Insignia NS-CNV43 GPS Quick Setup Manual

Congratulations on your purchase of a high-quality
Insignia product. Your GPS is designed for reliable and
trouble-free performance. Use this guide for initial setup.
See your User Guide for more information.
Package contents
• 4.3" GPS • Micro SD memory card
• Car DC power adapter • SIM card
• USB cable • User Guide
• Mounting bracket • Quick Setup Guide
• Mounting cradle
Setting up your GPS

Charging the battery

Your GPS comes with a built-in rechargeable battery.
Fully charge the battery before using the GPS for the first
time. Charging time is normally about three hours. A
fully charged battery delivers about two hours of use.
See "Connecting power to your GPS" below.
Connecting power to your GPS
Connecting to a cigarette lighter socket
CAUTION: Disconnect the GPS from the DC power adapter when
starting the vehicle.
• Plug the USB connector on the DC power adapter into the USB
port on the side of the GPS, then plug the DC plug into the
vehicle's 12-24V DC accessory socket (cigarette lighter socket).
Features
Front and side panels
Power button
Charge
indicator
LCD
screen
Mounting Microphone
slots
Back panel
Micro SD and
SIM card cover
cigarette lighter
Volume
control
USB port
Reset
button
Fig. 1
Mounting your GPS in a vehicle
Speaker
WARNING: The assembly must not be mounted so that it impairs the driver's view of the road.
Make sure that your car's airbags are not obstructed by the GPS.
Use the supplied mounting bracket and cradle to mount your GPS in a vehicle.
1 Slide the mounting cradle onto the end of the mounting bracket to secure it.
2 Set the bottom edge of the GPS onto the mounting cradle. Then push the retaining
bracket at the top of the mounting cradle (1) toward the GPS unit. To remove the
unit, push the retaining bracket at the top of the mount cradle toward the back of
the GPS.
3 Lift the suction cup lever, then press the suction cup to the windshield. Press down
on the suction cup lever (2) to secure the bracket to the windshield.
4 Rotate the mounted GPS (3) to a comfortable viewing position.
socket
Quick Setup Guide
NS-CNV43 GPS
Actual product may vary from image shown.
Fig. 2
