- Page 1 REPAIR PARTS MANUAL MODEL NO. MC13538LT (96012010300) Lawn Tractor www.mcculloch.biz 532 43 25-89...
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “Tractor” • Model Number - “MC13538LT (96012010300)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 SCHEMATIC SCH03 BATTERY STARTER FUSE AMMETER (OPTIONAL) WHITE CLUTCH / BRAKE ATTACHMENT CLUTCH (PEDAL UP) (CLUTCH OFF) BLACK BLACK SEAT SWITCH (NOT OCCUPIED) BLACK BLACK GRAY GRAY REVERSE SWITCH... -
Page 4: Electrical
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 ELECTRICAL... - Page 5 TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 ELECTRICAL PART DESCRIPTION 532 16 34-65 Battery 12 Volt 25 Amp 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 17 66-89 Battery Box 532 17 61-38 Switch Interlock Push-In 532 17 56-88 Harness Asm.
- Page 6 TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 CHASSIS AND ENCLOSURES...
-
Page 7: Chassis
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 CHASSIS AND ENCLOSURES PART DESCRIPTION 532 17 46-19 Chassis 532 17 65-54 Drawbar 532 15 52-72 Bumper, Hood/Dash 532 43 33-53 Dash 872 14 06-08 Bolt, Carriage 3/8-16 x 1... -
Page 8: Drive
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 DRIVE drive-stlt_Peerless_fender_13_r1... -
Page 9: Drive
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 DRIVE PART PART DESCRIPTION DESCRIPTION - - - - - - - - - Transaxle Peerless 205-545C 532 17 39-37 Bolt Hex 532 14 66-82 Spring Return Brake T/a Zinc 810 04 07-00 Washer Lock Hvy Hlcl Spr 7/16 532 12 36-66 Pulley Transaxle 18"... -
Page 10: Steering
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 STEERING steering_pl.lt_68_r2... - Page 11 TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 STEERING PART DESCRIPTION 532 42 45-43 Wheel Steering 532 41 81-68 Axle Asm 532 16 98-40 Spindle Asm LH 532 16 98-39 Spindle Asm RH 532 12 49-31 Bearing Race Thrust Harden 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
-
Page 12: Engine
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-stlt_bs_16... - Page 13 TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 ENGINE PART DESCRIPTION 532 17 05-51 Control Throttle /Choke 817 72 04-08 Screw Hex Thd Cut 1/4-20 x 5/8 T - - - - - - - - Engine Briggs &...
-
Page 14: Mower Deck
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 MOWER DECK 38-7_deck-manual_22... - Page 15 TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 19 25-56 Mower Housing Assembly 532 19 32-16 Spring Brake Return 872 14 05-06 Bolt Carriage 5/16-18 x 3/4 819 13 13-11 Washer 13/32 x 13/16 x 11 Ga.
-
Page 16: Mower Lift
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 MOWER LIFT 16 17 lift-rh.1piece_27 PART PART DESCRIPTION DESCRIPTION 532 40 49-81 Plunger Asm. Lift Lever 532 17 32-88 Link Front 873 35 08-00 Nut Jam Hex 1/2-13 unc... -
Page 17: Seat
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 SEAT seat-stlt_knob_1 PART PART DESCRIPTION DESCRIPTION 532 42 40-35 Seat 532 12 12-48 Bushing Snap Blk Nyl 532 14 05-51 Bracket Seat Pivot 872 05 04-12 Bolt Rdhd Sht Nk 1/4 - 20 x 1 -1/2 871 11 06-16 Bolt Hex 3/8 - 16 x 1 532 13 43-00 Spacer Split .28 x .96... -
Page 18: Decals
TRACTOR - - MODEL NUMBER MC13538LT (96012010300), PRODUCT NO. 960 12 01-03 DECALS PART PART DESCRIPTION DESCRIPTION 532 40 51-21 Decal Replacement 532 40 82-53 Decal, Hood LH 532 40 88-10 Decal, Eng. HP 532 43 26-57 Decal, Side Panel 532 41 16-58 Decal, Warning 532 13 83-11 Decal, Handle Lft Height Adj. - Page 19 SERVICE NOTES...
- Page 20 12.02.09 BAD Printed in the U.S.A.
