
Page 6: Cleaning And Care
CLEANING AND CARE G Before cleaning the unit, be sure to stop the unit and disconnect the power supply. CAUTION! G Do not stand on an unstable platform when cleaning. G When removing and replacing the air filters, be sure not to touch the heat exchanger, as per- sonal injury may result. - Page 7 ● AUXD 18/24, AUXA 30/36/45/54 When the filter lamp flashes, remove and 4. Re-attach the air filters to the intake grille. clean the filter. 1 Replace the air filter into its holder. 2 Make sure that the air filter makes contact with the filter 1.
-
Page 8: Troubleshooting
TROUBLESHOOTING The following conditions are not breakdowns or operation failures. Symptom Problem See page ● If the unit is stopped and then immediately started again, the compressor will not Doesn’t operate immedia- — tely: operate for about 3 minutes, in order to prevent fuse blowouts. ●... -
Page 9: Specifications
● The problem cannot be solved even when the troubleshooting checks have been performed. ● The OPERATION indicator lamp (green) is flashing very fast. ● The wired remote controller or simple remote controller indicate Er (when connected). ● It has burning smell. SPECIFICATIONS MODEL AUXB07L AUXB09L AUXB12L AUXB14L AUXB18L AUXB24L...
