- Page 1 61cm (24") FULL HD LED TV with DVB-T/-C/-S2 & CI+ Slot Model No.: LED-2419 BLACK Please read and follow these instructions before using your unit. www.lenco.com...
- Page 3 Caution The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of un-insulated “dangerous voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
-
Page 4: Safety Information
Safety Information To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below . Electrical safety • To prevent overload, don't share the same mains supply socket with too many other items of equipment. -
Page 5: Technical Specification
Accessories POWER MUTE PICTURE SOUND ASPECT SLEEP SUBTITLE CH.LIST TV/RADIO INPUT MENU EXIT DISPLAY REC.LIST TV/TXT CANCEL REVEAL NICAM/A2 INDEX HOLD SIZE SUBPAGE Batteries Converter cable for User’s Manual Remote control for Remote AV and YPbPr video Control Mains adapter * Note: The configuration of the components may look different from the following illustration Technical Specification - TV System... -
Page 6: Product Introduction
Product Introduction Introduction Front View POWER to turn on and off. Blue off Null INPUT: MENU: CH+/-: Press to scan through channels. VOL+/-: POWER:... - Page 7 Connections switch POWER HDMI PC-IN SCART COAX Switch: Switch on/off the power supply. POWER: Connect to the mains adaptor. HDMI: Connect it to the HDMI of DVD or other equipment. VGA: For PC display.Connect it to the D-Sub 15 pins analog output connector of the PC. PC-IN: Connect it to the audio output terminal of PC.
-
Page 8: Remote Control
Remote Control POWER MUTE MUTE: Press to mute the sound, press again or press VOL+ to unmute. PICTURE: Select the picture mode. PICTURE SOUND ASPECT SLEEP SOUND: Select the sound mode. ASPECT: Change the screen display mode. SUBTITLE CH.LIST SLEEP: Standby timer. TV/RADIO INPUT CH.LIST: Display the channel list. - Page 9 Remote Control POWER MUTE PICTURE SOUND ASPECT SLEEP SUBTITLE CH.LIST TV/RADIO INPUT VOL+/-: Adjust the volume. CH / : Scan through channels. : Press to start record the program in DVB mode. EXIT REC . LIST: Record List. : Play/Pause program. : Stop program.
-
Page 10: Basic Operation
Basic Operation Power on/off 1. Connect to the power supply with the adaptor. 2. -To turn on the TV Press POWER button on the TV or remote control. -To turn off the TV Press POWER button on the TV or remote control. Input Source select Press INPUT button on the TV set or remote control to display the input source menu, and use CH+/- button on the TV set or /\/v button... -
Page 11: Osd Menu
OSD Menu 1. Picture menu Description Picture Mode: Select your desired picture mode from Dynamic, Standard, Mild and User. Brightness: Adjust image black level. Contrast: Adjust image contrast. Sharpness: Adjust the sharpness(Gray and invalid in VGA/PC mode). Colour: Adjust image colour from black and white. Tint: Control the tint ( NTSC mode only). - Page 12 OSD Menu Sound menu Description Sound Mode: Select your desired sound mode from Standard, Movie, Music, Speech and User. Bass: Adjust the level of the lower-pitched sounds. Treble: Adjust the level of the higherpitched sounds. Balance: Adjust the audio output between left and right speakers. Surround: Turn on/off the surround sound function.
- Page 13 OSD Menu 3. Channel menu(In ATV/DTV mode) Channel Management: Enter the Channel management menu to edit the channels. Move Delete: Press RED button to sign the channels you want to delete, it will hint you when you exit. Lock: User must set the “Lock enable”(Feature-Lock- Lock enable) at ON to active this function. Press GREEN button to sign(lock) or cancel(unlock) the channel.
- Page 14 OSD Menu Country : Select the country. TV Connection: Select DTV type, you can choose Air(DVB-T), Cable(DVB-C), Satellite(DVB-S2), as you like. Auto Search: Press OK button to enter the Auto Search menu, select search mode, and press OK button to start auto search. Note: 1.ALL: Auto search channels for DTV, ATV and Radio.
- Page 15 OSD Menu Satellite System Press button to select the “TV Conection” , and set it on “Satellite”. Select “Auto Search” as follow: Operations in satellite Auto Search menu are shown in the following table Option Value Mode Default,Network Search,Full Search Satellite 65 satellite for searching(3 user edit satellite) Service Type...
-
Page 16: Satellite System
OSD Menu Satellite System Press button to select the “TV Conection” , and set it on “Satellite”. Press button to select the “Satellite System” , show as follow: Operations in Satellite List Menu are shown in the following table: Key Stroke Action KEY_UP use cursor to up... - Page 17 OSD Menu Feature menu Lock: This menu allows you to lock certain features of the television so that they can not be used or viewed. For example if you don’t want certain channels viewed by children or if the television is to be used in a hotel and you want certain channels be locked. When you enter the system lock menu you will be asked for a password.
- Page 18 OSD Menu Hotel Mode - Enter the Hotel Setting menu. Hotel Lock: Turn on/off the Hotel Lock function. Channel Lock: Disable the Channel menu in OSD. Picture Lock: Disable the Picture menu in OSD. Sound Lock: Disable the Sound menu in OSD. Feature Lock: Disable the Feature menu in OSD.
-
Page 19: Setup Menu
OSD Menu SETUP menu OSD Timer: Lets you adjust the amount of time the On Screen Menu stays on the screen before disappearing. Auto SCART: The TV will be changed to SCART source automatically when you connect the TV to the SCART device. PC Setup: Change the PC Settings in PC mode. -
Page 20: Multimedia Operation
Multimedia Operation Basic Operation 1). Press the INPUT button on the remote control to display the input source menu, select Media source by the buttons, and press OK button to enter the Multimedia menu as shown below. 2). Insert USB device, and select the Media mode form Photo, Music, Movie and eBook, then you will find the name of the device display on the screen as shown below. - Page 21 Multimedia Operation 1. Photo Play the photo Press button to select the option on the table, and press OK button to change. Note: You could press OK button to display the option table when it disappears. Play/Pause the photo playing. Stop and exit the full screen program.
- Page 22 Multimedia Operation 3. Movie Play the movie Press button to select the option on the table, and press OK button to change. Note: You could press OK button to display the option table when it disappears. Play/Pause the movie playing. Stop and exit the full screen program.
-
Page 23: Recording Operation
Recording Operation PVR settings Press the MENU button select Feature-PVR/Timeshift menu, press OK button to enter the menu as below. 1). Record File Format Select Record File Format mode from TS and PS for storing in the USB device. 2). Partition Select USB device informations Format: Press RED button to format the selected USB device. - Page 24 Recording Operation 5). Record List Display the Record list menu. Delete: Press RED button to delete the selected record plan. 6). Recorder Start Press OK button to start recording, as the function of the REC button on the remote control.
- Page 25 Recording Operation Recording Press REC button on the remote control to start recording in DTV mode, and the TV will give you a hint. Select “OK” item, and press OK to start recording, there will be a sign on the screen. Note: a.
- Page 26 LED-2419 BLACK LENCO 2011...
-
Page 27: Service And Support
The helpdesk is accessible from Monday till Friday from 9 AM till 6 PM. When contacting Lenco, you will always be asked for the model and serial number of your product. The serial number can be found on the back of the device. Please write down the serial number below:... - Page 28 Electrical and Electronic Equipment Directive). Products with the CE marking comply with the EMC Directive (2004/108/EC) and the Low Voltage Directive (2006/95/EC) issued by the Commission of the European Community. The declaration of conformity may be consulted at http://www.lenco.eu/supportfiles/CE/pjkohgtrd415643dffd.pdf ®All rights reserved...
