- Page 1 S E R V I C E I0700110 IPL, LT2223 A2, 2007-07, 502 52 52-05 96041004000 LT2223A2 Spare parts Ersatzteile Pièces détachées Reserve onderdelen Repuestos Reservdelar 502 52 52-05...
- Page 2 ILLUSTRATED PARTS LIST MODEL NO. 96041004000 CUSTOMER CATALOG NO. LT2223A2 PRODUCT NO. 960 41 00-40 532 40 86-43 Rev. 2...
- Page 3 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 DECALS PART PART DESCRIPTION DESCRIPTION 532 18 95-53 Decal, Hood Logo 532 40 03-89 Decal, Warning Sym. 532 19 68-41 Decal, Warning Engine 532 41 17-83 Decal, Replacement 532 19 87-85 Decal, Schematic...
- Page 4 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 SCHEMATIC 02929-194276_Regulated-Tex BATTERY SOLENOID STARTER FUSE BLACK ELECTRIC CLUTCH WHITE BLACK WHITE WHITE GRAY CLUTCH/BRAKE (PEDAL UP) BLACK REVERSE SWITCH PTO SWITCH (NOT IN REVERSE) (DISENGAGED) BLACK BLACK BLACK...
- Page 5 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 ELECTRICAL 194276D...
- Page 6 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 ELECTRICAL PART DESCRIPTION 532 14 49-27 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 18 64-91 Battery Box 532 17 61-38 Switch Interlock 532 17 56-88...
- Page 7 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 CHASSIS chassis-tex_Stealth_II_SRS_6...
- Page 8 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 CHASSIS PART DESCRIPTION 532 41 18-76 Dash 532 18 13-51 Hood 532 18 13-52 Grille 532 19 61-25 Plate Engine 817 06 05-12 Screw 5/16-18 x 3/4 532 41 18-77...
- Page 9 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 DRIVE drive-tex_50-Husq TuffTorq...
- Page 10 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 DRIVE PART PART DESCRIPTION DESCRIPTION 874 49 05-60 Bolt Hex Flghd 5/16-18 x 3.75 532 41 40-06 Transaxle, TUFFTORQ K46 532 19 43-22 Keeper Belt Centerspan 532 18 62-11 Key...
-
Page 11: Mower Deck
TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 MOWER DECK 1 33 48_deck_tex_24_r3... - Page 12 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 19 72-16 Deck Weldment Mower 532 19 72-42 Belt Deck Drive 532 19 72-48 Cover Mandrel LH 532 19 31-97 Pulley Idler 532 19 91-02 Cover Mandrel RH 873 90 06-00 Nut, Lock Flg.
- Page 13 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 ENGINE SPARK ARRESTER KIT engine-tex_24-vgt...
- Page 14 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 ENGINE PART DESCRIPTION - - - - - - Engine Briggs Model No. 445577 532 14 97-23 Muffler 532 19 43-20 Keeper Belt Engine 532 17 93-35 Clutch Electric...
- Page 15 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 STEERING ASSEMBLY 53 8 steering-tex_11-husq PART PART DESCRIPTION DESCRIPTION 532 19 47-32 Gear, Sector Plate 532 19 46-37 Wheel, Steering 532 19 59-68 Axle Asm., Front 819 18 38-12 Washer 9/16 x 2-3/8 x 12 Ga.
- Page 16 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 SEAT ASSEMBLY seat-tex_7-vgt PART PART DESCRIPTION DESCRIPTION 532 40 66-25 Seat 532 17 18-52 Bolt, Shoulder 5/16-18 532 18 01-66 Bracket Pivot Fender 873 80 05-00 Nut, Lock 5/16-18 unc...
- Page 17 TRACTOR - MODEL NO. LT2223A2 (96041004000), PRODUCT NO. 960 41 00-40 MOWER LIFT lift-tex_3 PART PART DESCRIPTION DESCRIPTION 532 19 52-23 Shaft Asm., Lift 819 19 19-12 Washer Clear Zinc 532 19 52-30 Lever Asm., Lift 532 19 42-08 Pin Cotter 5/16 Bow Tie Lock...
- Page 18 03.16.10 JA Printed in the U.S.A.
