- Page 1 Series 1580 Intercom Systems THE COMPLETE 1-ON-2 SOLUTION Installer’s Reference Guide...
- Page 2 • Clean the unit only with a dry or slightly dampened soft cloth. LIABILITY STATEMENT Every effort has been made to ensure that this product is free of defects. Audio Authority cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use.
-
Page 3: Table Of Contents
Lane Station with microphones, speakers, etc. Provides a complete 1-on-1 or 1-on-2 audio solution for drive-up and other customer service applications. Audio Installation The 1580 Series is not expandable beyond 1-on-2, and cannot be used with Customer Station Setup Series 1500 Counter Stations, Lane Stations or Hubs. - Page 4 SPEAKER SPEAKER CABLE DETAIL between them. CALL BUTTON CALL BUTTON COUNTER HANDSET HANDSET POWER STATION SUPPLY MODEL 1580H CAT 3 CABLE SHIELDED- LANE STATION PAIRED CABLE MODEL 1583 Audio Authority Series 1580 Installer’s Reference Guide ®...
-
Page 5: Wiring Notes
TRAFFIC SENSE AND LEVEL TRAFFIC SENSOR BLOWER CONTROL (MODEL1547) SHIELD SEE PAGE 8 FOR DETAILS CAT 5 CABLE CUSTOMER DRIVE-UP END CONNECTS TO 1580 COUNTER STATION - MAY BE UP TO 50 FT. Audio Authority Series 1580 Installer’s Reference Guide ®... -
Page 6: Video Installation
* The 5-amp 571-020 power supply is included CAT 5/6 UTP with 1585 units that SHIELDED TWISTED PAIR (AUDIO CABLE) have a heater installed. CAT 3 CABLE (HANDSET CABLE) SHIELDED TWISTED PAIR (AUDIO CABLE) Audio Authority Series 1580 Installer’s Reference Guide ®... - Page 7 CALL TRAFFIC BLOW COMMON N.O. Lane Station. STATION MICROPHONE SPEAKER SENSE MUTE CONTACTS Figure 9. Terminal block inside 1585 for connecting 1583 shielded cable devices. Video display, camera and handset are wired separately. Audio Authority Series 1580 Installer’s Reference Guide ®...
-
Page 8: Program Audio/Video
Using Model 1547 Traffic Sensors PROGRAM AUDIO The 1583 Dual Lane Station provides a connection for Audio Authority’s Model 1547 traffic sensors. One or two 1547 sensors may be connected to the 1583 flash LANE STATION LANE STATION port, located on the end panel, via the 1549 adapter as shown. -
Page 9: Calibration & Testing
3M Scotchbrite™ material in the microphone opening. 1580 COUNTER The Audio Authority lane microphone has a special ® STATION (UNDERSIDE) foam surround; for optimum results, use Audio Authority microphones (631-029) and speakers (631-030). Audio Authority Series 1580 Installer’s Reference Guide ®... -
Page 10: Operation
Operation Figure 12. Counter The 1580 Series Intercom is operated via Station Keypad. touch-sensitive keys on the Counter Station keypad, shown below. Tasks such as answering a customer call, ending a call, and putting a customer on HOLD are shown on the Operator Guide (page 11) which should be kept near the Counter Station for reference. -
Page 11: Operator Guide
OPERATOR GUIDE Audio Authority Series 1580 Counter Station Operation Tips Green Lane Key Lights • Speak naturally into the microphone at a Flashing (Rapidly) = Customer calling distance of about two inches On = Customer in 2-way contact • Touch keys with the pad of your finger Blinking (Slowly) = Customer placed on HOLD •... -
Page 12: Advanced Setup
Select SINGLE LANE, or AUTO-SELECT 1 LANE leaving the submenu. and touch SETUP. Select the desired lane, and touch SETUP to make adjustments to that lane. Touch PRIVACY to save and exit. Audio Authority Series 1580 Installer’s Reference Guide ®... -
Page 13: 1550 Field Setup Display
Touch any lane key to assign selected lane to that key Exit Setup a. Hold SETUP for one second to jump to EXIT menu at any time b. Select 2: EXIT AND SAVE c. Touch SETUP to exit Audio Authority Series 1580 Installer’s Reference Guide ®... - Page 14 First select the lane number to be assigned using the VOLUME keys. Then touch the key to be assigned to that lane. FIRMWARE UPGRADE This menu is used to update the firmware of system components. Call Audio Authority Technical Support for details. Audio Authority Series 1580 Installer’s Reference Guide...
-
Page 15: Appendix
TEST all cables 5 WHITE / BLUE (including pre-made) with a network 6 GREEN cable tester. 7 WHITE / BROWN 8 BROWN CABLES ARE WIRED THE SAME ON BOTH ENDS (NOT CROSSED OVER). Audio Authority Series 1580 Installer’s Reference Guide ®... - Page 16 2048 Mercer Road, Lexington, Kentucky 40511-1071 USA Phone: 859-233-4599 • Fax: 859-233-4510 Customer Toll-Free USA & Canada: 800-322-8346 www.audioauthority.com • support@audioauthority.com 752-593 6/10...
