- Page 1 REPAIR PARTS MANUAL MODEL NO. MC19542LT (96012011400) Lawn Tractor www.mcculloch.biz 532 44 05-84...
-
Page 2: Table Of Contents
Each tractor has its own model number. The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “Tractor” • Model Number - “MC19542LT (96012011400)” • Part Number • Part DESCRIPTION TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 SCHEMATIC SCH03 BATTERY STARTER FUSE AMMETER (OPTIONAL) WHITE CLUTCH / BRAKE ATTACHMENT CLUTCH (PEDAL UP) (CLUTCH OFF) BLACK BLACK SEAT SWITCH (NOT OCCUPIED) BLACK BLACK GRAY GRAY REVERSE SWITCH... -
Page 4: Electrical
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 ELECTRICAL... - Page 5 TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 ELECTRICAL PART DESCRIPTION 532 16 34-65 Battery 12 Volt 25 Amp 874 76 04-12 Bolt Hex Hd 1/4-20 Unc x 3/4 532 17 66-89 Battery Box 532 17 61-38...
-
Page 6: Chassis
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 CHASSIS AND ENCLOSURES Chassis-stlt_Alpha_18... -
Page 7: Chassis
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 CHASSIS AND ENCLOSURES PART DESCRIPTION 532 17 46-19 Chassis 532 17 65-54 Drawbar 532 15 52-72 Bumper, Hood/Dash 532 43 33-53 Dash 872 14 06-08 Bolt, Carriage 3/8-16 x 1... -
Page 8: Drive
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 DRIVE drive-stlt_Peerless_fender_13_r1... -
Page 9: Drive
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 DRIVE PART PART DESCRIPTION DESCRIPTION 532 17 54-10 Engine Pulley - - - - - - - - - Transaxle Peerless 206-545C 532 17 39-37 Bolt Hex 532 14 66-82... -
Page 10: Engine
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-stlt_bs_19... -
Page 11: Engine
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 ENGINE PART DESCRIPTION 532 17 05-51 Control Throttle /Choke 817 72 04-08 Screw Hex Thd Cut 1/4-20 x 5/8 T - - - - - - - -... -
Page 12: Steering
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 STEERING Steering-stlt_OPP_1... - Page 13 TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 STEERING PART DESCRIPTION 532 42 45-43 Wheel Steering 532 41 81-68 Axle Asm 532 16 98-40 Spindle Asm LH 532 16 98-39 Spindle Asm RH 532 12 49-31...
-
Page 14: Decals
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 DECALS PART PART DESCRIPTION DESCRIPTION 532 42 95-55 Decal, Engine HP 532 17 05-63 Decal, Deflect WRN 532 43 79-66 Decal, Steering Wheel 532 44 06-28 Decal, Side Panel... -
Page 15: Seat
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 SEAT seat-stlt_knob_1 PART PART DESCRIPTION DESCRIPTION 532 18 87-13 Seat 872 05 04-12 Bolt Rdhd Sht Nk 1/4 - 20 x 1 -1/2 532 14 05-51 Bracket Seat Pivot 532 13 43-00 Spacer Split .28 x .96... -
Page 16: Mower Deck
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 MOWER DECK... -
Page 17: Mower Deck
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 MOWER DECK PART PART DESCRIPTION DESCRIPTION 532 16 58-92 Mower Deck Assembly, 42" 532 13 39-44 Washer, Hardened 872 14 05-06 Bolt 532 13 98-88 Bolt, Shoulder 5/16-18 unc 532 13 80-17 Bracket Asm Fr. -
Page 18: Mower Lift
TRACTOR - - MODEL NUMBER MC19542LT (96012011400), PRODUCT NO. 960 12 01-14 MOWER LIFT 16 17 lift-rh.1piece_3 PART PART DESCRIPTION DESCRIPTION 532 40 49-81 Plunger Asm Lift Lever 873 35 08-00 Nut Jam Hex 1/2-13 Unc 532 15 94-71 Shaft Asm Lift RH... - Page 19 SERVICE NOTES...
-
Page 20: Limited Warranty
This Warranty gives you specific legal rights, and you may have other rights which vary from locale to locale. This is a limited Warranty within the meaning of that term as defined in the Magnuson-Moss Act of 1975. www.mcculloch.biz 12.28.10 BAD Printed in the U.S.A.
