TOTALINE Intellistat Owner's Manual

Combination temperature and humidity control, 2 heat - 1 cool

Hide thumbs

Table Of Contents

OWNER'S MANUAL

NTELLI

Combination Temperature

Humidity Control

i2:00

OOL

AUTO

EAT

2 HEAT - 1 COOL

TEMPERATURE & HUMIDITY

Complete Control

TOTALINE

Replacement Component Division

P/N P374-1600

TAT

and

7 Day Programmable

Technology

ICRO

ULSE

Thermoglow

One-For-All Technology

or Conventional

NTELLI

IST

Humidity Control

Read Outdoor Temperature

With Optional Sensor

Separate Humidification and

Dehumidification Terminals

Window Condensation

Control

Up to 24 gal./day @ 120 F

Plenum Temperature

from

Carrier Corporation 6/01

Backlight

Table of Contents

Summary of Contents for TOTALINE Intellistat

Page 1: Humidity Control
Read Outdoor Temperature With Optional Sensor Separate Humidification and Dehumidification Terminals Window Condensation Control 2 HEAT - 1 COOL Up to 24 gal./day @ 120 F Plenum Temperature TEMPERATURE & HUMIDITY Complete Control from TOTALINE Replacement Component Division Carrier Corporation 6/01...
Page 2: Table Of Contents
Table Of Contents FRONT PANEL DISPLAY QUICK START Set the clock and go BASIC OPERATION PROGRAMMING 4 Time Periods ADVANCED SETUP ABOUT ADVANCED OPERATION WARRANTY CAUTION Follow Installation Instructions before proceeding. SET THERMOSTAT TO MODE “OFF” PRIOR TO CHANGING SETTINGS IN SETUP OR RESTORING FACTORY DEFAULTS.
Page 3: Front Panel
Front Panel Backlit LCD Display Warmer or + Button 6:03 Cool AUTO Heat Cooler or - Button Mode Button Heat or Cool Indicator Red = Heat, Green = Cool Pressing the Humidity Shift Key will shift the button functions. The ‘upper’ labeled functions are humidity controls. NTELLI Temperature &...
Page 4: Display
Display 18:88 Program Setup Morning Night Evening SuMTuWThFSa ServiceFilter Outside AUTO Humidity OFFON Locked Mode Indicators Selects the operation mode of the equipment. HEAT - indicates the heat mode. COOL - indicates the air conditioning mode. AUTO - indicates the system will automatically changeover between heat and cool modes as the temperature varies.
Page 5 Display Outside Indication Indicates the temperature displayed is from the optional outside sensor. Page 22. Morning, Day, Evening & Night Indication Indicates the program time period. Page 9-12. Setup Indication Indicates the thermostat is in the programming mode. Page 13. Fan Operation Indication - indicates constant, continuous fan operation, (Fan On).
Page 6: Quick Start Set The Clock And Go
Quick Start Set the Clock and Go During Setup & Programming: SET CLOCK Press the SET CLOCK Pressing the Up and Down button. buttons will modify the flashing selection. 12:00 (Represented in dark black) To adjust the Press clock or Day use MODE buttons.
Page 7: Basic Operation
Basic Operation Temperature Control Select Mode 12:00 The HEAT setting indicates the temperature the room has to Heat reach before the furnace will Press MODE turn on to heat the room. 12:00 The COOL setting indicates the Cool temperature the room has to reach before the air conditioner will turn on to cool the room.
Page 8: Select Desired Temperature
Basic Operation Temperature Control Select Desired Temperature In any mode, adjust the desired Set Temperature 12:00 with Cool AUTO Heat buttons. Pressing the up/down buttons in Auto mode will adjust both the heat and cool set temperatures simultaneously. Pressing the up/down buttons in Heat or Cool modes will adjust only the heat or cool set temperature.
Page 9 Basic Operation Humidity Control Press the Humidity Button Press HUMIDITY Press Humidity Humidity Select Desired Humidity In the Humidity mode, adjust the desired Humidity Level with Humidity Humidity Setpoint buttons. NOTE: Due to variations in environmental conditions, it is not always possible to achieve the desired humidity setpoint.
Page 10: Programming
Programming 4 Time Periods Press Press the PROGRAM button to enter time period programming. PROGRAM Use the back cover Programming Worksheet to help with this section. Select the day of week (M - Su) Press MODE 6 00 Morning Adjust the start time for Morning.
Page 11 Programming 4 Time Periods 8 00 Adjust the start time for Day. Press MODE 8 00 Adjust the cooling Cool setpoint for Day. (35 - 99 ) Press MODE 8 00 Adjust the heating Cool setpoint for Day. Heat (35 - 99 ) Press MODE 6 00...
Page 12 Programming 4 Time Periods 6 00 Evening Adjust the heating Cool setpoint for Evening. Heat (35 - 99 ) Press MODE i0 00 Night Adjust the start time for Night. Press MODE i0 00 Night Adjust the cooling Cool setpoint for Night. (35 - 99 ) Press MODE...
Page 13 Programming 4 Time Periods The copy command becomes available after programming the entire previous day. 18:no Select Yes or No to copy the previous day’s program to this day. If No is selected: If Yes is selected: Selecting Yes, then pressing mode will copy the previous day’s program and then will ask the Press same copy question again.
Page 14: Advanced Setup
Advanced Setup Before entering Advanced Setup, use the Mode button to place the unit in OFF. These steps are normally set up by the installer. Setting these values incorrectly may result in improper operation. Setup steps 1 & 2 are found in the clock set section.
Page 15 Advanced Setup Setup Adjust the minimum difference between Cool cooling & heating setpoints. Heat (0 - 6 ) Press MODE Select the cycles per Setup hour limit. d=cycles per hour limit defeated. d1=d + defeat 5 min. Compressor lockout. Press (d, d1, 2 - 6) MODE Setup...
Page 16 Advanced Setup Setup Select Condensation Control for windows ON, or OFF. Page x. Press MODE Step 12 only appears if Step 9 is On 0:00 Setup Adjust the programmable fan timer. page 20 0 - 60 minutes. 0:00 = off Press MODE 7:00...
Page 17 Advanced Setup Setup Press ServiceFilter Reset the Service Filter counter to 0, to remove the icon from the display. Press MODE Setup Adjust the number of hours the blower will run before the Service ServiceFilter Filter icon appears on the display. 0 = off. (0 - 1950) Press MODE...
Page 18: Advanced Setup Table
Advanced Setup Advanced Setup Table Step # Description Range Factory Default Time of day clock set 24 hour 12:00 Am Day of the week Sun - Sat Monday Heat Pump operation Off / On Reversing valve polarity O / B Electric Heat Off / On Deadband, temperature swing...
Page 19: About Advanced Operation
About Advanced Features & Operation Technology Vs. Conventional Control - Advanced ICRO ULSE Setup Step # 9 allows the I to be configured to NTELLI control the I Humidifier or a conventional Humidifier. NTELLI Technology equipped controls for humidifiers ICRO ULSE are intelligent controls that take into account various parameters which include: HVAC equipment size, outdoor temperature,...
Page 20 About Advanced Features & Operation MULTI-STAGE OPERATION - Control up to 2 Heat, 1 Cool Stages. The 2nd Stage of heat is turned on when: (A) the 1st Stage has been on a minimum of 2 minutes and (B) the temperature spread from the setpoint is equal to or greater than: the setpoint plus the deadband, plus...
Page 21 About Advanced Features & Operation PROGRAMMABLE FAN - If the Programmable Fan timer is set to a value other than 0:00, the fan will run for the preprogrammed amount of time, page 15, step# 13. The Programmable Fan timer will start the fan at the top of each hour.
Page 22 About Advanced Features & Operation DUAL SETPOINT BEHAVIOR - The adjustable setpoint range is: 35 - 99 degrees in Fahrenheit and 2 - 36 degrees in Centigrade. When in the modes Heat or Cool, this adjustable range is unhampered. When adjusting any Auto mode, including programming 4 Time periods, the thermostat will not allow the Heat setpoint to get closer to the Cool setpoint...
Page 23 About Advanced Features & Operation OUTDOOR SENSOR (Optional Accessory) - When connected to terminals RS+5, RS1, & RS GND on the back of the thermostat, the thermostat will read the temperature from the Outdoor Sensor when asked to. This thermostat will not control to this sensor, it is only to read outside temperature.
Page 24 On these circuit boards DEHUM is connected to R to allow high speed fan and disconnected to force low speed fan. The Intellistat signal Y2 connected to DEHUM will keep the fan in high speed unless there is a 1st stage cooling demand, the humidity control is ON, AND the room humidity is ABOVE the humidity setpoint.
Page 25: Warranty
Warranty One-Year Warranty - This Product is warranted to be free from defects in material and workmanship. If it appears within one year from the date of original installation, whether or not actual use begins on that date, that the product does not meet this warranty, a new or remanufactured part, at the manufacturer’s sole option, to replace any defective part will be provided without charge for the part itself;...
Page 26 Programming Worksheet see page 9 DAY PERIOD START TIME COOL HEAT Morning Evening Night Morning Copy Mon Evening Night Morning Copy Tue Evening Night Morning Copy Wed Evening Night Morning Copy Thu Evening Night Morning Copy Fri Evening Night Morning Copy Sat Evening Night...
