Replacement Parts List - Panasonic CW-C180BN Service Manual

REPLACEMENT PARTS LIST

REF.NO. DESCRIPTION & NAME
100 BASE PAN ASS'Y
101 BULKHEAD
102 AIR GUIDER-PROPELLER FAN
103 BRACKET-FAN MOTOR
106 TOP PLATE ASS'Y
108 COVER-EVAPORATOR
109 DRAIN TRAY-EVAPOPATOR
110 AIR GUIDER-B. WHEEL (BOTTOM)
111 AIR GUIDER-B. WHEEL (UPPER)
112 HOLDER-VENT. LEVER
113 VENTILATION LEVER
114 VENTILATION DOOR
116 CONNECTING BAR-A. SWING VANES
117 VANE-AIR SWING
118 GUIDER-A. SWING VANES
120 BLOWER WHEEL ASS'Y
121 PROPELLER FAN
122 NUT-P. FAN
123 CONTROL BOARD (AUX.)
124 HOLDER-CAPACITOR (COMP.)
125 CONTROL BOARD (MAIN)
126 HOLDER-CAPACITOR (FAN)
127 HOLDER-SENSOR
128 HOLDER-SENSOR
129 DRAIN PLUG-BASE PAN
130 CHASSIS LOCKING BRACKET
131 VENTILATION ASS'Y
135 AIR GUIDER-B. WHEEL
144 AIR GUIDER-B. WHEEL (FRONT)
145 RECTIFICATION PLATE
146 SPLASH WATER PROOF LOUVER
147 FUSE HOLDER
148 BOX FOR AIR-SWING MOTOR
200 COMPRESSOR
201 BUSHING-COMP. MOUNT.
202 NUT-COMP. MOUNT.
203 GASKET-TERMINAL COVER
205 TERMINAL COVER-COMP.
207 NUT-TERMINAL. COVER
210 CONDENSER
211 STRAINER
212 CAPILLARY TUBE
217 4-WAY VALVE
220 EVAPORATOR
300 FAN MOTOR
302 CAPACITOR-FAN
303 CAPACITOR-COMP.
304 MAIN CONTROL SWITCH
306 SWITCH-AIR SWING
308 THERMOSTAT ROOM
310 TERMINAL BOARD
310-1 TERMINAL BOARD
311 POWER SUPPLY CORD
312 AIR SWING MOTOR
322 SWITCH-LOW TEMP CUT
323 COIL-4 WAY VALVE
326 DEICER
329 FUSE
500 FRONT GRILLE COMPLETE
501 AIR FILTER
502 GRILLE DOOR ASS'Y
503 HINGE-G. DOOR
505 VANE
507 LINK-VANES
508 CONTROL ESCUTCHEON
509 KNOB-TURNING
600 CABINET COMPLETE
610 DRAIN PAN
613 SOUND PROOF-COMP.
702 SCREW-BRACKET FAN MOTOR
703 SCREW-BLOWER WHEEL
707 SCREW-F. GRILLE MOUNT.
710 SCREW-DRAIN PAN
711 SCREW-C. LOCKING BRACKET
712 SCREW-UNIT INSTALLATION
OPERATING INSTRUCTIONS
• The above parts are kept for seven years in accordance with MEI service policy.
However, longer lead time will be taken in supplying the non-numbered parts.
QTY CW-C180BN
1 CWD52K226A
1 CWD53K093
1 CWD31092
1 CWD54091
1 CWD64K036
1 ––
1 CWH40166
1 ––
1 ––
1 CWD91021
1 ––
1 ––
1 CWE26139
2 CWE24314
1 ––
1 CWH01K052
1 CWH00009
1 CWH56033
1 CWD60384
1 CWH30133
1 CWH10772
1 CWH30132
1 ––
1 CWH32085
1 CWH4611062
1 CWD93302
1 CWH22007
1 CWD32124
1 CWD32126
1 CWD21008
1 CWD91029A
1 XCSCW011
1 CWD66191
1 2JS350D6BA02
(B09567)
3 CWH50055
3 CWH4582065
1 CWH7070603
1 CWH7070206
1 CWH7080300
1 CWB32604
1 CWB11025
2 CWB15491 (2)
1 ––
1 CWB30C049
1 CWA95263
1 CWA31357
(3.5µF, 450VAC)
1 CWA31504
(35µF, 370VAC)
1 CWA07034
1 CWA05024
1 CWA15122
1 CWA4711013
1 ––
1 CWA20C538
1 CWA98K067
1 ––
1 ––
1 ––
1 XBA2C50TR0
1 CWE11C697
1 CWD00157D
1 CWE14K046
2 CWH61029E
14 CWE24301D
1 CWE26136
1 CWE311086
2 CWE17C076
1 CWE00C121
1 CWH40077
1 CWG30377
4 CWH55039
1 CWH4580326
1 CWH82C163
1 CWG86C733
1 XTT4+8B
1 CWG86C280
1 F561189
All parts are supplied from MAICO, Malaysia (Vendor Code : 061).
– 15 –
CW-A180BN CW-C240SN
CWD52K225A CWD52K183A
←
CWD53K087
←
CWD31K037
←
CWD54142
←
CWD64k029
–– CWD11030
←
––
–– CWD32099
–– CWD32098
←
CWD66156
–– CWH22004
–– CWH21012
←
CWE26092
←
CWC24210
–– CWE26106
←
CWH01K056
← ←
← ←
←
CWH10K337
CWH30102 CWH30101
CWH10899 CWH10666
←
––
–– ––
CWH32086 CWH4690379
–– CWH4611062
← ←
←
––
←
––
CWD32126 (A) ––
←
––
–– ––
–– XCSCW011
←
––
2JS356D6DA01 2JS442D4AA01
(CWB09525) (B09374)
← ←
← ←
←
––
← ←
← ←
CWB32484 CWB32C073
← ←
CWB15363 CWB15315 (1)
CWB00003 ––
←
CWB30C004
←
CWA92125
←
CWA31244
(3µF, 400VAC)
←
CWA31506
(45µF, 370VAC)
CWA07040 CWA07034
← ←
CWA15123 CWA15122
CWA4711060 CWA4711013
–– ––
CWA20C643 CWA20C539
←
CWA98K046
–– CWA15005
CWA43C365 ––
CWA17004 ––
CWA16C158 XBA2C50TRO
← ←
← ←
← ←
← ←
← ←
← ←
CWE311085 CWE311073
← ←
CWE00C124 CWE00C120
← ←
–– CWG30377
← ←
← ←
← ←
← ←
← ←
← ←
← ←
CW-C180BN
CW-A240SN
CWD52K193A
CWD53K083
CWD31075
←
←
←
––
←
←
←
←
←
←
←
←
←
←
←
←
←
CWH10666
––
CWH32048
←
––
←
––
––
––
––
––
←
––
←
←
←
––
←
←
CWB32C095
←
CWB15589 (2)
CWB00003
CWB30C015
←
←
←
CWA07043
←
CWA15123
←
CWA4711022
CWA20C481
←
←
CWA43C356
CWA17004
←
←
←
←
←
CWE24301D
←
CWE311113
←
←
←
––
←
←
←
←
←
←
←
