  • Page 1 T 2045 T 2060 Maintenance Manual Matrix Printer Titelbild.iso...

  • Page 2: Spare Parts And Schematics

    Spare Parts and Schematics Spare Parts and Schematics The spare parts lists show: 1. The position of the part in the explosion drawing. 2. The name of the part. 3. The part number. 4. The type of the machine. Stand. means Standard Machine w/o Color Color means Color printer...
  • Page 3 Spare Parts and Schematics This page intentionally left blank.
  • Page 4 Housing/Panel Spare Parts and Schematics Housing/Panel (4x) 7-3/4...
  • Page 5 Spare Parts and Schematics Housing/Panel item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. Front Flap Assy 054 897 Housing Lower Part 054 571 Housing Upper Part 054 645 Tappet 054 632 Front Top Cover Assy...
  • Page 6 Housing/Panel Spare Parts and Schematics This page intentionally left blank.
  • Page 7 Basic Printer Spare Parts and Schematics Basic Printer Basic Printer 20 (3x) 28 29 30 10 (4x) 73 (2x) (2x) 7-7/8...
  • Page 8 Basic Printer Spare Parts and Schematics 89 41 93 (3x) 96 (6x) 104 (3x) 106 (3x) 105 (6x) 101 (2x) 7-9/10...

  • Page 9: Basic Printer

    Spare Parts and Schematics Basic Printer item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. ,,/“ no item number available. Please see details in according chapters ,,na“ no spare part ElectronicParts Interconnection Board 047 564...
  • Page 10 Basic Printer Spare Parts and Schematics item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. Ribbon Mask (SP) 054 426 Paper Guard (SP) 054 426 Screw 3x8 716 175 Shaft Assy Standard 053 241 Shaft Assy 2nd Tractor...
  • Page 11 Spare Parts and Schematics Basic Printer item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. Bevel gear 053 579 Bevel Gear Drive 053 580 Lid (Toothed Wheel Drive) 053 286 Damper right 053 204 Toothed Wheel Z58 FD...
  • Page 12 Basic Printer Spare Parts and Schematics item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. DIN (Standard) Parts Screw TORx 8x32 DIN 7981 707 044 Screw TORx 2x16 DIN 7981 707 049 Washer 4 DIN 6799...
  • Page 13 Spare Parts and Schematics 7-15...
  • Page 14 Spare Parts and Schematics item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. AGA Assy 047 540 AGA Flag 054 616 Indicator Axle 054 765 7-16...
  • Page 15 Spare Parts and Schematics Color Option Color Option 7-17...

  • Page 16: Color Option

    Color Option Spare Parts and Schematics item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. Color Parts Motor Controller (Color) 046 760 Color Motor Cable 046 809 Motor Color 053 510 Switch Shaft 053 315...
  • Page 17 Spare Parts and Schematics Connector Board/Cables Connector Board/Cables 7-19...
  • Page 18 Connector Board/Cables Spare Parts and Schematics item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. LF-Motor 053 437 2nd Tractor Cable 047 190 Interlock Assy 047 523 Paper Motion Cable – – PE Sensor ASF...
  • Page 19 Spare Parts and Schematics Power Supply T 2045 Part ID-No Class. Power Switch Assy 047 526 Part ID-No Class. Cable Power Supply 047 522 7-41...
  • Page 20 Shared Interface Standard Cx/RS232 (Option) Spare Parts and Schematics Shared Interface Standard Cx/RS232 (Option) Part. No.: 046 752 7-42...

  • Page 21: Motor Driver

    Motor Driver Spare Parts and Schematics Motor Driver Part. No.: 046 760 (Color) Part. No.: 047 367 (ASF) 7-46...
  • Page 22 Sheet Feeder Mechanic Adjustment and Modification of Sheetfeeder Area Adjustment and By assembling the Sheetfeeder unit take care about the position of the axle “A” to the swing plate “B”. They must be perpendicular mounted. Modification of Sheetfeeder Area To avoid problems during paper feed from sheetfeeder bins using paper with extreme smooth back side you may: –...
  • Page 23 Spare Parts and Schematics Sheet Feeder Mechanic Spare Parts and Schematics (2x) (2x) (4x) (4x) (2x) (2x) (4x) (2x) (4x) (4x) (2x) (2x) (2x) (4x) (2x) Bild8_4.iso 8-5/6...
  • Page 24 Spare Parts and Schematics Sheet Feeder Mechanic item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. File Support 053 492 Toothed Wheel Z35 Assy 053 489 Cover left 053 491 Marginal Stop right 053 483...
  • Page 25 Sheet Feeder Mechanic ASF/Sheetfeeder, Gear Block ASF/Sheetfeeder, Gear Block (3x) (2x) (2x)

  • Page 26: Asf/Sheetfeeder, Gear Block

    ASF/Sheetfeeder, Gear Block Sheet Feeder Mechanic item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. ASF Gear Block 054 484 Gear Cover 053 352 Motor CSF 053 455 Logic Motor Control 047 367 Gear Housing...

  • Page 27: Specification

    Specification Face Down Option Face Down Option Specification Please see section 8.1 Functional Description The face down option is an additional module which can be used in connection with the automatic sheet feeder as well as with the manual paper insertion at the front of the printer.
  • Page 28 Face Down Option Spare Parts Spare Parts...

  • Page 29: Spare Parts

    Spare Parts Face Down Option item name Part No Stand. Color T 2045 T 2060 T 2060-2T Class Qty. Face Down Assy Carrier Plate Assy (ET) 053 576 Paper Guide 053 419 Bearing left 053 421 Pressure Foil 053 422...
