    Salt & Swim Chlorine Generator for Swimming Pools up to 90,000 litres Owner’s Manual Contents Introduction....1 Installation....2-8 Operation....12-14 Troubleshooting... 15 Warranty......21 Model: SAS-AU Hayward Pool Products (Australia) Pty Ltd Melbourne, Sydney, Brisbane, Perth www.hayward-pool.com.au USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 2 • WARNING – To reduce the risk of electric shock, install unit at least 3.5 metres horizontally from the inside walls of a pool or spa/hot tub and at a height from the ground not less than 0.45 metres and in accordance with AS/NZS 3000 wiring rules. • Do not bury cord. Locate cord to minimise abuse from lawn mowers, hedge trimmers, and other equipment. Do not use an extension cord to connect the unit to the power outlet. SAVE THESE INSTRUCTIONS • USE ONLY HAYWARD GENUINE REPLACEMENT PARTS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 3: Introduction

    NOTE: The use of dry acid (sodium bisulfate) to adjust pool pH is discouraged especially in arid regions where pool water is subject to excessive evaporation and is not commonly diluted with fresh water. Dry acid can cause a buildup of by-products that can damage your chlorinator Cell. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 4: Installation

    This ensures a quick, troublefree transfer to the Salt & Swim system. Salt & Swim Installation Follow the step by step instructions located on the Installation Quick Start Guide. Refer to the following sections for more detailed information. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 5 4.5m of where the Control Box is mounted. Also, there must be enough clearance to insert and remove the Cell from the Vessel after the Vessel is installed. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 6 POOL POOL After gluing the Cell Unions on to the cut pipe, position the Vessel in a manner where the Cell can be easily inserted and removed. Secure the Vessel by handtightening the Unions. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 7 Remove the foam protector from the Cell. Fully cover Cell pins with supplied grease. Verify that the O-ring is attached to the Cell before inserting the Cell into the Cell Vessel as shown. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 8 3000 Wiring Rules), a bonding lug is provided at the bottom of the Salt & Swim enclosure. Run an eight gauge (8 AWG) solid copper wire from the bonding lug to your pool's existing bonding loop. to Pool Bonding loop USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 9 LED. The Flow Switch Calibration procedure is complete. You can now turn on your filter pump and begin normal operation. If the LOW WATER FLOW LED is still blinking after performing this procedure, refer to the Troubleshoot- ing section of this manual. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 10: Saturation Index

    Si = pH + Ti + Ci + Ai - 12.1 Total Calcuim ºC ºF Alkalinity Hardness How to use: Measure pool pH, temperature, calcium hardness, and total alkalinity. Use the chart above to determine Ti, Ci,and Ai from your measurements. Insert values of pH, Ti, Ci and Ai into the above equation. If Si equals .2 or more, scaling and staining may occur. If Si equals -.2 or less corrosion or irritation may occur. SCALING CORROSIVE USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 11 Always check stabiliser (cyanuric acid), when checking salt. These levels will most likely decline together. Use the chart on page 11 to determine how much stabiliser must be added to raise the level to 40 ppm. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 12 (33) (36) (37) 3000 (12) (14) (17) (18) (19) (11) (15) 3200 Ideal Ideal Ideal Ideal Ideal Ideal Ideal Ideal Ideal Ideal 3400 Dilute Dilute 3600+ Dilute Dilute Dilute Dilute Dilute Dilute Dilute Dilute USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 13 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 14: Operation

    Operation Controls The main controls and indicators are shown below. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 15: Before You Begin

    Stop Schedule - This selection will turn the schedule off. Pressing the RUN/STOP button while the pump is on will give you the following option: Stop Schedule - This selection will turn the schedule off. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 16 When illuminated steady, cell efficiency is greatly reduced and the SASAU has stopped producing chlorine. Inspect, clean or replace if necessary. Display The SASAU uses an LCD display to show information about its operating status. Depending on the USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 17 Maintaining the Salt & Swim System The replaceable Cell uses the same electronic self cleaning technology as the popular Hayward Turbo Cell. In most cases this self cleaning action will keep the Cell working at optimum efficien- cy. In areas where water is hard (high mineral content) and in pools where the water chemistry has been allowed to get "out of balance,"...
  • Page 18 Spring Start-up DO NOT turn the Salt & Swim on until the pool water chemistry has been brought to the proper levels. This information can be found on page 8. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 19: Troubleshooting

    Some indications may require a combination of LEDs to illuminate. To aid in interpreting these indications, Hayward has created an interactive tool located at www. hayward-pool.com.au. Use this tool and the information below to identify and correct problems that may arise.
  • Page 20 DAILY CHLORINE OUTPUT LEDs. There are ten DAILY CHLORINE OUTPUT LEDs that each indicate a different error. These LEDs are labeled with a number on the diagram below. Refer to the table on page 19 for their corresponding errors. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 21 40ºC 40ºC 10ºC USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 22: Warranty

    3. Where proof of purchase cannot be provided you will not be entitled to Extended Warranty Support. 4. Any item that has been Hard Wired to Power Supply cannot be serviced on site. Contact Hayward Pool Products Australia, Authorised Agent, or place of purchase for instruction.
  • Page 23 Local Branch Customer Service Manager to dispose of them. Hayward Pool Products (Australia) reserves the right to provide replacement or credit for any items authorised under this warranty program. All claims must be accompanied by a copy of original pur- chase receipt, clearly stating date of purchase.
  • Page 24 Hayward is a registered trademark and Salt & Swim is a trademark of Hayward Industries, Inc. © 2014 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
