Switch as a Desktop
Switch
S 3300 XM, SM, TM, MM
WITCH
The example in Figure 9 shows how the Switch can be used for a group
of users that require dedicated 10Mbps or 100Mbps connections to the
desktop. The 3300 SM Switch provides a Gigabit Ethernet connection to
a SuperStack II Switch 4900 in the basement and the 3300 TM Switch
provides a Gigabit Ethernet connection to a local server.
Figure 9 Using the Switch in a desktop environment
1000Mbps
Switch 3300:
SM
TM
Local server on a switched
XM
1000Mbps connection
MM
Endstations on switched 10Mbps
or 100Mbps connections
Switch 4900
