SRS-D4100/D5100
Ver 1.1
AMP
Ref. No. Part No. Description
C529 1-165-554-91 CERAMIC CHIP
C530 1-115-339-11 CERAMIC CHIP
C531 1-126-951-11 ELECT
C532 1-115-339-11 CERAMIC CHIP
C533 1-126-951-11 ELECT
C534 1-131-702-11 FILM
C581 1-162-964-11 CERAMIC CHIP
C621 1-124-465-00 ELECT
C622 1-115-339-11 CERAMIC CHIP
C623 1-165-554-91 CERAMIC CHIP
C624 1-115-339-11 CERAMIC CHIP
C625 1-162-961-11 CERAMIC CHIP
C626 1-165-554-91 CERAMIC CHIP
C627 1-162-961-11 CERAMIC CHIP
C628 1-107-823-11 CERAMIC CHIP
C629 1-115-339-11 CERAMIC CHIP
C630 1-115-339-11 CERAMIC CHIP
C631 1-165-554-91 CERAMIC CHIP
C632 1-163-023-00 CERAMIC CHIP
C633 1-115-339-11 CERAMIC CHIP
C634 1-115-339-11 CERAMIC CHIP
C635 1-165-554-91 CERAMIC CHIP
C637 1-165-554-91 CERAMIC CHIP
C638 1-163-023-00 CERAMIC CHIP
C639 1-115-339-11 CERAMIC CHIP
C640 1-115-339-11 CERAMIC CHIP
C641 1-165-554-91 CERAMIC CHIP
C642 1-128-552-51 ELECT
C643 1-162-923-11 CERAMIC CHIP
C644 1-164-739-11 CERAMIC CHIP
C645 1-164-739-11 CERAMIC CHIP
C646 1-131-702-11 FILM
C647 1-131-702-11 FILM
C648 1-131-696-11 FILM
C649 1-131-696-11 FILM
C650 1-163-023-00 CERAMIC CHIP
C651 1-163-023-00 CERAMIC CHIP
C652 1-162-970-11 CERAMIC CHIP
C653 1-165-554-91 CERAMIC CHIP
C654 1-165-554-91 CERAMIC CHIP
C655 1-165-554-91 CERAMIC CHIP
C656 1-165-554-91 CERAMIC CHIP
C657 1-165-554-91 CERAMIC CHIP
C658 1-165-554-91 CERAMIC CHIP
C661 1-115-339-11 CERAMIC CHIP
C662 1-115-339-11 CERAMIC CHIP
C663 1-126-951-11 ELECT
C664 1-126-951-11 ELECT
C666 1-126-947-11 ELECT
C667 1-126-947-11 ELECT
C901 1-119-939-11 ELECT
C902 1-119-939-11 ELECT
14
Remarks Ref. No.
0.1uF 10% 100V
(D5100)
0.1uF 10% 50V
(D5100)
470uF 20% 35V
(D5100)
0.1uF 10% 50V
(D5100)
470uF 20% 35V
(D5100)
0.68uF 5% 50V
(D5100)
0.001uF 10% 50V
(D5100)
0.47uF 20% 50V
0.1uF 10% 50V
0.1uF 10% 100V
*
0.1uF 10% 50V
330PF 10% 50V
*
0.1uF 10% 100V
330PF 10% 50V
0.47uF 10% 16V
0.1uF 10% 50V
0.1uF 10% 50V
0.1uF 10% 100V
0.015uF 10% 50V
0.1uF 10% 50V
0.1uF 10% 50V
0.1uF 10% 100V
0.1uF 10% 100V
0.015uF 10% 50V
0.1uF 10% 50V
0.1uF 10% 50V
0.1uF 10% 100V
47uF 20% 63V
47PF 5% 50V
560PF 5% 50V
560PF 5% 50V
0.68uF 5% 50V
0.68uF 5% 50V
0.22uF 5% 50V
0.22uF 5% 50V
0.015uF 10% 50V
0.015uF 10% 50V
0.01uF 10% 25V
0.1uF 10% 100V
0.1uF 10% 100V
0.1uF 10% 100V
0.1uF 10% 100V
0.1uF 10% 100V
0.1uF 10% 100V
0.1uF 10% 50V
0.1uF 10% 50V
470uF 20% 35V
470uF 20% 35V
47uF 20% 35V
47uF 20% 35V
6800uF 20% 35V
6800uF 20% 35V
Part No. Description
C903 1-119-939-11 ELECT
C904 1-119-939-11 ELECT
C905 1-126-942-61 ELECT
C906 1-113-920-11 CERAMIC
C909 1-162-970-11 CERAMIC CHIP
C910 1-126-947-11 ELECT
C961 1-130-491-00 MYLAR
C962 1-130-491-00 MYLAR
C963 1-130-491-00 MYLAR
C964 1-130-491-00 MYLAR
< CONNECTOR >
CN601 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN902 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
CN903 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN904 1-564-674-11 PIN, CONNECTOR (3.96mm PITCH) 8P
< DIODE >
D51 8-719-988-61 DIODE 1SS355TE-17
D52 8-719-988-61 DIODE 1SS355TE-17

D901

8-719-902-17 DIODE U15G

D902

8-719-902-17 DIODE U15G

D903

8-719-902-17 DIODE U15G

D904

8-719-902-17 DIODE U15G
D905 8-719-902-17 DIODE U15G
D906 8-719-902-17 DIODE U15G
D907 8-719-902-17 DIODE U15G
D908 8-719-902-17 DIODE U15G
D909 8-719-200-02 DIODE 10E-2
D910 8-719-200-02 DIODE 10E-2
D911 8-719-200-02 DIODE 10E-2
D912 8-719-200-02 DIODE 10E-2
< FERRITE BEAD >
FB101 1-400-160-51 INDUCTOR (SMALL TYPE)
FB102 1-400-160-51 INDUCTOR (SMALL TYPE)
FB601 1-400-160-51 INDUCTOR (SMALL TYPE)
FB602 1-400-160-51 INDUCTOR (SMALL TYPE)
FB603 1-400-160-51 INDUCTOR (SMALL TYPE)
FB604 1-400-160-51 INDUCTOR (SMALL TYPE)
< IC >
IC101 6-704-237-01 IC TDA7490L
IC301 6-704-237-01 IC TDA7490L
IC501 8-759-553-45 IC TDA7481 (D5100)

IC601

6-704-332-01 IC TDA8921TH
IC901 6-700-776-01 IC KIA78S09P-TP
< COIL >
L101 1-456-524-11 INDUCTOR
L301 1-456-524-11 INDUCTOR
L501 1-456-720-11 CIL, CHOKE 60uH (D5100)
L601 1-456-790-11 COIL, CHOKE
L602 1-456-790-11 COIL, CHOKE
Remarks
6800uF 20% 35V
6800uF 20% 35V
1000uF 20% 25V
0.0022uF 20% 250V
(AEP, UK, KR)
0.01uF 10% 25V
47uF 20% 35V
0.047uF 5% 50V
0.047uF 5% 50V
0.047uF 5% 50V
0.047uF 5% 50V
(AEP, UK, KR)
33uH
33uH
33uH
33uH
