TOTALINE P700U-21NHP Installation Instructions Manual

US patents: US20060165149 A1, USD578026 SI, US6205041 B1
Base Non ---Programmable Thermostat
NOTE: Read the entire instruction manual before starting the
installation.

TABLE OF CONTENTS

SAFETY CONSIDERATIONS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTALLATION CONSIDERATIONS
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Step 1 - Thermostat Location
Step 2- Install Thermostat
Step 3 - Set Thermostat Configuration
Step 4 - Thermostat Operation
Step 5 - Check Thermostat Operation
WIRING DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SAFETY CONSIDERATIONS

Improper installation, adjustment, alteration, service, maintenance,
or use can cause explosion, fire, electrical shock, or other
conditions which may cause death, personal injury, or property
damage. Consult a qualified installer, service agency, or your
distributor or branch for information or assistance. The qualified
installer or agency muse use factory- -authorized kits or accessories
when modifying this product. Refer to the individual instructions
packaged with the kits or accessories when installing.
Base Non- -Programmable Thermostats
Installation Instructions
Designed and Assembled
in the USA.
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
Follow all safety codes. Wear safety glasses, protective clothing,
and work gloves. Have a fire extinguisher available. Read these
instructions thoroughly and follow all warnings or cautions
included in literature and attached to the unit. Consult local
building codes and the current editions of the National Electrical
Code (NEC) NFPA 70.
In Canada, refer to the current editions of the Canadian Electrical
Code CSA C22.1.
Recognize safety information. This is the safety- -alert symbol
When you see this symbol on the unit and in the instructions or
manuals, be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, and
CAUTION. These words are used with the safety- -alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies a hazard
which could result in personal injury or death. CAUTION is used
to identify unsafe practices which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability, or
operation.
A14005
The Base thermostat is an electronic 24VAC, non- -programmable,
manual changeover wall mount thermostat. This thermostat uses a
single setpoint to maintain and control room temperature in both
the heating and air conditioning modes. The thermostat is designed
PAGE
to maintain +/- - 2_F accuracy. No batteries are required;
temperature, fan, mode, and installer configuration settings are
1
preserved with power off.
1

INSTALLATION CONSIDERATIONS

1
Universal Model
2
The P700U- -21NHP Base thermostat may be configured for either
2
AC models or HP models. When configured as an AC model, it
2
may be wired with or without connecting a common wire between
the indoor equipment and the thermostat. However, it is
2
recommended to use a common wire whenever possible. Without a
3
common wire this thermostat becomes "power stealing." This
3
means it will need to steal a small amount of power from the
equipment to which it is connected.
4
NOTE: Not all HVAC equipment is compatible with power
stealing type thermostats. All Carrier equipment is directly
compatible with this thermostat except the Thermostat Conversion
Kit, Part #TSTATXXCNV10. For all non- -Carrier equipment,
consult the system equipment Installation Instructions before
applying this thermostat in a power stealing manner.
When configured for HP units, it is NOT power stealing and
MUST have both the R and C terminals connected to operate
properly. This thermostat uses a green LED to indicate auxiliary
heat and emergency heat operation.
P700U- -21NHP

INTRODUCTION

.
