3.3.

STAGE 3 - INSTALLING THE SYSTEM

1) Inspect the package, you should see: a unit gateway, an antenna, an adapter, a User Manual. Please
note: the WINNER unit comes without the SIM card(s).
2) Connect the antenna at a distance greater than 1 meter from the unit. Location of the antenna is
important in order to get best performances, thus once you turn the power on, make sure you have
best reception and clear conversation with the unit.
3) Insert SIM card into the unit:
In case of single channel unit, insert the SIM card in the designated slot (on the right side panel)
adjacent to the antenna connection you will see a thin metallic black colored drawer. Use a small
pointed object such as the point of a ballpoint pen into the little hole on the right side of that
drawer/slot to open the drawer, then insert the SIM into that drawer (SIM face up) and close the
drawer firmly.
4) Connect the gateway unit to a PBX telephone network or telephone line with a RJ-11 cable on the left
side panel nearest to the LEDs.
5) Connect an ordinary analog telephone to the RJ-11 connector nearest to the power (pin 3 and 4 are
used for Tip and Ring).
6) On the left side panel you will find the POWER socket. Connect the adapter (provided with unit) to the
electrical outlet and then to the electrical socket.
Note: The power input is 90 –260 VAC and the output is 12 VDC 1.2 Amp.
7) Wait 90 seconds for the unit to startup.
3.4.

STAGE 4 - ABSTRACT

The Eurotech Communication one-number 'Follow Me' PSTN to GSM router with the Call-Back/Call-
Through feature availability is a clever device that attaches to your home or office telephone PSTN or line
or PBX and forwards all incoming calls to your personal cell phone. 'Follow Me' enables you to accept
phone calls from your office or home line on your mobile anywhere, anytime.
Incoming telephone calls will be automatically forwarded to your mobile phone via the embedded LCR that
utilizes a SIM card of the same GSM network to forward the call to your mobile phone. This device is more
beneficial than similar services available from telephone companies as the inner SIM card enables you to
remain in the same GSM network and thus cut costs of interconnections and high airtime charges by taking
advantage of the lower tariffs of same GSM network calls.
The Call-Back/Call-Through features enables you to enter up to 32 approved numbers that has the
capability and the approval to enter into your organization's PBX (i.e. the call will be made through your
PBX which will provide a dial tone immediately for Call-Through or the unit will call you back, thus giving
you a dial line Call-Back). These features will reduce the billing costs to your company up to 50% and more.
This allows you to decide which employee (telephone number) will be entered and defined as Call-Back or
Call-Through.
The ROUTER device readdresses calls from the landline network to the GSM network and vice-versa.
The readdressing of the calls to the appropriate GSM network is set according to the prefixes that were
updated to SIM 1 and SIM 2. All other prefixes NOT updated in SIM 1 and 2 will be readdressed to the PSTN
(landline).
