- Page 1 IPL, LT2217 CMA, 96061027301, 2010-03 LT2217 CMA Spare parts Ersatzteile Pièces détachées Reserve onderdelen Repuestos Reservdelar...
-
Page 2: Wheels And Tires
TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 DECALS 27 MAX + _ 90N MAX + _ 150N PART PART DESCRIPTION DESCRIPTION 532 40 03-89 Decal Warning Sym. CE 532 18 39-31 Decal Bagger 532 19 68-41 Decal Warning Eng. - Page 3 TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 SCHEMATIC 38 SCH08 12VDC STARTER AMMETER BATTERY SOLENOID (OPTIONAL) STARTER FUSE WHITE BLACK BLACK FBI BUZZER SWITCH CLUTCH / BRAKE ATT'MENT CLUTCH (PEDAL UP) (CLUTCH OFF) GREEN OPERATOR PRESENCE RELAY BLACK GRAY HOUR...
- Page 4 TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 ELECTRICAL 32 With Ammeter Option D .C Without Ammeter Option...
- Page 5 TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 ELECTRICAL 32 PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd. 1/4-20 unc x 3/4 532 17 61-38 Switch Interlock 532 18 37-59 Harness Asm. Light w/4152J 532 00 41-52 Bulb Light #1156 532 16 59-87...
-
Page 6: Chassis And Enclosures
TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 CHASSIS AND ENCLOSURES 39 26 25 chassis_CRD_Laser-SV II_6_r3... - Page 7 TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 CHASSIS AND ENCLOSURES 39 PART PART DESCRIPTION DESCRIPTION 532 17 46-20 Chassis 532 18 13-56 Cover Battery 532 18 03-84 Drawbar 532 19 94-88 Backplate Asm. CRD 817 06 06-12 Screw 3/8-16 x 3/4 872 14 06-20 Bolt Rdhd.
- Page 8 TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 DRIVE 40 drive-CRD_HYDROGR_fender_1_r2...
- Page 9 TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 DRIVE 40 PART PART DESCRIPTION DESCRIPTION - - - - - - - Transaxle Hydro Gear 321-0510 532 16 58-50 Bushing, Bellcrank Grnd. Dr. 532 19 27-06 Rod, Shift Fender Adjust Lt. 819 13 32-10 Washer 13/32 x 2 x 10 Ga.
-
Page 10: Optional Equipment
TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 ENGINE 24 OPTIONAL EQUIPMENT Spark Arrester engine-CRD_bs_21... - Page 11 TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 ENGINE 24 PART DESCRIPTION 532 17 05-51 Control Throttle/Choke 817 72 04-08 Screw Hex Thd. Cut 1/4-20 x 1/2 - - - - - - - - Engine Briggs Model 31E777-1439-B1 532 18 86-55 Muffler 532 17 18-77...
-
Page 12: Steering Assembly
TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 STEERING ASSEMBLY 41 steering-CRD_Prem2_1_w118... - Page 13 TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 STEERING ASSEMBLY 41 PART DESCRIPTION 532 42 41-46 Steering Wheel 532 19 35-42 Front Axle Assembly 532 16 98-40 Spindle Assembly, LH 532 16 98-39 Spindle Assembly, RH 532 12 49-31 Bearing, Race, Thrust, Hardened 532 12 17-48...
-
Page 14: Mower Deck
TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 MOWER DECK 44 117 119 41 119 Deck-CRD_97cm_Elect_1_r5... - Page 15 TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 MOWER DECK 44 PART PART DESCRIPTION DESCRIPTION 532 42 91-21 Housing Asm. Mower 97 CRD 532 42 95-32 Belt Drive 97 Mower 532 43 18-64 Bracket Asm. S-Bar Chass 97 CRD 532 16 54-82 Shaft Asm w/Lwr Brg RH Thd CRD 532 12 46-70...
-
Page 16: Mower Lift
TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 MOWER LIFT 45 17 18 20 lift-rh.1piece_9 PART PART DESCRIPTION DESCRIPTION 819 13 10-16 Washer 13/32 x 5/8 x 16 Ga. 532 40 49-81 Plunger Asm. Lift Lever 532 15 94-71 Shaft Asm. -
Page 17: Seat Assembly
TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 SEAT ASSEMBLY 42 seat-CRD_knob_1 PART PART DESCRIPTION DESCRIPTION 532 19 78-95 Seat 532 12 12-48 Bushing Snap Blk. Nyl. 50 Id. 532 14 05-51 Bracket Pnt. Pivot Fender 872 05 04-12 Bolt Rdhd. - Page 18 TRACTOR - - MODEL NO. LT2217CMA (96061027301), PRODUCT NO. 960 61 02-73 BAGGER 46 KEY PART KEY PART DESCRIPTION DESCRIPTION 532 16 57-87 Grip Handle 532 42 86-10 Tube Handle Bagger CRD 532 16 94-84 Retainer Clip 532 12 39-76 Nut Lock 1/4 Lge.
