Infinity Reference Series 1300a Service Manual page 12

1300a Reference Series
Part Number
MAIN BOARD
1204-5041-05 Variable Resistor
0704-6202-02 Resistor
0702-3220-02 Resistor
0702-1201-02 Resistor
0702-1562-02 Resistor
0702-1822-02 Resistor
Capacitors
06D212246001 CAP,Electro
06D212256301 CAP,Electro
06D212266010 CAP,Electro
06D214766109 CAP,Electro
06D214764102 CAP,Electro
06D211073116 CAP,Electro
06D212273109 CAP,Electro
06D21477H100 CAP,Electro
06D214775117 CAP,Electro
06D214789100 CAP,Electro
06D212274001 CAP,Electro
06D212285101 CAP,Electro
06D231017000 Ceramic Capacitor 100pF/100V ±20%
06D231047000 Ceramic Capacitor 0.1uF/100V ±20%
06D232217000 Ceramic Capacitor 220pF/100V ±20%
06D234717001 Ceramic Capacitor 470PF/100V ±20%
06D232207000 Ceramic Capacitor 22pF/100V ±20%
06D235607000 Ceramic Capacitor 56PF/100V ±20%
06D236817000 Ceramic Capacitor 680pF/100V ±20%
06D234737001 Ceramic Capacitor 473/100V ±20%
06D321027200 Ceramic Capacitor 102/100V ±5%
06D321037200 Ceramic Capacitor 103/100V ±5%
06D321047200 Ceramic Capacitor 104/100V ±5%
06D211074100 CAP,Electro
06D321839200 Ceramic Capacitor 183/63V ±5%
06D343939400 Ceramic Capacitor 393/63V ±5%
06D323349000 Ceramic Capacitor 334/63V ±5%
06D342249400 Ceramic Capacitor 224/63V ±5%
Semiconductors
04WY-82AV104 Zener Diode
04ZL-6A10-00 Diode
04WY-56AV104 Zener Diode
04PT-4148-04 Diode
04GS-R104-00 Diode
04GS-R204-00 Diode
04WY-39AV104 Zener Diode
03P1-1015-01 Transistor
03P1-A940-02 Transistor
Description
C500K ±10% BASS BOOST
2W 2KΩ ±5%
1/2W 22Ω ±5%
1/8W 200Ω ±5%
1/8W 5.6KΩ ±5%
1/8W 8.2KΩ ±5%
0.22UF/50V φ5*11mm ±20% 105℃
2.2UF/50V ±20% 5*11 105℃
22uF/50V ±20% 5*11 105℃
47uF/50V ±20% 5*11 105℃
47uF/25V ±20% 5*11 105℃
100UF/16V±20% 5*11 105℃
220uF/16V ±20% 5*11 105℃
470UF/80V ±20% φ16*25mm
470uF/35V ±20% 10*17 105℃
4700UF/63V ±20% φ35*27mm
220UF/25V ±20% 8*12 105℃
2200UF/35V Φ16*26MM ±20% 105℃
100uF/25V ±20% 6.3*11 105℃
8.2V DO-35 0.5W
6A10 1000V
5.6V 0.5W 20MA 52MM DO-35 0.5W
1N4148 GSS 200MA 75V DO-35
FR104 1A 400V 52MM
FR204 2A 400V 52MM
3.9V DO-35 0.5W
2SA1015 150MA 60V 400MW PNP TO-92
2SA940 PNP TO-220
Qty Reference Designator
1 VR3
2 R107A R108A
3 R142 R141 R140
1 R45
1 R46
1 R123
2 C110 C112
1 C208
12 C3 C204 C4 C5 C7 C8 C9 C10 C12 C13 C14 C103
2 C35 C36
2 C139 C102
3 C137 C138 C104
2 C209 C140
2 C135 C136
2 C133 C134
2 C144 C145
3 C1 C2 C207
4 C122 C123 C125 C124
11 C23 C24 C15 C16 C18 C19 C20 C21 C22 C56 C17
C101 C1A C1B C25 C26 C27 C28 C29 C30 C31 C32
28 C33 C34 C100 C111 C114 C115 C117 C118 C119
C120 C121 C6 C53 C54 C55 C128 C129
1 C38
1 C37
2 C42 C44
2 C201 C202
2 C200 C203
1 C205
2 C141 C142
2 C126 C127
8 C48 C116 C130 C131 C132 C146 C147 C206
2 C148 C143
3 C50 C51 C52
1 C49
2 C46 C47
2 C210 C211
1 DZ100
1 D106
1 DZ101
D100 D101 D102 D103 D104 D105 D200 D201 D202
12
D204 D205 D208
4 D117 D118 D119 D120
4 D107 D108 D109 D110
1 DZ101A
5 Q107 Q108 Q109 Q111 Q112
2 Q218 Q217
11
