Indesit cooker with ventilated oven instructions for installation and use

Advertisement

Quick Links

KG 6407 GV/G
KG 6407 AV/G
KG 6407 LV/G
KG 6408 WV/G
KG 6408 XV/G
Cooker with ventilated oven
Instructions for installation and use

Advertisement

loading
Need help?

Need help?

Do you have a question about the KG6407 AV/G and is the answer not in the manual?

Questions and answers

Summary of Contents for Indesit KG6407 AV/G

  • Page 1 KG 6407 GV/G KG 6407 AV/G KG 6407 LV/G KG 6408 WV/G KG 6408 XV/G Cooker with ventilated oven Instructions for installation and use...
  • Page 2 To maintain the EFFICIENCY and SAFETY of this appliance, we recommend: • use only the MANUFACTURER Service • use only ORIGINAL Spare Parts 1 These instructions are only for those countries whose symbols appear in the booklet and on the matriculation plate of the appliance.
  • Page 3: Installation Instructions

    All instruction on the following pages must be carried out by a competent person (corgi registered) in compliance with gas safety (installation and use) regulation 1984. Important: disconnect the cooker from the electrycity and gas supply when any adjustment, etc. Positioning Important: this unit may be installed and used only in permanently ventilated rooms according to the British...
  • Page 4 Electrical Connection Your appliance is now supplied with a 13 amp fused plug that can be plugged into a 13 amp socket for immediate use. Before using the appliance please read the instructions below. WARNING - THIS APPLIANCE MUST BE EARTHED. THE FOLLOWING OPERATIONS SHOULD BE CARRIED OUT BY A QUALIFIED ELECTRICIAN.
  • Page 5 • Rotate to the left to increase the flame and rotate to the right o lower the flame. N.B.: in the case of liquide gas, the regulation screw must be screwed in the bottom. Check that the flame does not turn off when you turn the tap quickly from hugh to low Fig.
  • Page 6: Technical Characteristics

    Mains frequency and voltage of the electric section and characteristics of the gas section Model Class KG 6407 GV/G KG 6407 AV/G KG 6407 LV/G II2H3+ KG 6408 WV/G KG 6408 XV/G (1) The values in g/h refer to the capacities with liquid gas (Butane, Propane). Dimensions of the oven: Volume of the oven: Dimensions of food-warmer drawer:...
  • Page 7 The different functions of the cooker The various functions included in the cooker are selected by operating the control devices located on the cooker control panel. The cooker is equipped, with a mechanical automatic programmer. Before operating the oven or the grill, ensure that the symbol coincides with the pointer on dial 4.
  • Page 8 burners, hold a lighted match or lighter near the burner. Push and turn the corresponding knob counter clockwise till to max position . Each burner can be operated at its maximum, minimum or intermediate power. Show on the knob are the different symbols for off • and it is in this position when the symbol corresponds with the reference mark for maximum and minimum...
  • Page 9 with the time shown in quadrant 5. Manual Operating Mode for the Oven The oven can be used normally, i.e. without being pro- grammed. In this case, knob 2 must be turned in the clock- wise direction until the symbol appears in quadrant 4. Semiautomatic Operating Mode The start time is nornal and end cooking time is pro- grammed:...
  • Page 10: Cooker Routine Maintenance And Cleaning

    Cooked well on the inside but sticky on the outside Use less liquid, lower the temperature, and increase the cooking time. The pastry sticks to the pan Grease the pan well and sprinkle it with a dusting of flour. I used more than one level and they are not all at the same cooking point Use a lower temperature setting.
  • Page 11 • Remove the lamp and replace with a lamp resistant to high temperatures (300°C) with the following characteristics: - Voltage 230V - Wattage 25W - Type E14 • Replace the glass over and connect the oven to the mains. Pratical advice for oven cooking Food to be cooked Wt.
  • Page 12 viale Aristide Merloni, 47 - 60044 Fabriano tel. 0732/6611 - telex 560196 - fax 0732/662954 www.Merloni.com...
