- Page 1 Colour Monitor USER GUIDE BENUTZERHANDBUCH MANUEL D'UTILISATION GUIDA UTENTE GUIA DEL USUARIO MODEL : StudioWorks 78DT5...
-
Page 2: Table Of Contents
Table of Contents Introduction ..................1 Monitor Registration................2 Important Precautions................3 Connecting the Monitor..............5 Location and Function of Controls .............9 Control Panel Function ..............10 On Screen Display (OSD) Control Adjustment.........11 OSD Adjustment and Selection Items..........12 Self Diagnostics ................17 Energy Saving Design ..............17 Video Memory Modes ..............18 Display Data Channel (DDC) ............20 Troubleshooting ................21... -
Page 3: Introduction
Features The StudioWorks 78DT5 is a 17-inch (16.0 inches viewable ) intelli- gent, microprocessor based monitor compatible with most analog RGB (Red, Green, Blue) display standards, including IBM PC , PS/2 ®... -
Page 4: Monitor Registration
Serial No. Notice All rights reserved. Reproduction in any manner, in whole or in part, is strictly prohibited without the written permission of LG Electronics Inc. Trademark Acknowledgments GoldStar is a trademark of LG Electronics Inc. IBM is a registered trademark and VGA is a trademark of International Business Machines Corporation. -
Page 5: Important Precautions
Important Precautions This unit has been engineered and manufactured to assure your personal safety, but improper use can result in potential electrical shock or fire hazard. In order not to defeat the safeguards incorpo- rated in this monitor, observe the following basic rules for its installa- tion, use, and servicing. - Page 6 Keep children from dropping or pushing objects into the monitor's cabinet openings. Some internal parts carry hazardous voltages. Do not add accessories that have not been designed for this monitor. During a lightning storm or when the monitor is to be left unattended for an extended period of time, unplug it from the wall outlet.
-
Page 7: Connecting The Monitor
Connecting the Monitor On the back of the monitor are three plug-in connections; one for the AC power cord, and the others for the signal cable from the video card. 1. AC Power Connection One end of the AC power cord is connected into the AC power connector on the back of the monitor. - Page 8 A) Connection to any IBM VGA PC compatible system Figure 3 shows the signal cable connections from the monitor to the Video Graphics Array (VGA) port typical in an IBM PC or PC compati- ble. This also applies to any graphics video card for PC-CAD or work- station that has a 15 pin high density (3 row) D-Sub connector.
- Page 9 B) Connecting to an Apple Macintosh II, Centris, and Quadra Figure 4 shows the connection to an Apple Macintosh, using a sepa- rately purchased adapter. 1. Power OFF both the monitor and the PC. 2. Connect the 15 pin VGA connector of the supplied signal cable to the matching input on the back of the monitor.
- Page 10 Notes on using the BNC connectors with other types of video cards. Follow the example that fits your needs. (BNC cables not included with Monitor.) IN CASE OF EXTERNAL COMPOSITE SYNC SIGNAL: Connect R, G, and B video signals and Composite sync signal to BNC receptacles on rear panel, respectively.
-
Page 11: Location And Function Of Controls
Location and Function of Controls Front View Power ON/OFF Switch OSD ON/OFF Power (DPMS) Indicator Enter button Contrast Adjustment Control OSD Select/Adjustment Control Brightness Adjustment Control Rear View ID Label D-Sub Signal Connector AC Power Socket BNC Signal Connectors... -
Page 12: Control Panel Function
Control Panel Function All functions are adjusted from the microprocessor-based digital controls. Power Indicator OSD ON/OFF Enter Button Power Button Brightness Contrast OSD Select /Adjust Control Increase Increase Decrease Decrease Buttons on the front of the monitor allow you to adjust the image easily through an OSD menu. -
Page 13: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Making adjustments to the image size, position and operating param- eters of the monitor are quick and easy with the On Screen Display Control system, using only the Enter button and Adjustment Control knob. A quick example is given below to familiarize you with the use of the controls. -
Page 14: Osd Adjustment And Selection Items
OSD Adjustment and Selection Items In the previous section, you were introduced to the procedure of selecting and adjusting an item using the OSD system. There are two Main Menu pages: the first one has the 8 most commonly used items, and the second page has items that are used less frequently. - Page 15 To adjust the controls for the first 8 items on Main Menu1, follow the sample procedure shown on page 12. For items on Main Menu 2, the examples below show how to adjust or select the possible options. In general, to adjust items in Main Menu 2 : 1.
- Page 16 MOIRE CONTROL This item allows you to reduce the moire (Moire is caused by interference the periodical display pattern with the periodical dot screen). It is normally OFF. If you want to adjust it, select ON using the adjustment control and push the Enter Button.
- Page 17 OPTION SELECT This item gives access 5 elements; manual degaussing, beep ON/OFF, signal input selection, Video level (0.7V or 1.0V) and exit. Press the Enter button to select the desired item to change. Rotate the adjustment control either to perform the function highlighted (red color) or to select the desired item.
- Page 18 MODE INFORMATION This item provides information about the stored video modes. After highlighting (red color) the mode information icon, press Enter. Rotate the Adjustment Control to see the desired video mode infor- mation. The mode information screens give you some information regarding industry resolution terminology, resolution, and memory mode number.
-
Page 19: Self Diagnostics
Self Diagnostics The Studioworks 78DT5 has a SELF DIAGNOSTICS OSD feature that pops up when there may be possible causes of non-operation. The OSD will highlight a possible reason the display is not showing an image. An example of this may be when you turn on the monitor with no signal cable attached. -
Page 20: Video Memory Modes
Video Memory Modes This multi-synchronous auto-scanning monitor can automatically detect and display several video modes falling within the monitor's scanning range of 30-85KHz Horizontal and 50-120Hz Vertical. In the PC area, this relates to a maximum flicker-free usable resolution of 1280x1024 at a non-interlaced refresh rate of 75Hz Vertical. - Page 21 A note about the video memory modes: There is a total of 40 video memory modes, generally more modes than you will use at any one time. Of these 40 modes, 8 are permanent, facto- ry fixed modes that cannot be changed, and another 8 are set at the fac- tory, but may be overwritten to make more room.
-
Page 22: Display Data Channel (Ddc)
Display Data Channel (DDC) This monitor complies with the VESA (Video Electronics Standard Association) DDC type 2B specification, a new standard allowing a compatible video card 2-way communication with the monitor. This communication includes automatic setup (sometimes referred to as Plug and Play) of the optimum resolution available to both the video card and monitor. -
Page 23: Troubleshooting
Troubleshooting Symptom: Self diagnostics message. Possible causes: The signal cable is not connected. Symptom: The power led is illuminated amber. Possible causes: Display power management mode. (Move mouse to awaken PC.) Check the computer power and graphics adapters configuration. The frequency of the sync input is outside the operating range of the monitor. -
Page 24: Service
Service 1. Unplug the monitor from the wall outlet and refer servicing to quali- fied service personnel when: The power cord or plug is damaged or frayed. Liquid has been spilled into the monitor. The monitor has been exposed to rain or water. The monitor does not operate normally following the operating instructions. - Page 25 Input Specifications Sync signal types Priority Type H. Sync. V. Sync Separate sync. H. Sync. V. Sync. Composite sync. H/V Sync. (N.C : no connection) Signal connector pin assignment Signal (D-Sub) Signal (5 BNC) Color Green Green Green Blue Blue Blue Optional H.
-
Page 26: Specifications
5 Watts DPMS-off mode Dimensions (WxHxD) 412 x 429 x 431mm/16.2 x 16.9 x 17 inches Weight (net) 20.5kg/45.2lbs Information in this document is subject to change without notice and does not represent a commitment on the part of LG Electronics Inc. -
Page 27: Environmental Labelling Of Personal Computers
FOR THE UNITED STATES AND CANADA LG Electronics U.S.A., Inc. will repair or at its option replace, without charge, your product which proves to be defective in material or workmanship under normal use, during the warranty period listed below from the date of original purchase. -
Page 28: Fcc Compliance Statement
- Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by LG Electronics Inc. for compliance could void the user's (or your) authority to operate the equipment. Only peripherals (digital input/output devices, terminals, printers, etc.) certified to comply with the Class B limits may... -
Page 29: Tco'95 Environmental Requirements
P/NO : 3828TUL009K(S-9710) USER GUIDE MANUEL D'UTILISATION MODEL : StudioWorks 78DT5 78DT5 78DT5 78DT5 78DT5 78DT5...
