QNAP VioStor NVR User Manual page 204

Environment 4: VioStor and the IP camera are installed behind the router
VioStor 1
VioStor 2
VioStor 3
Router public IP
In the example, to allow a remote PC to access each VioStor by FTP, you need to:
Step 1. Set up the port mapping (virtual server) on the router
VioStor 1
VioStor 2
VioStor 3
You can connect to VioStor 1 by ftp://219.87.145.205:2001
You can connect to VioStor 2 by ftp://219.87.145.205:2002
You can connect to VioStor 3 by ftp://219.87.145.205:2003
Step 2. Enable FTP port mapping on VioStor
To connect to each VioStor via FTP by clicking "FTP" on the playback page of each
VioStor, enable FTP port mapping in "Network Settings" > "File Services" on the
system administration page and set the mapped port number.
VioStor 1
VioStor 2
VioStor 3
After finishing the above two steps, you can access VioStor via FTP by entering the
IP address in the IE browser or clicking "FTP" on the playback page. Then login
VioStor by the correct user name and password.
IP address
192.168.1.101
192.168.1.102
192.168.1.103
219.87.145.205
From
219.87.145.205:2001
219.87.145.205:2002
219.87.145.205:2003
Mapped port
2001
2002
2003
Forward to
192.168.1.101:21
192.168.1.102:21
192.168.1.103:21
204
