Infinity Reference Series 1300a Service Manual page 11

1300a Reference Series
REFERENCE 1300a Electrical Parts List
Part Number
MAIN BOARD
Resistors
0702-10R0-02 Resistor
0702-34R7-02 Resistor
0702-1220-02 Resistor
0702-1680-02 Resistor
0702-1101-02 Resistor
0702-1221-02 Resistor
0702-1471-02 Resistor
1201-1021-03 Variable Resistor
0702-1561-02 Resistor
0702-1751-02 Resistor
0702-1102-02 Resistor
0702-1152-02 Resistor
0702-1182-02 Resistor
0702-1202-02 Resistor
0702-1222-02 Resistor
0702-1332-02 Resistor
0702-1472-02 Resistor
0703-1652-03 Resistor
0702-1682-02 Resistor
0702-1752-02 Resistor
0702-1103-02 Resistor
0702-1113-02 Resistor
0702-1123-02 Resistor
0702-1133-02 Resistor
0702-1153-02 Resistor
0702-1203-02 Resistor
0702-1223-02 Resistor
0702-1243-02 Resistor
0702-1303-02 Resistor
0702-1333-02 Resistor
0702-1473-02 Resistor
0702-1563-02 Resistor
0702-1623-02 Resistor
0702-1823-02 Resistor
0702-1104-02 Resistor
0702-1154-02 Resistor
0702-1334-02 Resistor
0702-1474-02 Resistor
0702-1205-02 Resistor
0702-3101-02 Resistor
0702-24R7-02 Resistor
0702-3271-02 Resistor
0702-2103-02 Resistor
0702-2203-02 Resistor
0705-515X-07 Cement Resistor
1204-5031-30 Variable Resistor
1204-1041-07 Variable Resistor
Description
CARBON 1/8W 0Ω ±5%
1/2W 4.7Ω ±5%
1/8W 22Ω ±5%
1/8W 68Ω ±5%
1/8W 100Ω ±5%
1/8W 220Ω ±5%
1/8W 470Ω ±5%
1k Ω
1/8W 560Ω ±5%
1/8W 750Ω ±5%
1/8W 1KΩ ±5%
1/8W 1.5KΩ ±5%
1/8W 1.8KΩ ±5%
1/8W 2KΩ ±5%
1/8W 2.2KΩ ±5%
1/8W 3.3KΩ ±5%
1/8W 4.7KΩ ±5%
1/8W 6.5KΩ ±1%
1/8W 6.8KΩ ±5%
1/8W 7.5KΩ ±5%
1/8W 10KΩ ±5%
1/8W 11KΩ ±5%
1/8W 12KΩ ±5%
1/8W 13KΩ ±5%
1/8W 15KΩ ±5%
1/8W 20KΩ ±5%
1/8W 22KΩ ±5%
1/8W 24KΩ ±5%
1/8W 30KΩ ±5%
1/8W 33KΩ ±5%
1/8W 47KΩ ±5%
1/8W 56KΩ ±5%
1/8W 62KΩ ±5%
1/8W 82KΩ ±5%
1/8W 100KΩ ±5%
1/8W 150KΩ ±5%
1/8W 330KΩ ±5%
1/8W 470KΩ ±5%
1/8W 2MΩ ±5%
1/2W 100Ω ±5%
1/4W 4.7Ω ±5%
1/2W 270Ω ±5%
1/4W 10KΩ ±5%
1/4W 20KΩ ±5%
5W 0.15Ω ±5%
B50K ±10% LEVEL
B100K ±10% LP FREQ.
Qty Reference Designator
9 R34 R35 R61 L1 L2 L3 L4 JP140 JP141
3 R242 R36 R37
5 R112 R210 R211 R212 R213
2 R202 R203
7 R42 R132 R133 R134 R136 R137 R138
5 R145 R129 R130 R131 R207
1 R240
1 RW200
2 R127 R128
1 R38
R25 R30 R31 R32 R33 R113 R114 R200 R201
10
R105A
6 R238 R241 R249 R250 R252 R253
1 R41
3 R104 R219 R115
4 R124 R217 R218 R204
1 R120
5 R109 R110 R205 R26 R39
1 R106A
5 R159 R157 R214 R215 R216
2 R50 R51
R117 R21 R22 R27 R55 R62 R100 R101 R102 R103
14
R105 R121 R122 R125
1 R158
1 R154
1 R19
4 R152 R239 R256 R110A
3 R17 R18 R119
8 R106 R108 R147 R208 R1 R2 R7 R109A
2 R40 R209
1 R153
1 R118
R13 R16 R20 R23 R24 R28 R29 R60 R63 R126
23
R107 R3 R4 R5 R6 R8 R9 R10 R11 R12 R14 R15
R64
3 R150 R58 R235
2 R48 R49
1 R59
6 D111 R149 R53 R54 R155 R156
2 R56 R57
1 R151
1 R206
1 R44
2 R222 R223
6 R225 R226 R227 R228 R229 R231
2 R220 R221
2 R143 R144
1 R148
6 R233 R234 R236 R237 R259 R260
1 VR1
1 VR2
10
