- Page 1 OPERATOR’S MANUAL 140 Watt Power Inverter Model No. 28.71522 Read and follow all Safety Rules and Operating Instructions before Every Use of this Product. SAvE ThESE INSTRUcTIONS. Sears Brands Management corporation, hoffman Estates, IL 60179 U.S.A. 00-99-001004/00...
-
Page 3: Table Of Contents
1 year from the date of purchase, return it to any DieHard outlet in the United States for free replacement. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. - Page 4 IMPORTANT: READ AND SAvE ThIS SAfETY AND INSTRUcTION MANUAL. SAvE ThESE INSTRUcTIONS – The 71522 offers a wide range of features to accommodate your needs. This manual will show you how to use your inverter safely and effectively. Please read, understand and follow these instructions and precautions carefully, as this manual contains important safety and operating instructions.
-
Page 5: Important Safety Instructions
IMPORTANT SAfETY INSTRUcTIONS SAvE ThESE INSTRUcTIONS Risk of electric shock or fire. Keep out of reach of children. Keep the inverter well ventilated in order to properly disperse heat generated while it is in use. Make sure there are several inches of clearance around the top and sides and do not block the slots of the inverter. -
Page 6: Features
fEATURES USB Port AC Outlet 12 Volt Power Plug BEfORE USINg YOUR POWER INvERTER NOTE: This inverter is designed to be used with a single battery, up to group 31 type and 130 Ah or smaller in size. Do not use with any larger battery type. Do not use with multiple batteries connected in parallel. - Page 7 To calculate the continuous load: Continuous Load = AMPS x 120 (AC Voltage). Always run a test to establish whether the inverter will operate a particular piece of equipment or device. In the event of a power overload, the inverter is designed to automatically shut down.
-
Page 8: Operating Instructions
OPERATINg INSTRUcTIONS DC Outlet DC Plug If connecting in a vehicle, remove the cigarette lighter from its outlet. Push the 12-volt power plug firmly into the outlet. The LED indicator light should glow GREEN verifying the inverter is receiving power. Make sure the device to be operated is turned OFF. -
Page 9: Led Indicator And Shutdown Protection
LED INDIcATOR AND ShUTDOWN PROTEcTION The LED glows GREEN automatically when plugged into a 12-volt DC source and will not glow under the following conditions: When the power input from the vehicle’s battery drops to approximately 10.5-volts, low battery shutdown occurs and inverter shuts off. Solution: Recharge or Replace the battery. -
Page 10: Troubleshooting
TROUBLEShOOTINg PROBLEM REASON SOLUTION LED does not light, or Poor contact at terminals. Unplug and reinsert the inverter does not function. 12-volt plug. Fuse Blown. See “IF THE INVERTER FUSE BLOWS” section. Inverter shutdown. See “LED INDICATOR AND SHUTDOWN PROTECTION” section. Inverter may not be working See Warranty and call properly. -
Page 11: Before Returning For Repairs
BEfORE RETURNINg fOR REPAIRS When an UNKNOWN OPERATING PROBLEM arises, please read the complete manual and call the customer service number for information that will usually eliminate the need for return. If the above solutions do not eliminate the problem or for information about troubleshooting or replacement parts, call toll-free from anywhere in the U.S.A.
