Heating Operation
1. Press MODE button until HEAT is displayed.
2. Press UP button until LCD readout reads 3_F/2_C above
room temperature. Press UP and FAN buttons simultane-
ously to defeat timers. Heating system should begin to oper-
ate immediately.
3. For HP applications only, press MODE button until EMHT
(emergency heat) appears. Press UP and FAN buttons si-
multaneously to defeat timers. Emergency heating (W is
ON, Y is OFF) should begin immediately.
EQUIPMENT
CONFIGURATION OP-
TION #1
AC, PC
HP , PH
RVS = C
HP , PH
RVS = H
Fig. 1 - - A/C Thermostat Typical Installation
Replacement Components, Carrier Corporation
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
Table 1 – Outputs
COOL
STAGE 1
Y, G
Y, G, O/B
Y,G

WIRING DIAGRAMS

A06566
www.totaline.com Edition Date: 02/14
Cooling Operation
1. Press MODE button until COOL is displayed.
2. Press DOWN button until LCD readout reads 3_F/2_C be-
low room temperature. Press UP and FAN buttons simulta-
neously to defeat timers. Cooling system should begin to
operate immediately.
Table 1 shows the thermostat outputs for each available stage of
heating or cooling. It may be useful in checkout or
troubleshooting.
HEAT
STAGE 1 STAGE 2
W
Y, G Y, G, W
Y, G, O/B Y, G, W, O/B
Fig. 2 - - HP Thermostat Typical Installation
U.S. Export Classification: EAR99.
4
HEAT
EM HEAT
--- --- --- ---
Catalog No: RCIIP710U ---21PHP---03
Replaces: RCIIP710U--- 21PHP--- 02
W
W
A06567
