STEP 2 (See Diagram 2)
A.) Attach the Vertical Frame (#2) onto the Main Frame (#1). Secure them with two M10 x 2 ¾"
Carriage Bolts (#46), one 5 ½" x 2" Bracket (#12), two Ø ¾" Washers (#59), and two M10
Aircraft Nuts (#56).
B.) Slide 14 Weight Plates (#40) onto the Guide Rods (#10). Make sure the deep grooves on the
Plates all face down and toward to the back of the machine. Insert a Selector Rod (#9) into
the center hole on the Plates. Slide the Selector Stem (#39) onto the Guide Rods. Use the
Weight Selector Pin (#38) to select the number of Wight Pates to exercise. Please refer to
the Weight Resistance Chart in page-19.
C.) Attach the Upper Frame (#3) in between the two Guide Rods. Secure each Guide Rod to
Upper Frame with one M10 x 1 ¾" Allen Bolt (#54) and Ø ¾" x Ø ½" Curved Washer (#61).
D.) Place the Upper Frame onto the Vertical Frame. Secure it with two M10 x 2 ¾" Carriage
Bolts (#46), one 5 ½" x 2" Bracket (#12), two
Nuts (#56).
E.) Securely tighten all Nuts and Bolts installed in Step-1 and Step-2.
F.) Attach the Leg Developer (#7) to the Front Post (#6). Secure it with one M12 x 3 1/8" Allen
Bolt (#49), two Ø 1" Washers (#60), and one M12 Aircraft Nut (#57).
¾" Washers (#59), and two M10 Aircraft
