- Page 1 J O N S E R E D S E R V I C E 03090 LT2218A2 Operator's Manual...
-
Page 2: Safety Rules
SAFETY RULES Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. • Do not operate machine without the entire grass catcher, WARNING: In order to prevent ac- discharge guard, or other safety devices in place and ci den tal starting when setting up,... - Page 3 SAFETY RULES Safe Operation Practices for Ride-On Mowers III. CHILDREN GENERAL SERVICE • Never operate machine in a closed area. Tragic accidents can occur if the operator is not alert to • Keep all nuts and bolts tight to be sure the equipment the presence of children.
-
Page 4: Table Of Contents
PRODUCT SPECIFICATIONS CUSTOMER RESPONSIBILITIES Gasoline Capacity 4 Gallons • Read and observe the safety rules. and type: Unleaded Regular • Follow a regular schedule in maintaining, caring for Oil Type (API-SG-SL): SAE 30 (above 32°F) and using your tractor. SAE 5W-30 (below 32°F) •... -
Page 5: Assembly
UNASSEMBLED PARTS Slope Sheet (1) Oil Drain Tube (2) Keys ASSEMBLY Your new tractor has been assembled at the factory with the exception of those parts left unassembled for shipping puposes. When right or left hand is mentioned in this man ual, it means NEGATIVE (BLACK)CABLE when you are in the operating po si tion (seated be hind the... - Page 6 ASSEMBLY NOTE: You may now roll or drive your tractor off the skid. CHECK FOR PROPER POSITION OF ALL Follow the ap pro pri ate instruction below to remove the BELTS tractor from the skid. See the figures that are shown for replacing motion and WARNING: Before start ing, read, un der stand and fol low mower blade drive belts in the Service and Adjustments all in struc tions in the Op er a tion section of this man u al.
-
Page 7: Operation
OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their mean- ing. FAST SLOW REVERSE HIGH NEUTRAL CHOKE IGNITION SWITCH ENGINE START MOWER HEIGHT MOWER LIFT REVERSE ENGINE ON PARKING BRAKE ENGINE OFF OPERATION SYSTEM (ROS) - Page 8 OPERATION KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. FIG.
- Page 9 OPERATION The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any ad just ments or repairs. We rec om mend standard safety glasses or a wide vision safety mask worn over spectacles.
- Page 10 OPERATION TO OPERATE MOWER TO ADJUST MOWER CUT TING HEIGHT (See Fig. 8) Your tractor is equipped with an operator presence sensing switch. Any attempt by the operator to leave the seat with The po si tion of the at tach ment lift le ver (A) de ter mines the the engine running and the attachment clutch engaged will cut ting height.
-
Page 11: Before Starting The Engine
OPERATION TO OPERATE ON HILLS TOWING CARTS AND OTHER AT TACH MENTS Tow only the attachments that are recommended by and CAUTION: Do not drive up or down hills comply with specifications of the manufacturer of your trac- with slopes greater than 15° and do not tor. - Page 12 OPERATION TO START ENGINE (See Fig. 3) PURGE TRANSMISSION When starting the engine for the first time or if the engine CAUTION: Never engage or disengage has run out of fuel, it will take extra cranking time to move freewheel lever while the engine is fuel from the tank to the engine.
-
Page 13: Operation
OPERATION MOWING TIPS • Mower should be properly leveled for best mowing performance. See “TO LEVEL MOWER HOUSING” in the Service and Adjustments section of this manual. • The left hand side of mower should be used for trim- ming. •... -
Page 14: Maintenance Schedule
MAINTENANCE BEFORE EVERY EVERY EVERY EVERY EVERY BEFORE MAINTENANCE EACH SEASON STORAGE SCHEDULE HOURS HOURS HOURS HOURS Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling Check Mower Levelness... -
Page 15: Maintenance
MAINTENANCE TRACTOR BLADE CARE Always observe safety rules when per form ing any main- For best results mower blades must be sharp. Re place te nance. worn, bent or damaged blades. BRAKE OPERATION CAUTION: Use only a replacement If tractor requires more than five (5) feet to stop at highest blade approved by the manufacturer of speed in high est gear on a level, dry concrete or paved your tractor. -
Page 16: Clean Air Screen
MAINTENANCE TO CHANGE ENGINE OIL (See Figs. 14 and 15) • Coat terminals with grease or petroleum jelly. • Reinstall battery (See “REPLACING BATTERY" in Determine temperature range expected before oil change. the SERVICE AND ADJUSTMENTS section of this All oil must meet API service classification SG-SL. man u al). - Page 17 MAINTENANCE MUFFLER CLAMP Inspect and replace corroded muffler and spark arrester (if equipped) as it could create a fire hazard and/or dam- age. FUEL FILTER SPARK PLUGS FIG. 16 Replace spark plugs at the beginning of each mowing season or after every 100 hours of operation, whichever CLEANING occurs first.
-
Page 18: Service And Adjustments
SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST - MENTS: • Depress brake pedal fully and set parking brake. • Place attachment clutch in “DISENGAGED” position. • Turn ignition key to “STOP” and remove key. •... -
Page 19: Service And Adjustments
SERVICE AND ADJUSTMENTS • ATTACH FRONT LINK (E) - Work from left side of trac- tor. Insert rod end of link assembly through front hole in tractor front suspension bracket (F). • Insert end of link (E) into hole in front mower bracket and secure with washer and retainer spring (J). - Page 20 SERVICE AND ADJUSTMENTS TO LEVEL MOWER • If adjustment is necessary, see step in Visual Adjust- ment instructions above. Make sure tires are properly inflated to the PSI shown on • Recheck measurements, adjust if necessary until both tires. If tires are over or under inflated, it may affect the sides are equal.
- Page 21 SERVICE AND ADJUSTMENTS • Pull belt slack toward rear of trac tor. Carefully remove TO REPLACE MOWER DRIVE BELT belt up wards from trans mis sion input pulley and over (See Fig. 26) cooling fan blades (F). MOWER DRIVE BELT REMOVAL •...
- Page 22 SERVICE AND ADJUSTMENTS TO START ENGINE WITH A WEAK BATTERY TO CHECK BRAKE (See Fig. 29) If tractor requires more than five (5) feet to stop at highest speed in high est gear on a level, dry concrete or paved WARNING: Lead-acid batteries gen- surface, then brake must be serviced.
-
Page 23: Service And Ad Just Ments
SERVICE AND ADJUSTMENTS REPLACING BATTERY TO REMOVE HOOD AND GRILL ASSEMBLY (See Fig. 31) WARNING: Do not short battery ter mi nals by allowing a wrench or any other object to contact both terminals at • Raise hood. the same time. Before connecting battery, remove metal •... -
Page 24: Storage
STORAGE Immediately prepare your tractor for storage at the end ENGINE of the season or if the tractor will not be used for 30 days or more. FUEL SYSTEM IMPORTANT: IT IS IMPORTANT TO PREVENT GUM DEPOSITS WARNING: Never store the trac tor with FROM FORMING IN ES SEN TIAL FUEL SYSTEM PARTS SUCH gas o line in the tank inside a building AS CARBURETOR, FUEL FIL TER, FUEL HOSE, OR TANK... -
Page 25: Trou Ble Shoot Ing
TROUBLESHOOTING POINTS PROBLEM CAUSE CORRECTION Will not start Out of fuel. Fill fuel tank. Engine not “CHOKED” properly. See “TO START ENGINE” in Operation section. Engine flooded. Wait several minutes before attempting to start. Bad spark plug. Replace spark plug. Weak or dead battery. - Page 26 TROUBLESHOOTING POINTS PROBLEM CAUSE CORRECTION Engine dies when Reverse operation system Turn ignition key to tractor is shifted (ROS) is not "ON" while ROS "ON" position. into reverse mower or other attachment See Operation section. is engaged. Engine continues to run Faulty operator-safety presence control system.
- Page 28 Jonsered Motor AB, 532 41 09-84 05.04.07 AP S-433 81 Partille, Sweden. Printed in U.S.A.
