Toa SR-F3 Instruction Manual

SPEAKER SYSTEM
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
[ SR-F3 ]
354
A
20°
542

1. SAFETY PRECAUTIONS

• Be sure to read the instructions in this section carefully
before use.
• Make sure to observe the instructions in this manual as
the conventions of safety symbols and messages
regarded as very important precautions are included.
• We also recommend you keep this instruction manual
handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used
in this manual to prevent bodily injury and property
damage which could result from mishandling. Before
operating your product, read this manual first so you are
thoroughly aware of the potential safety hazards as well as
understand the safety symbols and messages.
WARNING
situation which, if mishandled, could result in death or
serious personal injury.
CAUTION
situation which, if mishandled, could result in moderate
or minor personal injury, and/or property damage.
167 149
The side as viewed from
the direction of arrow A
Indicates a potentially hazardous
Indicates a potentially hazardous
INSTRUCTION MANUAL
[ SR-L3 ]
1082
When Installing the Unit
• Install the unit only in a location that can structurally
support the weight of the unit and the mounting bracket.
Doing otherwise may result in the speaker falling down
and causing personal injury and/or property damage.
• Flying Precautions (SR-F3 only)
Be sure to follow the instructions below. The suspension
wires or belts may be off or snap and the speaker may
fall, causing personal injuries.
·
Check to confirm that the suspension wires and belts
are strong enough to withstand the speaker load.
·
The connectors of the suspension wires and belts must
be securely linked with those of the speaker.
·
All parts and components (such as enclosures, metal
pieces, and screws) must be free from any
deformation, crack, and corrosion.
SR-F3/SR-L3
Unit: mm
652
WARNING
