Code Alarm CA 4050 Installation Manual page 9

5 RED
Locate 1 of the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.
6 PINK
Locate the vehicle's ignition wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or
RUN) position. The voltage does not drop out when the key is turned to the
START (or CRANK) position.
Connect the PINK wire to the vehicle's Ignition wire.
This wire is also used for Ignition 1 Output.
4 Pin Auxiliary Output Harness
1 LT GREEN/BLACK
This wire will supply a ( - ) 500mA pulse both upon disarming the system and when
the remote start feature is activated. Locate the factory perimeter alarm disarm
wire from the key cylinder inside the drivers door.
Verification: This wire registers ground if the key is turned to the unlock
position in the driver's door cylinder.
Connect the LIGHT GREEN/BLACK wire to the factory alarm disarm wire.
2 LT BLUE
This wire will supply a ( - ) 500mA pulse upon successful completion of the remote
start activation sequence and is typically used to re-lock the vehicle's doors upon
remote start if necessary.
2009 Audiovox Electronics Corporation. All rights reserved.
BATTERY 12V ( + )
IGNITION 1 ( + )
FACTORY DISARM /
PULSE BEFORE START ( - )
PULSE AFTER START ( - )
9
