Volume Down - Polycom EFIR11 Instruction Manual

3.) V D
OLUME OWN
This is a user defined button that executes Macro 53 on all Vortexes. The reason that
the button is user defined is that different rooms will use different outputs that are sent
to the amplifier.
Here is an example of how to create a Volume Down Macro for Output A. For this
example, we will attenuate the output by 2 dB each time the Volume Down button is
pushed. First, go to the Macros page of Conference Composer and scroll down until
you see M 53. Now, right click your mouse under the C column. Select
ACRO OMMAND
I C , O , A, G , -, 2 B:
NSERT OMMAND UTPUT AIN D
You should see this when you are finished:
If you want to lower the gain on multiple outputs, just add another command to Macro
53. In this example, let's lower Output B also by 2 dB each time the Volume Down
button is pushed. Right click your mouse in the row for Macro 53 and select I
NSERT
C , O , B, G , -, 2 B:
OMMAND UTPUT AIN D
7
