Summary of Contents for Citizen Eco-Drive H950

Page 1 INSTRUCTION MANUAL...
Page 2 Thank you for your purchase of this Citizen watch. Before using the watch, read this instruction manual carefully to ensure correct use. After reading the manual, store it in a safe place for future reference. Visit the Citizen website (http://www.citizenwatch-global.com/) to view visual guides for operation of your watch.
Page 3: Safety Precautions
Safety precautions (IMPORTANT) This manual contains instructions that should be strictly followed at all times not only for optimal use, but to prevent any injuries to yourself, other persons or property. We encourage you to read the entire booklet (especially, pages 68 to 77) and understand the meaning of the following symbols: ■...
Page 4 Safety precautions (IMPORTANT) ■ Important instructions are categorized and depicted in this manual as follows: Warning (caution) symbol followed by instructions that should be followed or precautions that should be observed. Warning (caution) symbol followed by prohibited matters.
Page 5: Before Using This Watch
Before using this watch After unpacking, the following must be carried out before using the watch: ◆ Checking the power reserve  Page 17 ◆ Setting the World Time  Page 21 ◆ Receiving the satellite time signal  Page 31 This watch has a rechargeable cell which is charged by exposing the dial to light.
Page 6: Protective Stickers
We recommend seeking the assistance of an experienced watch technician for sizing of your watch. If adjustment is not done correctly, the bracelet may unexpectedly become detached leading to loss of your watch or injury. Consult your nearest authorized Citizen service center.
Page 7: How To Use A Specially Designed Crown/Push Button
Before using this watch ◆ How to use a specially designed crown/push button Some models are equipped with a specially designed crown and/or push button to prevent accidental operation. Screw down crown and screw down push button Unlock the crown prior to operate your watch. Unlock Lock Push the crown in to...
Page 8 Before using this watch Recessed buttons Press the button with a non-marring narrow- tipped object such as a wooden toothpick. • Metal objects may cause marring or scratching of the button.
Page 9: Table Of Contents
Table of contents Features ……………………………………………………………… 10 Component identiication ………………………………………… 11 Charging your watch ………………………………………………… 12 Using the world time function ……………………………………… 20 Switching summer time and standard time ……………………… 28 Before receiving the satellite time signal ………………………… 31 Receiving the satellite time signal ………………………………… 37 Checking and adjusting leap seconds………………………………...
Page 10 Table of contents Troubleshooting …………………………………………………… 60 Eco-Drive watch handling precautions …………………………… 68 Water resistance …………………………………………………… 70 Precautionary items and usage limitations ……………………… 72 Speciications ………………………………………………………… 78...
Page 11: Features
"Perpetual calendar" No need for date correction at the end of each month. The leap year is also updated automatically. "World Time" Time can be selected and indicated from 40 time zones in the world. * "Eco-Drive" is Citizen's proprietary.
Page 12: Component Identiication
Component identification Reception-in-progress indication (RX) Minute hand Hour hand Ⓑ Upper right button Reception result indicator (OK/NO) Function indication • Day of the week Crown • Summer Time indication (ON/OFF) 24-hour hand • Power reserve level Ⓐ Function Lower right button indication hand Second hand Areas / time differences...
Page 13: Charging Your Watch
Charging your watch This watch has a rechargeable cell which is charged by exposing the dial to light, such as direct sunlight or fluorescent lamps (refer to pages 14 and 15 for charging guidelines). After taking off the watch, put it in a location where the dial is exposed to bright light, such as by a window.
Page 14 Charging your watch • If the watch is obscured from light by long sleeves frequently, supplemental charging may be needed to ensure continual operation. • Do not charge the watch at a high temperature (about 60°C (140°F) or higher) as doing so may cause movement malfunction.
Page 15: When The Watch Reaches A Low Charge State (Insufficient Charge Warning Function)
Charging your watch ◆ When the watch reaches a low charge state (insufficient charge warning function) When the power reserve becomes low, the second hand moves once every two seconds. This is the insufficient charge warning function. Be sure to fully charge your watch.
Page 16: Charging Time By Environment
Charging your watch ◆ Charging time by environment Below are the approximate times required for charging when exposing the watch dial to light continuously. Please use this table as a reference only. Charging time (approx.) Illuminance To start working To become fully Environment To work for (lx)
Page 17 If the watch does not work even after charging for more than one day under direct sunlight, please consult Citizen Customer Support Center. Fully charged to fully discharged: Approximately 2 years...
Page 18 Charging your watch ◆ Checking the power reserve Check the current power reserve. 1. Ensure that the crown is in position 0 . 2. Press the lower right button Ⓐ . The function indication hand indicates the power reserve level. • For details on the power reserve level, see the Ⓐ...
Page 19 Charging your watch Charging your watch The power reserve level Level Power reserve level Approx. 2 years to 1 year Approx. 1 year to 16 days Approx. 16 to 10 days Approx. 10 days Power reserve Power reserve is Power reserve is Power reserve is is sufficient for sufficient for all...
Page 20 Charging your watch • When the power reserve is at the 0 level, the second hand indicates the insufficient charge warning state (by moving once every two seconds). You can manually correct the time and calendar, but you cannot perform the other operations and receive satellite signals.
Page 21: Using The World Time Function
Using the world time function ◆ Confirming the world time Check the current world time setting. 1. Ensure that the crown is in position 0 . Ⓑ 2. Press the upper right button Ⓑ . The second hand indicates the world time setting and the function indication hand indicates the summer time setting.
Page 22 Using the world time function ◆ Setting the World Time The watch can indicate the time of any of the 40 time zones in the world. • When using the watch in an area not listed in the table, select and set an area with the same time zone. 1. Pull the crown out to position . The second hand indicates the current setting of the world time and the function indication hand indicates the summer time setting.
Page 23 Using the world time function ◆ How to read indication of the world time setting The watch has 40 time zone markers with several representative area names. A time zone is set by pointing the second hand at one of the markers. Time zone marker In the illustration on the left, the second hand points to 28 seconds and time zone...
Page 24 Using the world time function ◆ Table of time zones and representative areas Countries or regions may change time zones for various reasons. Time zone Second hand Area name Representative area (UTC offset) position LON London 0 sec. Paris 2 sec. ATH Athens 4 sec.
Page 25 Using the world time function Time zone Second hand Area name Representative area (UTC offset) position +5.5 Delhi 12 sec. +5.75 — Kathmandu 13 sec. Dhaka 14 sec. +6.5 — Yangon 15 sec. Bangkok 16 sec. BJS （HKG） Beijing / Hong kong 18 sec.
Page 26 Using the world time function Time zone Second hand Area name Representative area (UTC offset) position Sydney 25 sec. +10.5 — Lord Howe Island 26 sec. Noumea 27 sec. +11.5 — Norfolk Island 28 sec. Auckland 29 sec. +12.75 — Chatham Islands 31 sec.
Page 27 Using the world time function Time zone Second hand Area name Representative area (UTC offset) position –11 MDY Midway 38 sec. –10 Honolulu 40 sec. –9.5 — Marquesas Islands 41 sec. –9 Anchorage 42 sec. –8 Los Angeles 44 sec. –7 Denver 46 sec.
Page 28 Using the world time function Time zone Second hand Area name Representative area (UTC offset) position –4 Santiago 52 sec. –3.5 — St. John's 53 sec. –3 Rio de Janeiro 54 sec. –2 Fernando de Noronha 56 sec. –1 Azores 58 sec.
Page 29: Switching Summer Time And Standard Time
Switching summer time and standard time ◆ Summer time Summer time is a system adopted in some countries/areas to gain an extra daylight during summer. This watch can display the summer time or the standard time according to the area selected for world time. •...
Page 30 Switching summer time and standard time ◆ Checking the time currently shown Check whether the watch shows Summer Time or standard time. 1. Ensure that the crown is in position 0 . Ⓑ 2. Press the upper right button Ⓑ . The function indication shows the summer time ON/ OFF setting.
Page 31 Switching summer time and standard time ◆ Changing the summer time setting 1. Pull the crown out to position . 2. Press the lower right button Ⓐ to switch the summer time setting to ON or OFF. To show summer time Select "ON".
Page 32: Before Receiving The Satellite Time Signal
Before receiving the satellite time signal This watch receives the clock time information sent by satellite. This watch only receives time information. Location information cannot be acquired. ◆ Receiving the satellite time signal The satellite time signal can be received using the following two methods. You can also check whether the last attempt to receive the time signal was successful or not.
Page 33 Before receiving the satellite time signal When All Reset has been performed or you have manually adjusted the calendar, reception may take up to about 70 seconds.
Page 34 Before receiving the satellite time signal ◆ Cautions regarding receiving the satellite time signal Do not perform satellite time signal reception while operating a vehicle as doing so is extremely dangerous. • If the second hand is moving once every two seconds (insufficient charge warning function), you cannot perform satellite time signal reception. Charge the watch sufficiently before attempting time signal reception.
Page 35 Before receiving the satellite time signal ◆ When receiving the satellite time signal As shown in the picture below, make sure you are in an area with few surrounding trees, buildings, or other objects that may obstruct the satellite time signal. Face the dial towards the sky and perform time signal reception.
Page 36 Before receiving the satellite time signal • Receiving signals indoors near a window • Place the watch near a window with a wide view of the sky and orient the dial in an obliquely upward direction (approximately 45°). • If there are buildings, trees, or other obstacles above the window, satellite signals may not be able to be received. • The direction of the window that allow signal reception may be limited. Find the direction in which you can securely receive signals. • Satellite signals may not be able to be received through wire-reinforced glass or heat reflective glass (or film).
Page 37: Poor Reception Areas
Before receiving the satellite time signal ◆ Poor reception areas It may be difficult to receive the satellite time signal under certain environmental conditions or in certain areas. Areas with obstructions above the Nearby objects which emit magnetism watch or noise • Indoors or underground • High-voltage electric cables, railway • Areas surrounded by tall...
Page 38: Receiving The Satellite Time Signal
Receiving the satellite time signal ◆ Manual reception 1 Use this method for normal reception. 1. Ensure that the crown is in position 0 . 2. Press and hold the lower right button Ⓐ for two or more seconds. After indicating the previous reception result, the tail of the second hand moves to “RX”...
Page 39 Receiving the satellite time signal The second hand will move normally once reception is finished and the reception result has been displayed for 2 seconds. Successful signal reception Failed signal reception Reception result (OK) Reception result (NO) The time will be updated and the Normal operation resumes with the previously set time.
Page 40 Receiving the satellite time signal To cancel the reception Press and hold the lower right button Ⓐ for two or more seconds. The reception is canceled and the current time will be indicated. • If the time is not correct even after performing signal reception, it is possible that the leap second has been updated.
Page 41 Receiving the satellite time signal ◆ Manual reception 2 Use this method when the leap second has been updated. 1. Ensure that the crown is in position 0 . 2. Press and hold the lower right button Ⓐ for seven or more seconds.
Page 42 Receiving the satellite time signal The second hand will move normally once reception is finished and the reception result has been displayed for 2 seconds. Successful signal reception Failed signal reception Reception result (OK) Reception result (NO) The time will be Normal operation updated and the watch resumes with the...
Page 43 Receiving the satellite time signal ◆ Checking the satellite time signal reception You can check the previous result of satellite time signal reception (Manual reception 1/Manual reception 2). 1. Ensure that the crown is in position 0 . 2. Press the lower right button Ⓐ . The tail of the second hand indicates the reception result.
Page 44 Receiving the satellite time signal • Even if reception has succeeded, "NO" will be indicated if more than 48 hours have passed since time signal reception was last performed. 3. Press and release the lower right button Ⓐ to finish the procedure. • The current time indication will resume automatically when leaving the watch for approx. 10 seconds.
Page 45: Checking And Adjusting Leap Seconds
Checking and adjusting leap seconds This watch displays the time information by setting the leap second and time zone (manual adjustment) to the International Atomic Time information received from the satellite. • The leap second setting is specified according to the time of shipment. "-35 seconds” is specified as of August 2014. • When the leap second information is received through performing manual reception 2 (see page 40), the leap second is automatically adjusted. • The leap second can also be adjusted manually. You can find a list of leap seconds at the homepage of IERS (INTERNATIONAL EARTH ROTATION &...
Page 46 Checking and adjusting leap seconds 1. Pull the crown out to position 2 . Ⓑ 2. Press the upper right button Ⓑ . Using the "0:00:00" position as the starting point, the minute hand and second hand will indicate the leap second setting after a few seconds. When 0 minutes and When 1 minute and 35 seconds is indicated: 5 seconds is indicated:...
Page 47 Checking and adjusting leap seconds 3. Rotate the crown to adjust the leap second. • The leap second can be adjusted in the range of 0 to –90 seconds. 4. Push the crown in to position 0 to finish the procedure. The leap second setting is specified according to the time of shipment. "-35 seconds” is specified as of August 2014.
Page 48: Checking And Adjusting The Rollover Number
Checking and adjusting the rollover number In order for this watch to correctly process the week information* received from the satellite, a rollover number for each time period is set. The rollover numbers will be updated automatically. If the rollover number setting is incorrect, the time and date may not be displayed accurately.
Page 49 Checking and adjusting the rollover number Time period (Coordinated Universal Time, GMT) Rollover number 22/8/1999 (Sun) 00:00 – 6/4/2019 (Sat) 23:59 7/4/2019 (Sun) 00:00 – 20/11/2038 (Sat) 23:59 21/11/2038 (Sun) 00:00 – 6/7/2058 (Sat) 23:59 7/7/2058 (Sun) 00:00 – 19/2/2078 (Sat) 23:59 20/2/2078 (Sun) 00:00 –...
Page 50 Checking and adjusting the rollover number 1. Pull the crown out to position 2 . Ⓑ 2. Press the upper right button Ⓑ . The minute hand and second hand will indicate the current leap second setting. 3. Press and hold the upper right button Ⓑ for five or more seconds.
Page 51 Checking and adjusting the rollover number 4. Rotate the crown to adjust the rollover number. • The rollover number can be adjusted in the range of 0 – 5. See the table on page 48 for appropriate rollover number. 5. Push the crown in to position 0 to finish the procedure.
Page 52: Adjusting The Time/Calendar Manually
Adjusting the time/calendar manually Manually adjust the time/calendar when the watch cannot receive the time signal. 1. Pull the crown out to position 2 . The second hand moves to the 30-second position. 2. Press the lower right button Ⓐ . The second hand moves to the 0 second position, and it becomes possible to adjust the time/calendar. Ⓐ...
Page 53 Adjusting the time/calendar manually 3. Press the lower right button Ⓐ to select the ② ⑤ correction target. Each time you press the lower right button Ⓐ , the correction target changes as follows and the corresponding hand slightly moves. ① ② Time (minutes) → Time (hours/24-hour time) → ③...
Page 54 Adjusting the time/calendar manually 4. Rotate the crown to adjust each setting. • If you spin the crown quickly, the hands for the time and day will move continuously. To slow down and stop them, slightly rotate the crown. • To move the date forward or backward by one day, slightly rotate the crown. • The year and month are indicated by the second hand. Adjust them by referring to the figure in the next page. 5. Repeat procedures 3 and 4. 6. On the stroke of the time signal, push the crown in to position 0 to finish the setting.
Page 55 Adjusting the time/calendar manually ◆ Month and year indications The number of years and months since the leap year is December indicated by the position of the second hand. [Month] January December : between 12:00 and 01:00 January : between 01:00 and 02:00 February : between 02:00 and 03:00 [Year] Leap year:...
Page 56 Adjusting the time/calendar manually You can get the actual year from the number of years passed from the leap year by referring to the following table: Indication of the second hand Passed year Year Hour marker Leap year 2016, 2020, 2024 1st min.
Page 57: Checking And Correcting The Current Reference Position
Checking and correcting the current reference position ◆ What is the reference position? The base position for all the hands to indicate the time and date. If the reference position is not correct, the time and functions are not indicated correctly.
Page 58 Checking and correcting the current reference position ◆ Checking and correcting the current reference position 1. Ensure that the crown is in position 0 . Ⓑ 2. Press and hold the upper right button Ⓑ for seven seconds. All hands and the date indication move to indicate the current reference position.
Page 59 Checking and correcting the current reference position ② 5. Press the lower right button Ⓐ to select the correction target. Each time you press the lower right button Ⓐ , the correction target changes as follows and the corresponding hand slightly moves. ① Day of the week (function indication)/date Ⓐ...
Page 60 Checking and correcting the current reference position 6. Rotate the crown to correct the reference position of the active hand/ indication. • When you rotate the crown quickly, each hand will move continuously. To slow down and stop them, slightly rotate the crown. 7. Push the crown in to position 0 to finish the correction. 8.
Page 61: Troubleshooting
Troubleshooting If you have a problem with your watch, check the table below. Problems with time signal reception. Symptoms Remedies Page Push the crown in to position 0 . — Avoiding places where the satellite signal may be obstructed and objects which emit noise, face the dial 34 to 36 towards the sky and start reception.
Page 62 If the remedies above do not solve the problems, (Continued) — consult your nearest Authorized Citizen Service Center. Check and correct the World Time setting. 20 to 27 If the time is not indicated correctly after performing 40 to 41 manual reception 1, perform manual reception 2.
Page 63 Troubleshooting The hands do not work properly. Symptoms Remedies Page The second hand moves once every two Charge the watch. 12 to 16 seconds. Push the crown in to position 0 . — All hands stop moving. Charge the watch by exposing it to direct sunlight 12 to 16 until the second hand starts moving every second.
Page 64 Troubleshooting The time and/or date is incorrect. Symptoms Remedies Page Check the World Time setting. 20 to 27 Change the Summer Time setting. 28 to 30 The time and/or date is Check and correct the current reference position. 56 to 59 incorrect.
Page 65 Send the watch to your nearest Authorized Citizen Service Center. Charge the watch for 2 to 3 days under direct sunlight. If the second hand starts moving once every two seconds The watch stops the watch is being charged correctly.
Page 66: All Reset
Troubleshooting ◆ All Reset When the watch does not work properly, you can reset all the settings. If the power reserve is insufficient, charge the watch first. Check before performing All Reset. After performing All Reset, you need to configure all the settings again. Set the watch again by following the procedures in the next page.
Page 67 Troubleshooting 1. Correct the current reference position. See page 56. After performing All Reset, the watch is in reference position correction mode. See from step 5 on page 58. 2. Set the World Time. See page 21. • To set Summer Time, see page 30. 3. Adjust the time/calendar. • For adjustment through receiving the satellite time signal: See pages 37.
Page 68 Troubleshooting ◆ Performing All Reset Perform this operation after checking the contents of the previous page. 1. Pull the crown out to position 2 . 2. Press and hold both the lower right button Ⓐ and the Ⓑ upper right button Ⓑ for three or more seconds. The second hand moves to the “0” second position, the hour hand and date indication move slightly, and the watch is reset.
Page 69: Eco-Drive Watch Handling Precautions
Eco-Drive watch handling precautions <Always Make Sure to Recharge Frequently> • Please note that if you wear long sleeves, the watch may stop as a result of being covered by your sleeve and blocked from the light. • When you take off the watch, try to place it in as bright a location as possible. This will ensure optimal operation.
Page 70 Eco-Drive watch handling precautions <Replacement of Rechargeable Cell> • This watch utilizes a special rechargeable cell that does not require regular replacement. However power consumption may increase after using the watch for a number of years due to wear of internal components and deterioration of oils. This may cause stored power to be depleted at a faster rate. For optimal performance, we recommend having your watch inspected (chargeable to the owner) by an Authorized Service center to ensure operation is within factory specifications.
Page 71: Water Resistance
Water resistance WARNING Water Resistance • Refer to the watch dial and the case back for the indication of the water resistance of your watch. The following chart provides examples of use for reference to ensure that your watch is used properly. (The unit "1bar" is roughly equal to 1 atmosphere.) • WATER RESIST(ANT) ××bar may also be indicated as W.R.××bar. • Non-water resistant models are not designed to come into contact with any moisture. Take care not to expose a watch with this rating to any type of moisture. • Water resistance for daily use (to 3 atmospheres) means the watch is water resistant for occasional accidental splashing.
Page 72 Water resistance • Upgraded water resistance for daily use (to 5 atmospheres) means that the watch may be worn while swimming, but is not to worn while skin diving. • Upgraded water resistance for daily use (to 10/20 atmospheres) means that the watch may be worn while skin diving, but not while scuba or saturated diving using helium gas. Water-related use Minor exposure Swimming and Operate the crown Skin diving, Scuba diving to water (washing general washing...
Page 73: Precautionary Items And Usage Limitations
Precautionary items and usage limitations CAUTION To Avoid Injury • Be particularly careful when wearing your watch while holding a small child, to avoid injury. • Be particularly careful when engaged in strenuous exercise or work, to avoid injury to yourself and others. • Do NOT wear your watch while in a sauna or other location where your watch may become excessively hot, since there is the risk of burns. • Be careful when putting on and taking off your watch, since there is a risk of damaging your fingernails, depending on the manner in which the band is fastened. • Take off your watch before going to bed. CAUTION Precautions • Always use the watch with the crown pushed in (normal position). If the crown is of the screw...
Page 74 Precautionary items and usage limitations • Even if your watch has a high level of water resistance, please be careful of the following. - If your watch is immersed in sea water, rinse thoroughly with fresh water and wipe with a dry cloth. - Do not pour water from a tap directly onto your watch. - Take off your watch before taking a bath. • If seawater enters the watch, place the watch in a box or plastic bag and immediately take it in for repair. Otherwise, pressure inside the watch will increase, and parts (crystal, crown, push button, etc.) may come off.
Page 75 - The pin of the band is protruding. • We recommend seeking the assistance of an experienced watch technician for sizing of your watch. If adjustment is not done correctly, the bracelet may unexpectedly become detached leading to loss of your watch or injury. Consult your nearest authorized Citizen service center. <Temperature> • The watch may stop or the function of the watch may be impaired in extremely high or low temperature. Do not use the watch in places where the temperature is outside the operating temperature range as stated in the specifications.
Page 76 Precautionary items and usage limitations <Strong Shock> • Avoid dropping the watch or subjecting it to other strong impact. It may cause malfunctions and/ or performance deterioration as well as damage to the case and bracelet. <Static Electricity> • The integrated circuits (IC) used in quartz watches are sensitive to static electricity. Please note that the watch may operate erratically or not at all if exposed to intense static electricity. <Chemicals, Corrosive Gasses and Mercury>...
Page 77 Precautionary items and usage limitations CAUTION Always Keep Your Watch Clean • Rotate the crown while it is pressed in fully and press the buttons periodically so they do not become stuck due to accumulations of foreign matter. • The case and band of the watch come into direct contact with the skin in the same manner as undergarments. Corrosion of the metal or unnoticed soiling such as that caused by perspiration and dirt can soil sleeves and other portions of clothing. Keep your watch clean at all times. • The case and band of the watch come into direct contact with the skin. If you think there is something wrong, discontinue wearing the watch immediately and consult your physician.
Page 78 Precautionary items and usage limitations Caring for Your Watch • Wipe any dirt or moisture such as perspiration from the case and crystal with a soft cloth. • For a metallic, plastic or rubber (urethane) watchband, wash any dirt off with water. Remove the small amounts of dirt trapped between the crevices of the metallic band with a soft brush. • For a leather band, wipe off dirt using a dry cloth. • If you will not be using your watch for an extended period of time, carefully wipe off any perspiration, dirt or moisture and store in a proper location, avoiding locations subject to excessively high or low temperatures and high humidity.
Page 79: Speciications
Specifications Model H950 Type Analog solar-powered watch Timekeeping Within ±15 seconds per month when worn at normal operation accuracy (without temperatures (between +5°C and +35°C) (between 41°F and 95°F) reception) Operating -10°C to +60°C (14°F to 140°F) temperature range Chargeable 0°C to +40°C (32°F to 104°F) temperature range...
Page 80 Specifications • Solar power function • Power reserve indication • Charge suspension temperature detection function • Overcharging prevention function • Over discharge detection function • Insufficient charge warning function (two-second interval movement) • Satellite time signal reception function (manual reception 1/manual Additional reception 2) •...
Page 81 This product follows the provisions of R&TTE Directive (1999/5/EC) ETSI EN300 440-2 V1.4.1 ETSI EN301 489-3 V1.4.1 EN60950-1 : 2006 +A12 : 2011...
Page 82 ・CC109＊ Model No.CC108＊ Cal.H950 CTZ-B8181...
