- Page 1 Colour Monitor USER GUIDE MANUAL DO PREPRIETÁRIO StudioWorks 775N...
- Page 2 - Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by LG Electronics Inc. for compliance could void the user's (or your) authority to operate the equipment. Only peripherals (digital input/output devices, terminals, printers, etc.) certified to comply with the Class B limits may be attached to this monitor.
- Page 3 This Class B digital apparatus meets all Canadian requirements of the Canadian Interference-Causing D.O.C. Equipment Regulations. Notice Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Products with the “CE” Marking comply with the Conformity EMC Directive(89/336/EEC) and LOW VOLTAGE Notice...
-
Page 4: Table Of Contents
Table of Contents Introduction ....................Features Monitor Registration Notice ......................Trademark Acknowledgments ..............Important Precautions ....................On Safety On Installation ....................A4 On Cleaning ....................A4 On Repacking ....................A4 Connecting the Monitor ................A5 Location and Function of Controls ....................Front View Rear View .......................A6 Control Panel Function Front Panel Controls ..................A7 OSD Button.....................A7... -
Page 5: Features
Introduction Thank you for purchasing a high resolution monitor. It will give you high resolution performance and convenient reliable operation in a variety of video operating modes. Features The monitor is a 17 inches (15.9 inches viewable ) intelligent, microprocessor based monitor compatible with most analog RGB (Red, Green, Blue) display standards, including IBM PC , PS/2 ®... -
Page 6: Monitor Registration
Serial No. Notice All rights reserved. Reproduction in any manner, in whole or in part, is strictly prohibited without the written permission of LG Electronics Inc. Trademark Acknowledgments LG is a trademark of LG Electronics Inc. IBM is a registered trademark and VGA is a trademark of International Business Machines Corporation. -
Page 7: Important Precautions
Important Precautions This unit has been engineered and manufactured to assure your personal safety, but improper use can result in potential electrical shock or fire hazard. In order not to defeat the safeguards incorporated in this monitor, observe the following basic rules for its installation, use, and servicing. -
Page 8: On Installation
Keep children from dropping or pushing objects into the monitor's cabinet openings. Some internal parts carry hazardous voltages. Do not add accessories that have not been designed for this monitor. During a lightning storm or when the monitor is to be left unattended for an extended period of time, unplug it from the wall outlet. -
Page 9: Connecting The Monitor
Connecting the Monitor On the back of the monitor are two plug-in connections; one for the AC power cord, and the other for the signal cable from the video card. Power off both the monitor and PC. Connect the 15 pin VGA connector of the supplied signal cable to the output VGA video connector on the PC and the matching input connector on the rear of the monitor. -
Page 10: Location And Function Of Controls
Location and Function of Controls Location and Function of Controls Front View Power Button Power Indicator OSD Button Digital Control Panel Rear View ID Label AC Power Socket D-Sub Signal Cable... -
Page 11: Control Panel Function Front Panel Controls
Control Panel Function Front Panel Controls SET Button Power Indicator Buttons Power Button OSD Button Control Function Use this button to enter or exit the on screen OSD Button display . Use these buttons to choose or adjust items in the on screen display. Buttons Use this button to enter a selection in the on SET Button... -
Page 12: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Making adjustments to the image size, position and operating parameters of the monitor are quick and easy with the On Screen Display Control system, using only the Enter button and Adjustment Control buttons. A quick example is given below to familiarize you with the use of the controls. -
Page 13: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selection and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the items that are shown on the Menu. OSD Adjust Description BRIGHTNESS CONTRAST... - Page 14 OSD Adjust Description Vertical Size SIZE To adjust image height. Horizontal Size To adjust image width. Side Pincushion To correct the bowing in and out of the SHAPE image. Side pincushion balance To correct the balance of both sides bowling. Trapezoid To correct geometric distortion.
- Page 15 OSD Adjust Description SPECIAL DEGAUSS To manually demagnetize the screen which may show some image or DEGAUSS color incorrectly. RECALL MOIRE H: 0/V: 0 54.4kHz/60.0Hz RECALL If the monitor is operating in a USER MODE factory preset mode, this control will reset the image to the factory preset mode.
-
Page 16: Video Memory Modes
Video Memory Modes The monitor has 36 memory locations for display modes, 11 of which are factory preset to popular video modes. Display Modes (Resolution) Display Modes Horizontal Vertical (Resolution) Frequency (kHz) Frequency (Hz) 640 x 400 31.47 VESA 640 x 480 31.47 VESA 640 x 480... -
Page 17: Energy Saving Design
Energy Saving Design This monitor complies with the EPA's Energy Star program, which is a program designed to have manufacturers of computer equipment build circuitry into their products to reduce power consumption during time of non-use. This monitor also goes into its energy saving mode if you exceed the monitor's operating limits, such as the maximum resolution of 1280x1024 or the frequency refresh rates of 30-70kHz horizontal or 50-160Hz vertical. -
Page 18: Low Radiation Compliance (Mpr Ii)
Low Radiation Compliance (MPR II) This monitor meets one of the strictest guidelines available today for low radiation emissions, offering the user extra shielding and an antistatic screen coating. These guidelines, set forth by a government agency in Sweden, limit the amount of emission allowed in the Extremely Low Frequency (ELF) and Very Low Frequency (VLF) electromagnetic range. -
Page 19: Troubleshooting
Troubleshooting Self diagnostics message. The signal cable is not connected. OUT OF FREQUENCY message appears. The frequency of the sync input is outside the operating range of the monitor. *Horizontal Frequency: 30-70kHz *Vertical Frequency: 50-160Hz Use the graphics board's utility software to change the frequency setting (Refer to the manual for graphics board). -
Page 20: Service
Service Unplug the monitor from the wall outlet and refer servicing to qualified service personnel when : The power cord or plug is damaged or frayed. Liquid has been spilled into the monitor. The monitor has been exposed to rain or water. The monitor does not operate normally following the operating instructions. -
Page 21: Specifications
: 10% to 90% non-condensing Storage condition Temperature : 0˚C to 60˚C Humidity : 5% to 90% non-condensing Information in this document is subject to change without notice and does not represent a commitment on the part of LG Electronics Inc.
