ShelterLogic 25783 Assembly Instructions

12' x 12' celebration canopy

Table of Contents

Download this manual

12' x 12'

Celebration CanoPY

assembly instructions

DesCriPtion

MoDel #

12' x 12' Celebration Canopy - 4 Leg - Blue

25783

reCoMMenDeD tools

Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored.

THIS IS A TEMPORARY STRUCTURE AND NOT RECOMMENDED AS A PERMANENT STRUCTURE.

Before you start: 2+ individual recommended for assembly, approximate time 1 hr.

1-800-524-9970

150 Callender Road

Canada:

Watertown, CT 06795

1-800-559-6175

www.shelterlogic.com

05-25783-0D

01/07/09

Page 1

Table of Contents

Do you have a question about the 25783 and is the answer not in the manual?

Page 1 DesCriPtion MoDel # 12' x 12' Celebration Canopy - 4 Leg - Blue 25783 reCoMMenDeD tools Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored. THIS IS A TEMPORARY STRUCTURE AND NOT RECOMMENDED AS A PERMANENT STRUCTURE.
Page 2 This shelter product is manufactured with quality materials. It is designed to fit the ShelterLogic custom fabric cover included. ® , LLC ShelterLogic Shelters offer storage and protection from damage caused by sun, light rain, tree sap and animal - bird excrement.
Page 3 12' x 12' Celebration Canopy Parts List Model #25783 Description of Parts: Quantity Part # 53.7" Rafter Tubes 10394 53.7" Rafter Tubes 10395 37.5" Cross Rails 10396 42.4" Upright Tubes 10391 10392 42.4" Upright Tubes 10585 4-Way Top Connectors 4-Way Top Connectors...
Page 4 B. Lift one side of the roof assembly and attach the 3-way corner connector (10385). Put both legs in one side then assemble other side. Ensure all buttons pop into place. DETAIL B 10585 10394 10395 10391 10385 10395 10396 10394 10391 10392 10392 05-25783-0D Page 4...
Page 5 Insert 1 pin (10052) into each hole to secure each foot. Repeat for each leg. See Detail H. B. Insert two anchors into each of the foot plates. (10431). Force each anchor down until completely inserted. Repeat for each leg. See Detail I. 05-25783-0C 05-25783-0D Page 5...
