Infinity Reference Series 1300a Service Manual page 14

1300a Reference Series
Part Number
LED BOARD
2102-0154-02 FFC
1502-0504-00 Jack
06S121046000 SMD Capacitor
04PT-4148-01 Diode
MECHANICAL
LS1AM0250401 Screw
LS1AY0301201 Screw
LS1CJ0402507 Screw
KT-200021300 CAP
KT-200012200 CAP
LS5KP0300807 Screw
LS5KJ0301007 Screw
ZL-10037A-15 6.5PC Pole
ZA-H00040100 REFsnap button
DQ8069032084 Washer
KG-100100500 snap button
LS1AM0300607 Screw
LS1AY0300452 Screw
LS1AA0301501 Screw
LS1AA0200501 Screw
LS1FM0300011 Screw
LS1FJ0200801 Screw
PL-L0002-000 Grounding
XN-10500-012 Knob
XN-10500-011 Knob
JY297A22A001 Mica
JY247A22A001 Mica
CP-B00011400 Lens
SG-0016-2601 Top plate
SR-1300-0117 Heatsink
XG-0017-2601 Bottom Plate
PL-L0007-000 Cliper
PL-L0006-000 Cliper
GD-600011400 Reflector
GD-600010003 Acrylics board
JY222A18A01X Mica
HG-0004-2601 Rear Plate
MK-0004-2601 Front Plate
Description
2PIN UL1007 Red Black 28AWG L=40mm
soldering with 5mm
DIP Pitch 2.0MM 5PIN 弯90度
SMD 0.1uF/50V 0805 X7R ±10%
SMD 1N4148 DO-213AA
plating black zinc 2.5*4
PM3*12MM plating black zinc
TA4*25MM plating
red PVC RCA jack PVC material
white PVC RCA jack PVC material
3*8MM (plating)
3*10MM (plating)
φ7*6.4+φ4.95*1.5mm nylon color
φ7.5 M3.5*4 aluminum
Φ6.9*Φ3.2*0.8MM M3
T07-003-01 snap button φ11*φ14*10.8
black ABS
PM3*6(plating)
PM3*4.5MM plating white znic
PA3*15(plating black znic)
PA2*5(plating)
KM 3*6MM black znic
KA2*8（platiing）
GND-3
ABS-757 black Ф10.5*9MM
ABS-757black 11.7*Ф11MM red direction
97*22*0.1mm no hole
47*22*0.1mm no hole
40*10.8*5.7mm Pc material plastic grey
10C
360*227*62mm aluminium，H1-144silver
lacquer silk-screen
325*216*58mm
325*182*1.2mm H1-144silver lacquer
sick-screen
30*36*0.8mm
30*28*0.8mm
270*53.5*13mmblue clear PC material
plastic
264*48*4.0mm clear Acrylics
22*18*0.1MM
214*70*1.2mm H1-144silver paint silk-
screen
214*70*1.2mm H1-144silver paint silk-
screen
Qty Reference Designator
1
1
2 C1 C2
2 D1 D2
4
1
4 Accessory kit
2
2
8
3
1
4
1
4
2
2
2
1
5
2
1
3
1
2
4
1
1
1
1
4
6
1
1
1
1
1
13
