User Manual for Firefly Microscope GT700
Version: 1.0
GT700

User Manual

D
UV M
IGITAL
ICROSCOPE
THANK YOU FOR SELECTING A FIREFLY MICROSCOPE
To take full advantage of this product's advanced capabilities,
and to properly and safely use this product, please read the manual carefully.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT700 and is the answer not in the manual?

Questions and answers

Summary of Contents for Firefly GT700

  • Page 1: User Manual

    User Manual for Firefly Microscope GT700 Version: 1.0 GT700 User Manual UV M IGITAL ICROSCOPE THANK YOU FOR SELECTING A FIREFLY MICROSCOPE To take full advantage of this product’s advanced capabilities, and to properly and safely use this product, please read the manual carefully.
  • Page 2 Firefly Global (www.fireflyglobal.com). Firefly Global assumes no responsibility for any injury, or for any illegal or improper use of the product, that may result from failure to use this product in accordance with the instructions, cautions, warnings, or indications for use published in this manual.
  • Page 3: Table Of Contents

    User Manual for Firefly Microscope GT700 Version: 1.0 ABLE OF ONTENTS Table of Contents.......................3 Introduction ......................4 Warnings & Cautions ....................5 Warning ............................ 5 Caution............................5 Check List ........................7 Operation........................8 Setting up the software application: ..................9 Connect to PC:......................... 9 Power the Device On:...
  • Page 4: Introduction

    Saturation, Hue, Brightness, Contrast and Sharpness for desired applications. System Requirements The Firefly Microscope System requires a user PC system running Windows XP Service Pack 2 or later operating system, a viewing screen, and a PC with an available USB 1.1 or 2.0 port.
  • Page 5: Warnings & Cautions

    In order to obtain optimum performance and ensure patient safety, thoroughly read this manual. Do not use the Firefly Microscope if you notice any signs of damage to the components of the system. Contact customer service for immediate assistance.
  • Page 6 User Manual for Firefly Microscope GT700 Version: 1.0 responsible for verifying that the system complies with the requirements of the system standard IEC 60601-1-1. This product complies with current required standards for electromagnetic interference and should not present problems to other equipment or be affected by other devices.
  • Page 7: Check List

    User Manual for Firefly Microscope GT700 Version: 1.0 HECK Before starting, check that all the following items have been included with your product. If anything is missing, contact your dealer. Microscope Stand x 1 pc Microscope x 1pc Tripod x 1 pc...
  • Page 8 User Manual for Firefly Microscope GT700 Version: 1.0 NOMENCLATURE...
  • Page 9: Operation

    User Manual for Firefly Microscope GT700 Version: 1.0 PERATION To obtain a clear image, please grip the Firefly Microscope; remain still and avoid vibration as much as possible during observation. Setting up the software application: Prior to using the Firefly Microscope for the first time, install the FireflyPro software application following the instructions provided with the installation CD.
  • Page 10: Recommended Holding Position

    User Manual for Firefly Microscope GT700 Version: 1.0 Using the Firefly Microscope System: Recommended holding position: It is suggested to hold the microscope, transparent cover forward, with the thumb held on the equipment. This holding position offers relative stability and allows lens control. The index finger is still free to rotate and adjust the focus wheel (as shown).
  • Page 11: High Ratio >100X

    User Manual for Firefly Microscope GT700 Version: 1.0 High ratio >100x: When there is a need to zoom in more than 100 times, maintaining body stability becomes more paramount. In such instances, a microscope stand is recommended. When a stand is not available, it is suggested that...
  • Page 12: Focus

    User Manual for Firefly Microscope GT700 Version: 1.0 Focus: Based on the relative height of the observed object, the focus wheel can be turned for a clear image. When a higher magnification is required, the focus wheel can be turned to the left (see below). If a larger field of view is required, the microscope can be moved farther away and the wheel turned to the right.
  • Page 13: Using The Image Capture Control

    User Manual for Firefly Microscope GT700 Version: 1.0 Using the image capture control: Press and release the Capture button to capture image frames. The system will generate a shutter sound from the PC speaker as confirmation. C a p t u r...
  • Page 14: Launch The Software Application

    Double-click the FireflyPro.exe icon on your computer desktop: Viewing the Images: FireflyPro software controls your Firefly Microscope. The Microscope communicates with the PC through the USB compact receiver. The user can configure the video properties, review live images, capture images, record video clips and perform a variety of powerful measurement and documentation functions.
  • Page 15: Tool Bars

    User Manual for Firefly Microscope GT700 Version: 1.0 Tool bars The Tools bars enable quick access to the functions of FireflyPro software. The tool bars can be grouped into Control, Images and Device tool bar sets. Control tool bars: Icon...
  • Page 16: Device Tool Bars

    User Manual for Firefly Microscope GT700 Version: 1.0 Device Tool bars: Icon Icon Name Function Description Device Connect Refresh image device connection Select available image devices, such as Microscope Select a video format (default 640x480 YUY2)
  • Page 17: Maintenance And Service

    Do not apply alcohol, chemicals, or water to the lens. Any liquids entering the optical assembly will damage internal components. Use a dry cloth to clean the Digital Firefly Microscope System on a weekly basis. Recycling the system components Within the EU Do not dispose of this product as unsorted municipal refuse.
  • Page 18: Service Policy

    Version: 1.0 Service policy All repairs on products under warranty must be performed or approved by Firefly or its authorized resellers. Unauthorized repairs will void the warranty. In addition, whether or not covered under warranty, any product repair shall exclusively be performed by Firefly-certified service personnel.
  • Page 19: Specifications

    User Manual for Firefly Microscope GT700 Version: 1.0 SPECIFICATIONS Item Specification Weight Approximately 100 g (0.22 lb) Length: 13.0 cm (5.2 inches) Dimensions (approximate) Height: 3.6 cm (1.5 inches) Width: 4.0 cm (1.6 inches) Power USB 5VDC, 150mA Protection against ingress of IPXØ...
  • Page 20: Limited Warranty

    Limited Hardware Warranty (through distributors & resellers) FireFly Global hardware products purchased in the U.S. come with a 1-year limited hardware warranty. The warranty is extended through Firefly Global authorized representatives and resellers. If you have a warranty claim, please contact the store, distributor, or website through which the product was purchased.
  • Page 21 How long does this limited hardware warranty last? The limited hardware warranty on all FireFly Global products begins on the date of the packing slip, invoice, or receipt. The warranty period is not extended if a warranted product or any parts are repaired or replaced. FireFly Global may change the availability of limited hardware warranties, at its discretion, but any changes will not be retroactive.
  • Page 22: Troubleshooting

    Version: 1.0 ROUBLESHOOTING Frequently Asked Questions (FAQs): Q1. What do I do if my Firefly Microscope and FireflyPro software suddenly stops working? Answer: a) Shutdown the Firefly Microscope and disconnect the USB data cable from the computer. b) Close the FireflyPro software.
  • Page 23 User Manual for Firefly Microscope GT700 Version: 1.0 b. Check whether the system is infected by a virus. c. The PC may be too old to properly drive the video stream and does not meet the minimum standards set forth in the instructions. Please use faster system.
