  • Page 3 +33 3 90 20 74 40 Suunto Web Site www.suunto.com Congratulations on the purchase of your Suunto Observer. The Observer is designed to provide you with the most accurate information during your enjoyment of any outdoor activity you are engaged in.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS CHAPTER 1 INTRODUCTION ..............5 1.1 General Information ..................... 5 1.2 Care and Maintenance ..................5 1.3 Adjusting the Bracelet (St and Tt models) ............6 1.4 Main Functions (Modes) ..................7 1.5 Backlight Features ....................7 1.6 Water Resistance ....................
  • Page 5 CHAPTER 3 ALTIMETER MODE .............. 17 3.1 Altimeter-Barometer Use ................... 17 3.2 Setting the Altimeter ................... 18 3.3 Logbook Sub Mode .................... 20 3.3.1 Starting and Stopping a Logbook Recording ..........20 3.3.2 To View in the Logbook Mode ..............21 3.4 Fast Cumulative Feature ..................

  • Page 6: Figure

    Figure 1.1 SELECT MODE PRESSURE SENSOR ON / OFF QUICK - Altitude Alarm Indicator - Daily Alarm Indicator - Mode Indicator - AM/PM Indicator (12h display) - Low Battery Indicator - Use Indicator - Chronometer Indicator...

  • Page 7: Chapter 1 Introduction

    Protect your Observer from shocks, extreme heat and prolonged exposure to direct sunlight. If not in use, your Observer should be stored in a clean, dry environment at room temperature. The Observer can be wiped clean with a lightly moistened (warm water) cloth. Applying a mild soap to the area can clean stubborn stains or marks.

  • Page 8: Adjusting The Bracelet (St And Tt Models)

    1.3 ADJUSTING THE BRACELET (ST AND TT MODELS) The metal / elastomer bracelets of the Observer models St and Tt have to be adjusted for the user. The steps are 1. Remove the buckle by releasing the spring bars with pin, paper clip or other sharp object.

  • Page 9: Main Functions (Modes)

    10 seconds from the last pressing. 1.6 WATER RESISTANCE The Observer is water resistant up to 100m/330ft. However, it is not a diving instrument and therefore the buttons should not be operated (put in use) while underwater.
  • Page 10 The ON OFF Button Located on the bottom right of the Observer performs the following functions: • In the TIME Mode, the bottom field view can be scrolled displaying the calendar date, seconds, or dual time. • During the setup process, a short press causes the selected value to increase.

  • Page 11: Lcd Display

    The middle field displays large numbers and/or the related unit of measure of a function. c) The bottom field displays either numbers and/or text. d) The Mode Indictor Bar displays the main modes of the Observer. The half oblong shape located just below the bar indicates the mode you are viewing.

  • Page 12: To Set Or Check Unit Of Measurement Settings

    In the calibration setting mode, scroll the barometric pressure value up or down until text “dEF” appears. This is the factory setting. Then exit by pressing [MODE]. 1.11 BATTERY REPLACEMENT The Observer operates on a three-volt lithium cell Type: CR 2032. The maximum life expectancy is approximately 12 months.
  • Page 13 To replace the battery: 1. On the backside of the Observer, insert a coin into the slot located on the battery compartment cover. 2. Turn the coin counterclockwise until it is aligned with the open position marker, or even slightly further for easy opening.

  • Page 14: Chapter 2 Time Mode

    After every battery replacement, it is necessary to calibrate the magnetic sensor. Refer to Chapter 5, Calibrating the Compass. CHAPTER 2 TIME MODE There are three time sub modes: time, chronometer and alarms. NOTE: These functions are accessible in the TIME mode, i.e. when the mode indictor is below TIME.

  • Page 15: Chronometer Sub Mode

    Once you determine the year, month and day, the Observer will supply the day of the week in the top field. Setup mode will automatically be released if left idle for more than one minute.

  • Page 16: To View The Chronometer Memory

    2. Press the [QUICK] button to store the lap time and split time into memory. Lap and split times are displayed as follows: In the top field the lap time is shown for the latest lap. The number of this lap is shown in the bottom field “L #”...

  • Page 17: Figure

    c) The date of the timed event; d) The stopwatch icon; and e) The text “MEM” to indicate the memory view. You press the [ON OFF] button to move to the next screen. The second screen (Fig. 2.4) displays: a) The total number of laps stored in the middle field; and b) The text “MEM and “LAP”...

  • Page 18: Daily Alarm Sub Mode

    2.3 DAILY ALARM SUB MODE The Observer allows you to select and enter settings for up to three alarms. In the TIME mode, press the [SELECT] button twice to enter this sub mode. (After stopwatch) In the Daily Alarm mode (Fig. 2.7): a) “ON”...

  • Page 19: Chapter 3 Altimeter Mode

    1000 ft) 3.1 ALTIMETER-BAROMETER USE The Observer can be used as either a weather station or altimeter. This operating feature is chosen in the setup process while in the altimeter or the barometer mode. To toggle between these icon positions, hold the [Select]-button in for 2 seconds and then, press the [Quick] or [On Off]-button to lock in one of the functions.

  • Page 20: Setting The Altimeter

    The position of the icon indicates whether the Observer is being used as a weather station (BARO) or altimeter (ALTI). NOTE: This is different than moving between ALTI and BARO main modes. THIS IS IMPORTANT. The use indicator has to be in ALTI position, otherwise the altitude display is fixed.
  • Page 21 provided in the section below. If the Altitude is not known, you can set the sea level pressure in the Barometric mode. Refer to Chapter 4, Setting the Sea Level Pressure. Setting the Sea Level Pressure will adjust the altimeter to the current altitude within approximately ten meters or 30 ft.

  • Page 22: Logbook Sub Mode

    NOTE: You can return to main ALTI display by pressing [MODE] during any of the steps 1-9. Once you have set the reference altitude of the current location to the known altitude, the Observer will also correct the sea level pressure, and therefore, it will not be necessary for this function to be set.

  • Page 23: To View In The Logbook Mode

    Observer will display the text “LOG” flashing in the bottom field. 3.3.2 To View in the Logbook Mode In the Altimeter mode, press the [SELECT] button once to enter this sub mode. The logbook mode features five screens. The first screen displays for 7 seconds. Thereafter, the screens will increment (2-5) displaying at four-second intervals.

  • Page 24: Fast Cumulative Feature

    The third screen shows the number of laps (runs) accomplished during the current log- book. After the third display is shown, the Observer automatically returns to the main mode in which you were viewing. NOTE: During this process, pressing the [QUICK] button allows you to move on to the next...

  • Page 25: Logbook History Sub Mode

    3.5 LOGBOOK HISTORY SUB MODE The Logbook history shows a summation of all logs recorded. In the Altimeter mode, press the [SELECT] button twice to enter this sub mode. There are four screens displayed in the logbook history. In the first screen (Fig. 3.7): •...

  • Page 26: Clearing The Logbook History

    3.6 EFFECT OF AIR TEMPERATURE ON ALTITUDE MEASUREMENT The atmospheric pressure means the weight of air mass above the observer: at a higher altitude there is less air than at a lower altitude. The principle of an altimeter is to measure the different air pressure between different altitudes.
  • Page 27 Table 1. Normal temperatures corresponding to different altitudes Altitude (m) Altitude (ft) Temperature (ºC) Temperature (ºF) above sea level above sea level 15.0 59.0 13.7 56.7 1312 12.4 54.3 1969 11.1 52.0 2625 49.6 1000 3281 47.3 1200 3937 45.0 1400 4593 42.6...
  • Page 28 The reference altitude is set at 3280 feet. At 9840 feet the altitude difference is 6560 feet and Observer shows 100 feet too much (-14 ºF * 6560 ft * 0.0011/ºF = -100 ft). Your actual altitude is thus 9740 ft.

  • Page 29: Chapter 4 Barometer Mode

    An Altimeter-Barometer use feature. Refer to Chapter 3, Altimeter-Barometer Use for more information. NOTE: To acquire true temperature reading, take the Observer away from wrist and allow it to adjust to the ambient temperature for 15 minutes. To view and use the Barometric function:...

  • Page 30: Setting The Sea Level Pressure

    Press the [MODE] button until the mode indicator is directly below BARO. In the Barometric mode the fields display information as shown in Fig. 4.1: a) The top field displays the current temperature and barometric trend indicator; b) The middle field displays sea level pressure; c) The bottom field displays either the current time or the current absolute atmospheric pressure.

  • Page 31: 4-Day Memory Sub Mode

    5. When the current sea level pressure is displayed, press the [MODE] button to accept the changes and exit. Once you complete this process, the altitude measurement on the Observer should be correct within a range of approximately ten meters or some tens of feet.

  • Page 32: Barometric Trend Indicator

    A bearing tracking mode that’s used to indicate desired direction and actual bearing. • A declination correction feature; and IMPORTANT NOTE: To reach as accurate compass readings as possible, keep the Observer in a level position. In the compass mode, the fields display the following data as shown in Fig. 5.1:...

  • Page 33: Bearing Tracking Sub Mode

    b) The middle field displays bearing in degrees; c) The bottom field displays current time; and d) The outer circumference of the LCD graphically displays lit segments representing a North-South arrow; (one-lit segment indicates North, three-lit segments indicate South) To view and use the Compass function: Press the [MODE] button until the mode indicator is directly below COMP.

  • Page 34: Declination Adjustment Sub Mode

    1. Press the [SELECT] button for 2 seconds to start the setup process. Located in the mid- dle field, the actual bearing in degrees will begin to flash. 2. Turn the Observer to the desired direction. Lock the bearing displayed by pressing the [QUICK] button.

  • Page 35: Calibrating The Compass

    NOTE: For successful calibration, it is important to hold the Observer level during the calibration process. This is simple to accomplish. For example, place the Observer on an over-turned drinking glass on a table. 5. Within a minute of completing a full circle, the Observer will inform you whether the cali-...

  • Page 36: Chapter 6 Frequently Asked Questions

    Why is the altitude reading not changing even though I’m moving in a vertical direction? You are using the Observer as a barometer and the altitude is fixed. To change to the altimeter use, enter settings in the BARO or ALTI mode. The first thing that you can set is the choice...
  • Page 37 Observer do. Because the Observer measures ascent and descent based on changes in air pressure, it interprets these changes as vertical movement.
  • Page 38 - it will in either case give you the proper altitude reading providing the weather conditions have not changed. All Suunto Observers are temperature compensated within the range -5 to 140 ° F / - 20 to +60 ° C. Refer to Chapter 3, Effect of Air Temperature on Altitude Measurement.
  • Page 39 A natural way to alternate between Altimeter/Barometer Use during a hike is to use the Observer as altimeter when moving and as barometer when camping (no vertical movement expected). This way you will have more accurate information on both altitude and weather.

  • Page 40: Copyright And Trademark Notice

    LIMITS OF LIABILITY AND ISO 9001 COMPLIANCE If this product should fail due to defects in materials or workmanship, Suunto Oy will, at its sole option, repair or replace it with new or rebuilt parts, free of charge, for two (2) years from...
  • Page 41 Suunto Oy, Suunto Europe and Suunto USA/Canada shall in no event be liable for any incidental or consequential damages arising from the use of or inability to use the product. Suunto Oy does not assume any responsibility for losses or claims by third parties that may arise through the use of this device.
