Stanley Lismore Installation And Operating Instructions Manual

Non boiler solid fuel stove
Hide thumbs Also See for Lismore:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Instructions and Operating Manual
Lismore
Non Boiler Solid Fuel Stove
INSTALLATION AND OPERATING INSTRUCTIONS
This appliance is hot while in operation and retains its heat for a long period of time after use. Children,
aged or infirm persons should be supervised at all times and should not be allowed to touch the hot
working surfaces while in use or until the appliance has thoroughly cooled.
When using the stove in situations where children, aged and/or infirm persons are present a fireguard
must be used to prevent accidental contact with the stove. The fireguard should be
manufactured in accordance with BS 8423:2002.

Advertisement

Table of Contents
loading

Related Manuals for Stanley Lismore

Summary of Contents for Stanley Lismore

  • Page 1 Lismore Non Boiler Solid Fuel Stove INSTALLATION AND OPERATING INSTRUCTIONS This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE NO. General ............... 2 Handling .

  • Page 3: General

    GENERAL 1:2007 Design, Installation and Commissioning of When installing, operating and maintaining your chimneys. Lismore Stove respect basic standards of fire safety. Read these instructions carefully before commenc- FLuES ing the installation. Failure to do so may result in Flues should be vertical wherever possible and damage to persons and property.

  • Page 4: Flue Pipes

    FLuE PIPES Fig.2 A flue pipe should only be used to connect an appli- ance to a chimney and should not pass through any Flue Liner roof space. Sleeve Flue pipes may be of any of the following materials: Flue Flue Pipe Possible Cast iron as described in BS 41:...

  • Page 5: Chimney

    The outlet from the chimney should be above the Fig.4 roof of the building in accordance with the provisions of Building Regulations Approved Document J. Fig.5 CHIMNEy Do not connect to a chimney serving another appliance. The stove is a radiant room heater and must be con- nected to a chimney of the proper size and type.
  • Page 6 If installation is into an existing chimney then it must Fig.8 be sound and have no cracks or other faults which might allow fumes into the house. Older properties, especially, may have chimney faults or the cross section may be too large i.e. more than 200mm diameter.
  • Page 7 CLEARANCE TO COMBuSTIBLES ALCOVE INSTALLATION Fig.9 Fig.12 FIREPLACE INSTALLATION FLuE CLEARANCES CORNER INSTALLATION Fig.10 Fig.13 MANTLE CLEARANCE Fig.11 Fig.14 MINIMuM COMBuSTIBLE ALCOVE...

  • Page 8: Installation Clearances

    If it is found that there is excessive draught in the Building Regulations and B.S. 8303: Part 1 from any chimney then a draught stabiliser should be fitted. part of any flue terminal. These air vents must also Fitting of a draught stabiliser will affect the require- be satisfactorily fire proofed as per Building ment for the permanent air supply into the room in Regulations and B.S.

  • Page 9: External Ducted Air

    Combustible’ Section. HEAT RECOVERy VENTILATION CO ALARM Waterford Stanley recommend the fitting of a CO Where a stove is to be installed in a dwelling with Alarm in the same room as the appliance, this is a Heat Recovery Ventilation (HRV) a number of requirement under UK Building Regulations.

  • Page 10: Location

    FLuE LOCATIONS LOCATION There are several conditions to be considered in Flue outlet to suit 152mm (6”) internal diameter flue selecting a location for your Stanley Lismore Stove. pipe. Fig.17 a. Position in the area to be heated, central locations are usually best.

  • Page 11: Technical Data

    TECHNICAL DATA WOOD MANuFACTuRED SMOKELESS FuEL Room Room Max Output: (kW) 10.6 kW 11 kW Typical refuelling intervals to obtain nominal 1 hour WOOD .75 hrs outputs: Mean Flue Gas Temperature Flue Gas Mass Flue Gross Weight: 200 kgs Flue Outlet: 150mm Efficiency 70.4%...

  • Page 12: Handover

    HANDOVER On completion of the installation allow a suitable period of time for any fire cement and mortar to dry out, when a small fire may be lit and checked to ensure the smoke and fumes are taken from the stove up the chimney and emitted safely to the atmosphere.

  • Page 13: Important Notes

    16. Avoid contact with the appliance when in use as stove reaches very high operating temperatures. 17. This appliance should be regularly maintained by a competent service engineer. Use only replacement parts recommended by Stanley. Making unauthorised modifications, or using unautho- rised parts will invalidate your guarantee and may cause damage or injury.

  • Page 14: Lighting

    LIGHTING Before lighting the stove check with the installer that the installation work and commissioning checks described in the installation instructions have been carried out correctly and that the chimney has been swept clean, is sound and free from any obstructions.

  • Page 15: Operating Instructions

    There are two air con- All fuels should be stored under cover and kept trols on the Lismore non boiler stove, a primary air as dry as possible prior to use. control and a secondary air control.

  • Page 16: De-Ashing

    Fig.20 mend that you remove ashes after you have riddled the fire when the stove is thoroughly cooled. Ashes should be placed in a metal or other non- combustible container with a tight fitting lid. The closed container of ashes should be placed on a non-combustible material, pending final disposal.

  • Page 17: Changing Grate Orientation

    For best combustion of wood it is best to use a flat grate so that it can build up a bed of ash as it burns. The grate on the Lismore Stove can be changed from a coal setting to wood burning setting.

  • Page 18: Fire Safety

    Fig.27 4. DO NOT uSE ABRASIVE PADS OR OVEN CLEANSERS CONTAINING CITRIC ACID ON ENAMELLED SuRFACES. ENSuRE THAT THE CLEANSER MANuFACTuR ERS INSTRuCTIONS ARE ADHERED TO. Hex Bolt GLASS CLEANING FIRE SAFETy The glass will self clean when there is sufficient heat To provide reasonable fire safety, the following generated by the burning fuel.

  • Page 19: Exploded View

    - F01098AXX 41. DAMPER LEVER - V01006AXX 19. OSA BOX COVER - F01101AXX 42. RIDDLING BAR - Z00047AXX 20. LISMORE NB SHELL - F01102AXX 43. FLUE CLEANING DOOR - Z00048AXX 21. BACK BRICK - H00214AXX 44. FIRE FENCE - Z00059AXX 22.

  • Page 20: Installation Check List

    9. The room in which the appliance is located should have an air vent of adequate size to support correct combustion (see Ventilation & Combustion Air Requirement Section for specific details). Manufactured by Waterford Stanley Ltd., Unit 401-403, IDA Industrial Estate, Cork Road, Waterford, Ireland. Tel: (051) 302300 Fax (051) 302315...
