Verizon 7500 Setup Manual

Verizon 7500 Setup Manual

Wireless router/modem static ip set up guide
Hide thumbs Also See for 7500:
Table of Contents

Advertisement

Quick Links

See also: User Manual
STATIC IP
SET UP
GUIDE
VERIZON 7500 WIRELESS
ROUTER/MODEM
Verizon High Speed Internet
for Business

Advertisement

Table of Contents
loading

Related Manuals for Verizon 7500

Summary of Contents for Verizon 7500

  • Page 1 STATIC IP SET UP GUIDE VERIZON 7500 WIRELESS ROUTER/MODEM Verizon High Speed Internet for Business...

  • Page 2: Static Ip Connection

    Verizon High Speed Internet for Business Service will not work until you have been notified by Verizon that your service is activated. Connect your new Verizon HSI 7500 wireless modem router to your computer following the “Quick Start Guide” in the box with the modem router.

  • Page 3: Table Of Contents

    ..PAGES 24-7 WINDOWS XP..........PAGES 24-28 ® WINDOWS VISTA ........PAGES 29-32 ® OS X (10.4)........PAGES 33-34 ® OS X (10.5)........PAGES 35-37 ® SECTION Troubleshooting: ........PAGE 38 If the Connection is not working NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...

  • Page 4: Section

    Verizon High Speed Internet for Business SECTION Configuring Your Verizon 7500 Wireless Modem Router with a Single IP Step 1 - Login: To get to the Verizon Wireless interface, enter in the browser address line: http://192.168.1.1 admin password After you have clicked “OK” in the secure screen, the Detect WAN Click on Detect Configuration to continue.

  • Page 5: Single Static Ip Configuration

    When the modem has completed detection (or even if detection fails), wait for the DSL light to go solid and then click on the Main link in the left navigation menu. NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...
  • Page 6 Verizon High Speed Internet for Business Since this is the first login, a prompt is displayed to change the factory default User Name and password. This is the user name/password setting for the GUI interface. For the User Name, type “admin” or the name of your choice. Next, type a password (Be sure to write down your User Name and password and store it in a safe place for future use).
  • Page 7 Single Static IP From the MAIN screen, Gateway Status: NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...
  • Page 8 Verizon High Speed Internet for Business In the My Gateway panel of the Main page, view the DSL link field. If the status reads Not Connected, you do not have a DSL link. However, if DSL Link field displays Connected and the Speed...
  • Page 9 The My Network page is displayed. Click on Network Connections. This will bring you to the Network Connections screen. Click on Action. This will bring you to the Advance DSL Connection screen. NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...

  • Page 10: Section

    Verizon High Speed Internet for Business Click on Edit in the VCs section.
  • Page 11 Single Static IP From the VC1 Configuration screen. Click on the Protocol dropdown menu and select Bridge. Click on Bridge Mode dropdown menu and select Routed Bridge. NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...

  • Page 12: Section 3

    IP address. See section 3 for your operating system. Open the browser and test your Internet connection by going to business.verizon.net to learn about the Verizon Small Business Center, Verizon email, web hosting and where to get additional Verizon High Speed Internet for Business support.

  • Page 13: Section

    SECTION Configuring Your Verizon 7500 Wireless Modem Router with Multiple Static IPs Step 1 - Login: To get to the Verizon Wireless gateway interface, enter in the browser address line: http://192.168.1.1 admin password After you have clicked “OK” in the secure screen, the Detect WAN Configuration page is displayed during a first time login.
  • Page 14 Verizon High Speed Internet for Business During detection the modem will reset numerous times. Be sure to keep an eye on the DSL light status to know when the modem has obtained sync and is ready to continue. When the modem has completed detection (or even if detection fails), wait for the DSL light to go solid and then click on the Main link in the left navigation menu.

  • Page 15: Multiple Static Ips Configuration

    Note: Creating a User Name and password and the detection of WAN settings is only required on the first login to the modem. Future logins will not require these steps except when the gateway has been set to factory default settings. NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...
  • Page 16 Verizon High Speed Internet for Business From the MAIN screen, Gateway Status:...
  • Page 17 Connected and the Speed (Down/Up) field displays numeric values, a DSL link has been established. Notice the Connection Type, Username and IP Address. In this example, the Connection Type is "PPP" (PPPoE). NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...
  • Page 18 Verizon High Speed Internet for Business Click on My Network. The My Network page is displayed. Click on Network Connections. This will bring you to the Network Connections screen. Click on Action. This will bring you to the Advance DSL Connection...

  • Page 19: Section

    Multiple Static IPs Click on Edit in the VCs section. NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...
  • Page 20 Verizon High Speed Internet for Business From the VC1 Configuration screen. Click on the Protocol dropdown menu and select Bridge. Click on Bridge Mode dropdown menu and select Routed Bridge.
  • Page 21 Click on Bullet. Use the following static addresses (disable DHCP Client). This will give you the option to input the static IP Address, Subnet, Gateway and DNS. Enter the information (found in your Verizon Service Activation Email). NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...
  • Page 22 Verizon High Speed Internet for Business Enter the 1st IP Address of the block of IP's in the IP address field, the Subnet in the Subnet field, the Gateway in the Gateway field, and the Primary and Secondary DNS servers in the DNS fields.
  • Page 23 Multiple Static IPs Click “Yes” at the warning screen. Select Public LAN. NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...

  • Page 24: Section

    Verizon High Speed Internet for Business Note: Make sure DHCP is NOT enabled/checked. Check the box next to Public LAN Enable. Enter the 1st IP Address (of the block of IP’s) in the Public LAN IP Address box. This is the address the router will use to “bridge” the router to the computers on the network.

  • Page 25: Section

    Windows XP, Windows Vista and MAC OS X WINDOWS XP - SET UP SINGLE OR MULTIPLE STATIC IP ADDRESSES ® 1. Click the Start button. Then click on My Computer. NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...
  • Page 26 Verizon High Speed Internet for Business 2. Click on the My Network Places icon. 3. Click on View Network Connections.

  • Page 27: Windows Xp

    4. If the LAN Connection is enabled, go to step 5. Note: If LAN Connections is disabled, then right click on Local Area Connection icon and click on Enable. 5. Right click on Local Area Connection then click on Properties. NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...
  • Page 28 Verizon High Speed Internet for Business 6. The Local Area Connection Properties window should open. Click on Internet Protocol (TCP/IP) to highlight it then click on Properties.

  • Page 29: Section

    7. Click on the General tab and select Use the following IP Address. Enter the IP address Subnet Mask and Default gateway address (found in your Verizon Service Activation Email). Go down to “Use the Following DNS Server” section. Click on Preferred DNS server textbox and enter the DNS 1 address (found in your Verizon Service Activation Email).

  • Page 30: Windows Vista

    WINDOWS VISTA - SET UP SINGLE OR MULTIPLE STATIC IP ADDRESSES ® Note: The steps in this section should be used to configure the computer to work with the Verizon 7500 Modem. 1. Click the Start button. 2. Click on Network.
  • Page 31 Windows Vista . Click Network and Share Center. 4. Click Manage network connections from the left menu. NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...
  • Page 32 Verizon High Speed Internet for Business . Right-click Local Area Connection and click Properties. 6. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties.
  • Page 33 Windows Vista 7. Enter the IP address Subnet Mask and Default gateway address (found in your Verizon Service Activation Email). Go down to “Use the Following DNS Server” section. Click on Preferred DNS server textbox and enter the DNS 1 address (found in your Verizon Service Activation Email).
  • Page 34 ® Note: The steps in this section should be used to configure the computer to work with the Verizon 7500 Modem. 1. First click the Apple, Select Location, then click System Preferences. 2. The System Preferences window opens. Click Network on the top menu.

  • Page 35: Mac Os X (10.4)

    Default Gateway Address (found in your Verizon Service Activation Email). Click on the Domain Name Servers textbox and enter the DNS1 and DNS 2 Server Addresses (found in your Verizon Service Activation Email). Click “Apply” Now. 5. Open the browser and test your Internet connection by going to business.verizon.net to learn about the Verizon Small Business Center,...

  • Page 36: Section

    ® Note: The steps in this section should be used to configure the computer to work with the Verizon 7500 Modem. 1. First click the Apple, Select Location, then click System Preferences. 2. The System Preferences window opens. Click Network on the top menu.

  • Page 37: Mac Os X (10.5)

    Mac OS X (10.5) . The Network window opens. In the dropdown menu labeled Configure, select Manually. NEED HELP? Call The Verizon Online Business Center at 1.888.649.9500...
  • Page 38 Activation Email). Click on the Domain Name Servers textbox and enter the DNS1 and DNS 2 Server Addresses Server Addresses separated by a comma and a space (found in your Verizon Service Activation Email). Click “Apply” Now. 5. Open the browser and test your Internet connection by going to business.verizon.net to learn about the Verizon Small Business Center,...

  • Page 39: Troubleshooting

    Check your Static IP setting; make sure the IP addresses are Correct and in proper position. • If your connection is still not working, please call The Verizon Business Center at 1.888.649.9500, choose the option for Installation Support to verify that your Static IP is available.
  • Page 40 STATICGWAYGD *STATICGWAYGD* ©2009 Verizon. Version: 0709...
