- Page 1 795FT/795FT Monitor User’s Guide Benutzerhandbuch Manuel d’utilisation Guida Utente Guia del Usuario...
-
Page 2: Trademark Acknowledgments
Notice Copyright © LG Electronics Inc., 1999 All Rights Reserved This document is protected by copyright with all rights reserved. No part of the document may be reproduced or transmitted by any means or in any form, without prior consent in writing from LG Electronics Inc. -
Page 3: Table Of Contents
Table of Contents Introduction Introduction Important Precautions Installation Connecting the Monitor Making use of USB (Universal Serial Bus)* Operation Location and Function of Controls Control Panel Function On Screen Display (OSD) Control Adjustment On Screen Display(OSD) Selection and Adjustment Technical Information Energy Saving Design Low Radiation Compliance (MPR II) and DDC (Display Data Channel) Video Memory Modes... -
Page 4: Introduction
Introduction Introduction Thank you for purchasing a high resolution monitor. It will give you high resolution performance and convenient reliable operation in a variety of video operating modes. Features The monitor is a 17 inches (16.0 inches viewable ) intelligent, microprocessor based monitor compatible with most analog RGB (Red, Green, Blue) display standards, including IBM PC ®... -
Page 5: Important Precautions
Introduction Operation Important Precautions This unit has been engineered and manufactured to assure your personal safety, but improper use can result in potential electrical shock or fire hazard. In order not to defeat the safeguards incorporated in this monitor, observe the following basic rules for its installation, use, and servicing. - Page 6 Introduction Operation Important Precautions Do not add accessories that have not been designed for this monitor. During a lightning storm or when the monitor is to be left unattended for an extended period of time, unplug it from the wall outlet. Do not bring magnetic devices such as magnets or motors near the picture tube.
-
Page 7: Installation
Installation Connecting the Monitor Connection to any IBM Figure 1 shows the signal cable connections from the monitor to the Video Graphics Array (VGA) port typical in an IBM PC or PC VGA PC compatible compatible. This also applies to any graphics video card for PC-CAD system or workstation that has a 15 pin high density (3 row) d-Sub connector. - Page 8 Installation Connecting the Monitor Connecting to an Apple Figure 2 shows the connection to an Apple Macintosh, using a separately purchased adapter. Macintosh PC Power OFF both the monitor and the PC. Locate the appropriate MAC to VGA adapter block at your local computer store.
-
Page 9: Making Use Of Usb (Universal Serial Bus)
Installation Making use of USB (Universal Serial Bus) * USB (Universal Serial Bus) is an innovation in connecting your computer to your monitor. By using the USB, you will be able to connect your mouse, keyboard, printer, and other peripherals to your monitor instead of having to connect them to your computer. - Page 10 Installation Making use of USB (Universal Serial Bus) * Example of connection monitor scanner computer keyboard mouse printer NOTE To activate the USB hub function, the monitor must be connected to a USB compliant PC(OS) or another hub with the USB cable(enclosed). When connecting the USB cable, check that the shape of the connector at the cable side matches the shape at the connecting side.
- Page 11 Installation Making use of USB (Universal Serial Bus) * USB-Monitor Software As an added advantage, the monitor can be controlled from a computer with a mouse or keyboard. Making adjustments to the function image size, position, screen color and operating parameters of the monitor is easy with the USB-Monitor software (please refer to the supplied disk).
-
Page 12: Operation
Operation Location and Function of Controls Front View • Power Button • • • Power Indicator OSD Button SET Button Buttons Rear View ID Label • • D-Sub Signal Connector • • USB upstream port * * Applies to 795FT plus only. AC Power USB downstream ports * Socket... -
Page 13: Control Panel Function
Operation Control Panel Function Front Panel Controls Power Indicator OSD Button The power indicator light is shown in the Use this button to enter power button. This indicator lights up or exit the on screen green when the monitor operates display. -
Page 14: On Screen Display (Osd) Control Adjustment
Operation On Screen Display (OSD) Control Adjustment Making adjustments to the image size, position and operating parameters of the monitor are quick and easy with the On Screen Display Control system. A quick example is given below to familiarize you with the use of the controls. Following section is an outline of the available adjustments and selections you can make using the OSD. -
Page 15: On Screen Display(Osd) Selection And Adjustment
Operation On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selection and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the items that are shown on the Menu. OSD Adjust Description BRIGHTNESS CONTRAST... - Page 16 Operation On Screen Display(OSD) Selection and Adjustment OSD Adjust Description Vertical Size SIZE To adjust image height. SIZE Horizontal Size To adjust image width. Side Pincushion To correct the bowing in and out of the SHAPE image. Side pincushion balance To correct the balance of both sides bowling.
- Page 17 Operation On Screen Display(OSD) Selection and Adjustment OSD Adjust Description SPECIAL DEGAUSS To manually demagnetize the DEGAUSS screen which may show some RECALL image or color incorrectly. MOIRE H: 0/V: 0 CONVERGENCE H:50/V:50 PURITY 54.4kHz/60.0Hz RECALL If the monitor is operating in a USER MODE SPECIAL factory preset mode, this control...
-
Page 18: Energy Saving Design
Operation Energy Saving Design This monitor complies with the EPA's Energy Star program, which is a program designed to have manufacturers of computer equipment build circuitry into their products to reduce power consumption during time of non-use. This monitor also goes into its energy saving mode if you exceed the monitor's operating limits, such as the maximum resolution of 1600x1200 or the frequency refresh rates of 30-96kHz horizontal or 50-160Hz vertical. -
Page 19: Low Radiation Compliance (Mpr Ii) And Ddc (Display Data Channel)
Operation Low Radiation Compliance (MPR II) and DDC (Display Data Channel) Low Radiation Compliance This monitor meets one of the strictest guidelines available today for low radiation emissions, offering the user extra shielding and an antistatic (MPR II) screen coating. These guidelines, set forth by a government agency in Sweden, limit the amount of emission allowed in the Extremely Low Frequency (ELF) and Very Low Frequency (VLF) electromagnetic range. -
Page 20: Video Memory Modes
Technical Information Video Memory Modes The monitor has 38 memory locations for display modes, 12 of which are factory preset to popular video modes. Display Modes Display Modes (Resolution) Horizontal Freq.(kHz) Vertical Freq.(Hz) (Resolution) 31.469 VESA 720 x 400 VESA 31.469 640 x 480 VESA... -
Page 21: Troubleshooting
Technical Information Troubleshooting Check the following before calling for service. SELF DIAGNOSTICS message. The signal cable is not connected. OUT OF FREQUENCY message appears. The frequency of the sync input is outside the operating range of the monitor. *Horizontal Frequency : 30-96kHz *Vertical Frequency : 50-160Hz Use the graphics board's utility software to change the frequency setting (Refer to the manual for graphics board). -
Page 22: Service
Technical Information Service Unplug the monitor from the wall outlet and refer servicing to qualified service personnel when : The power cord or plug is damaged or frayed. Liquid has been spilled into the monitor. The monitor has been exposed to rain or water. The monitor does not operate normally following the operating instructions. -
Page 23: Specifications
Technical Information Specifications Sync Signal Types Resolution Type H.Sync. V.Sync. H. Sync. V. Sync. Separate Sync. Composite Sync. H/V. Sync. N.C. Sync. On Green N.C. N.C. (N.C : No Connection) Signal Connector 15pin VGA Connector Pin Assignment Signal(D-Sub) Signal(D-Sub) N.C. Green Ground Blue... -
Page 24: Video Input
10 % to 90 % non-Condensing Storage Condition Temperature 0˚C to 60 C Humidity 5 % to 90 % non-Condensing NOTE Information in this document is subject to change without notice and does not represent a commitment on the part of LG Electronics Inc. -
Page 25: Appendix
Appendix Communications Regulation Information This equipment has been tested and found to comply within the limits of a FCC Compliance Statement Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 26: Environmental Labelling Of Personal Computers
Appendix Environmental Labelling of Personal Computers You have just purchased a TCO’99 approved and labelled product! Your Congratulations! choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. - Page 27 Appendix Environmental Labelling of Personal Computers Approval requirements cover a wide range of issues: environment, ergonomics, usability, emission of electric and magnetic fields, energy consumption and electrical and fire safety. The environmental demands impose restrictions on the presence and use of heavy metals, brominated and chlorinated flame retardants, CFCs (freons) and chlorinated solvents, among other things.
- Page 28 Appendix Environmental Labelling of Personal Computers Flame retardants Environmental Flame retardants are present in printed circuit boards, cables, wires, casings and requirements housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are chemically related to another group of environmental toxins, PCBs.
