  • Page 1 Owner’s Guide NV29...

  • Page 2: Table Of Contents

    Thank you for purchasing the Infinity Upright Vacuum. TOLL FREE: 1-888-668-9600 Contents Important Safety Instructions Getting Started Using the Vacuum Transporting the Vacuum Cleaning with the Vacuum Accessories Emptying the Dust Cup Assembly Proper Care of Your Infinity Upright Vacuum Troubleshooting Checking for Blockages Maintenance...

  • Page 3: Important Safety Instructions

    DO NOT place vacuum on unstable surfaces such as chairs or tables. DO NOT allow young children to operate the vacuum or use as a toy. DO NOT use vacuum cleaner if it has been dropped, damaged, left outdoors, or submerged in water. Return to EURO-PRO Operating LLC for examination, repair,...
  • Page 4 flammable dust or other explosive or toxic materials. DO NOT vacuum up any liquids. DO NOT immerse vacuum cleaner in water or other liquids. DO NOT use outdoors or on wet surfaces; use only on dry surfaces. Use extra care when cleaning on stairs.

  • Page 5: Getting Started

    Getting Started Along with your upright unit, you will find the following components: Detachable Handle (Ergonomic Grip) Telescopic Wand Cleaning Attachments Upper Hose Holder Extra Filters Super Stretch Hose Spare Motor Belt *Note: depending on the model you select, your Infinity comes with a Pet Hair Power Brush (h) and Low Reach Bare Floor Brush (i) that are kept in a separate accessory bag.
  • Page 6 Attach each end of the Super Stretch Hose to the vacuum and press into Upper Hose Holder for easy storage. IMPORTANT: To prevent vacuum from tipping, secure hose in lower holder. Store Crevice Tool and Upholstery/ Dusting Brush on the unit. When storing your vacuum, wind cord around the two cord holders and secure with cord clip:...

  • Page 7: Using The Vacuum

    Using the Vacuum Your Infinity Upright Vacuum is a versatile tool that can be used to clean bare floor surfaces or carpets – with the click of a button. Lock vacuum into the upright position. Plug in the vacuum. Bare Floors Carpets Set the Height Adjustment Dial.

  • Page 8: Transporting The Vacuum

    Step on Power Button to turn unit on and off. Push to vacuum. Note: If vacuum is difficult to push, adjust the Height Adjustment Dial until vacuum glides easily over the carpet surface. Transporting the Vacuum Lock vacuum into the upright position. Unplug the vacuum.

  • Page 9: Cleaning With The Vacuum Accessories

    Change the Brush Roll Pedal to the bare floors/ tools position. DO NOT pull vacuum cleaner around by the hose. DO NOT overextend the hose beyond its 17-foot reach. Vacuum Accessories Your vacuum comes a Detachable Handle and Telescopic Wand.
  • Page 10 Using the Telescopic Wand: Lock vacuum into upright position. Press the Telescopic Wand release button (b). Hold Telescopic Wand and pull out of unit. Push the selected cleaning tool onto the end of the wand. Press the Telescopic Height Adjustment Button (c) to adjust wand to desired length.

  • Page 11: Emptying The Dust Cup Assembly

    Emptying the Dust Cup Assembly For best results empty the Dust Cup Assembly after each use; empty several times during prolonged usage. Or empty the Dust Cup Assembly when it reaches the MAX fill line; NEVER OVER-FILL THE DUST CUP. Lock vacuum into upright position.

  • Page 12: Proper Care Of Your Infinity Upright Vacuum

    Proper Care of Your Infinity Upright Vacuum For proper care, consult the table to the right for the maintenance schedule of your Cyclonic Chamber and Filters. Lock vacuum into upright position. Turn vacuum off. CAUTION: Unplug the vacuum; failure to do so might result in electric shock.

  • Page 13: Troubleshooting

    Troubleshooting WARNING: to reduce the risk of electric shock, the power cord must be disconnected before performing maintenance/troubleshooting checks. Problem Vacuum will not run. Vacuum is not picking up dirt. Vacuum pushes scatter rugs (lightweight, movable rugs) on carpets setting. Vacuum too hard to push on carpets setting.

  • Page 14: Checking For Blockages

    Checking for Blockages Blockages may cause your vacuum to overheat and shut down. If so, clear the blockages, then follow the instructions for Resetting the Motor Thermostat on page 14. WARNING: Never insert sharp objects into any opening to clear an obstruction.

  • Page 15: Maintenance

    Maintenance Changing the Headlight Bulb You will need to order replacement bulbs from: www.infinityvac.com or contact Customer Service at: 1-888-668-9600. Turn power off. Unplug the vacuum. Unlock vacuum and lay flat. Insert a Flathead screwdriver into one of the two top slots of the Headlight Cover; gently pry off cover from slots.
  • Page 16 To replace new Belt: Slide one end of the new Belt over the motor-driven shaft (e). Slide second end of the Belt around Brush Roll (f). Partially insert the right end of the roller into one side holder (g). Partially insert the left end into the other side holder (h).

  • Page 17: Warranty And Registration

    Warranty and Registration Your Infinity Upright Vacuum comes with a Five year limited warranty. FOR CANADIAN CONSUMERS ONLY Please fill out and mail the Owner Registration Card within ten (10) days of purchase. The registration will enable us to contact you in the unlikely event of a product safety notification.

  • Page 18: Owner Registration Card

    Mail to the following address: • Canada: EURO-PRO Operating LLC 4400 Bois Franc, St. Laurent, Québec H4S 1A7 Owners Name: Address: City: Date Purchased: Name of Store: Vacuum Model: NV29 Prov.: Postal Code:...
  • Page 19 U.S.: EURO-PRO Operating LLC 94 Main Mill Street, Door 16, Plattsburgh, NY 12901 Canada: EURO-PRO Operating LLC 4400 Bois Franc St. Laurent, Québec H4S 1A7 1-888-668-9600 www.infinityvac.com COPYRIGHT© EURO-PRO OPERATING LLC 2007 PRINTED IN CHINA REV. 071201ENG...
