INSTALLATION

Step 1 — Thermostat Location
Thermostat should be mounted:
S Approximately 5 ft (1.5m) from floor.
S Close to or in a frequently used room, preferably on an inside
partitioning wall.
S On a section of wall without pipes or duct work.
Thermostat should NOT be mounted:
S Close to a window, on an outside wall, or next to a door leading
to the outside.
S Exposed to direct light and heat from the sun, a lamp, fireplace,
or other heat- -radiating object which may cause a false reading.
S Close to or in direct airflow from supply registers and return- -air
grilles.
S In areas with poor air circulation, such as behind a door or in an
alcove.
Step 2 — Install Thermostat
IMPORTANT: Install batteries last to ensure proper thermostat
mounting and latch engagement.
WARNING
!
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal injury
or death.
Before installing thermostat, turn off all power to unit. There
may be more than one disconnect.
1. Turn OFF all power to unit.
2. If an existing thermostat is being replaced:
a. Remove existing thermostat from wall.
b. Disconnect wires from existing thermostat, one at a
time. Be careful not to allow wires to fall back into wall.
c. As each wire is disconnected, record wire color and
terminal marking.
d. Discard or recycle old thermostat.
CAUTION
!
ENVIRONMENTAL HAZARD
Failure to follow this caution may result in environmental
damage.
Mercury is a hazardous waste. Federal regulations require that
mercury be disposed of properly.
3. Separate front and back (mounting base) assembly of ther-
mostat.
4. Route thermostat wires through hole in mounting base.
Level mounting base against wall (for aesthetic value and
optimum air flow, the thermostat need not be level for prop-
er operation) and mark wall through 2 of the available
mounting holes.
5. Drill two 3/16- -in. (5 mm) mounting holes in wall where
marked.
6. Secure mounting base to wall with 2 anchors and screws
provided, making sure all wires extend through hole in plas-
tic.
NOTE: Anchoring the mounting base will ensure proper
mounting and allow latch to fully engage.
7. Strip 1/4 in. insulation from thermostat wire and adjust
length to reach terminal block connector on mounting base.
Match and connect wires to proper terminal location in ac-
cordance with wiring diagrams.
8. Push any excess wire back into wall. Seal hole in wall to
prevent air leaks. Leaks can affect thermostat operation.
Any excess wire left inside thermostat casing may also af-
fect thermostat operation by interfering with airflow across
the temperature sensor.
9. Locate jumper marked J2 on circuit board. If common (C)
wire has been connected, put J2 in the "24VAC" position. If
no common wire leave J2 in the default "BATT" position.
10. Set the thermostat front housing into the (2) notches on the
bottom of the mounting plate.
11. Rotate the front housing forward and snap into place, mak-
ing sure terminal block connector aligns and assembly is se-
cure.
12. Remove the branded faceplate and insert batteries provided.
13. Replace branded faceplate.
14. Turn ON power to unit.
On power up, the LCD readout will display AC, as this is the
default equipment type.
Step 3 — Set Thermostat Configuration
Configuration options enable the installer to configure the
thermostat for a particular installation.
These selections are intended to be made at installation and
normally are not modified by the homeowner. Below is a list of
available options followed by a description of each one.
Option 01 - - Equipment type
Option 03 - - Fahrenheit/Centigrade operation
Option 04 - - Enable fan (G) on with heat W output
Option 10 - -O (reversing valve) On with Heat or cool (present
only when configured for HP applications)
Option 13 - - Room air temperature offset adjustment
Option 15 - -Auto Changeover. "OF" means AUTO Mode is off.
"ON" means AUTO MODE is on. Default = OF.
Option 21 - - Keypad Lockout
Option 26 - - Minimum Cooling Setpoint
Option 27 - - Maximum Heating Setpoint
To Enter The Configuration Mode:
Press and hold the FAN key for about 10 seconds until the display
changes so that only two pairs of digits are showing. The
configuration number, now
setpoint/temperature location and the configuration setting will
appear in the clock location. The configuration number (left pair)
will be flashing which means it can be adjusted using the UP and
DOWN keys. To cause the opposite pair to flash (to be adjustable),
press the MODE key. Successive presses of the MODE key
alternate between the configuration number (left) and the
configuration setting (right). To exit the configuration mode, press
the HOLD/END key. If no key is pressed for 3 minutes, the
configuration mode will automatically exit, returning the
thermostat to normal operation.
Option 01 - - Equipment type
Selections: HP, AC, PH, or PC
Meanings:
PH or PC selects PTAC units (Packaged Terminal Air
Conditioners) which are used in motel rooms and other rented
spaces. When this option is selected, the display shows only the
setpoint, not the room temperature. Also, the compressor
timeguard is disabled, allowing the compressor to turn on
immediately when a demand is established.
2
01, will appear in the
