- Page 1 REPAIR PARTS MANUAL MODEL NO. MC11T94 (96011001501) Lawn Tractor McCulloch www.electrolux.com/mcculloch 532 19 69-98 1.12.05 RD PRINTED IN U.S.A.
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “Tractor” • Model Number - “MC11T94 (96011001501)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 SCHEMATIC BLACK BATTERY FUSE STARTER AMMETER (OPTIONAL) BLACK WHITE SOLENOID CLUTCH / BRAKE (PEDAL UP) WHITE SEAT SWITCH IGNITION (NOT OCCUPIED) SWITCH WHITE BLACK BLACK BLACK BLACK ATT'MENT CLUTCH... -
Page 4: Electrical
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 ELECTRICAL... -
Page 5: Electrical
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 ELECTRICAL PART DESCRIPTION 532 16 34-65 Battery 12 Volt 25 Amp 874 76 04-12 Bolt Hex Hd 1/4-20 Unc x 3/4 532 17 66-89 Battery Box 532 17 61-38 Switch Interlock Push-In 532 12 47-80 Cable Battery 6 Ga. -
Page 6: Chassis
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 CHASSIS AND ENCLOSURES Chassis-Alpha_LT_3... - Page 7 REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 CHASSIS AND ENCLOSURES PART DESCRIPTION 532 17 46-20 Chassis 532 17 65-54 Drawbar 532 15 52-72 Bumper, Hood/Dash 532 18 25-34 Saddle 532 15 51-38 Clip Retainer Slide-On...
-
Page 8: Drive
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 DRIVE drive-saddle_31... -
Page 9: Drive
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 DRIVE PART PART DESCRIPTION DESCRIPTION - - - - - - - - - Transaxle, Peerless 205-544C 532 12 32-05 Retainer Belt Style Spring (Order parts from transaxle manu- 872 11 06-12 Bolt Carr Sh 3/8-16 x 1-1/2 Gr. -
Page 10: Steering
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 STEERING steering_pl.lt_58... - Page 11 REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 STEERING PART DESCRIPTION 532 18 67-80 Wheel Steering 532 17 51-31 Axle Asm 532 16 98-40 Spindle Asm LH 532 16 98-39 Spindle Asm RH 532 12 49-31 Bearing Race Thrust Harden 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
-
Page 12: Engine
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-bs.1cyl_38... -
Page 13: Engine
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 ENGINE PART DESCRIPTION 532 17 05-51 Control Throttle /Choke 817 72 04-08 Screw Hex Thd Cut 1/4-20 x 5/8 T - - - - - - - -... -
Page 14: Seat
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 SEAT seat_lt.bolt_1 PART PART DESCRIPTION DESCRIPTION 532 17 53-89 Seat 872 05 04-12 Bolt Rdhd Sht Nk 1/4 - 20 x 1 -1/2 532 14 05-51 Bracket Seat Pivot 532 13 43-00 Spacer Split .28 x .96... -
Page 15: Decals
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 DECALS PART PART DESCRIPTION DESCRIPTION 532 18 58-81 Decal, Steering Wheel 532 18 21-66 Decal, Cut Finger 532 15 97-37 Decal, Brake/Clutch 532 18 90-24 Decal, Hood RH/LH 532 15 97-36 Decal, Hot Muffl... -
Page 16: Mower Deck
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 MOWER DECK 38_deck-manual_2... -
Page 17: Mower Deck
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 17 02-80 Mower Housing Assembly 532 17 85-15 Washer, Hardened 532 13 38-40 Idler Arm Assembly 872 14 05-06 Bolt Carriage 5/16-18 x 3/4 532 16 57-23 Spacer, Retainer 532 13 80-17 Bracket Asm Fr. -
Page 18: Mower Lift
REPAIR PARTS TRACTOR - - MODEL NUMBER MC11T94 (96011001501), PRODUCT NO. 960 11 00-15 MOWER LIFT 17 18 20 lift-rh.1piece_3 PART PART DESCRIPTION DESCRIPTION 532 17 32-88 Link Front 532 15 94-60 Wire Asm Inner/Sprg w/plunger 532 15 94-71 Shaft Asm Lift RH... - Page 19 SERVICE POLICY ® ® WARRANTY Issued January 1980 LIMITED WARRANTIES Revised January 1991 NEW PEERLESS GEAR POWER TRAIN COMPONENTS A. Products Warranted Peerless Gear and Machine Division of Tecumseh Products Company (“Tecumseh”), subject to the limitations contained below, will, at its option, repair or replace, without charge for parts or labor only, any part of a new Power Train Component (which as used herein means and includes the transaxle, gear box, trans mis sion, differential and right angle drives, and any part of the Power Train Component), EXCEPT any new Power Train Component incorporated in equipment used for commercial or rental pur pos es, which is found upon examination by any Tecumseh Au tho rized Service Outlet or by Tecumseh’s factory in Grafton, Wis con sin, to be DEFECTIVE...
- Page 20 McCulloch www.electrolux.com/mcculloch...
