- Page 1 S i R ob e r t s on S i g n a t u r e E d i t i on T R E A S U R E C OM M A N D E R T C 2 X M e t a l D e t e c t or T C 2 X Op e r a t i n g M a n u a l...
-
Page 3: Table Of Contents
Using the GPS Function ....................11 Getting Started the Right Way ..................12 Let's Find Something .......................13 Target Recovery ......................14 Detecting Tips .........................14 Care & Maintenance .......................15 Troubleshooting ......................16 Treasure Commander TC2X Specifications ..............17 Treasure Hunters Code of Ethics ..................17 Warranty & Service Information ..................18... -
Page 4: Congratulations
Your Treasure Commander TC2X is capable of meeting your needs in a wide range of treasure hunting situations. As with any other metal detector, familiarity with this instrument is probably the limiting factor in determining how successful you can be. I recommend that you read this manual and fully understand how to operate this detector before attempting to use it in the field. -
Page 5: Getting Started
Getting Started Your Treasure Commander TC2X comes complete and ready to use. The first step is to unpack the box and check to make sure you have all the items needed to quickly assemble the detector. You should find the following parts inside the box: ... - Page 6 Align the grooves to ensure the rods remain properly positioned. Connect the Search Coil Cable to the Control Housing: The Treasure Commander TC2X's search coil cable is run through the inside of the bottom and top rods which keeps it from being caught by branches underbrush...
- Page 7 Replace the battery compartment cover and tighten the screws. Either standard AA or rechargeable AA batteries can be used on the TC2X. Alkaline AA batteries are recommended for optimal performance and service life.
-
Page 8: Understanding The Lcd Display
Categories of commonly found targets - treasure and trash - are provided on the screen. The following figure shows what types of targets will register in each of the eight segments. A useful function on the TC2X is the ability to accept or reject any... - Page 9 of the segments independently from each other allowing you to quickly and easily create a custom program designed to handle any conditions you might come across in the field. It is important to note that the eight segments capture commonly found targets but not all targets you might come across are listed.
-
Page 10: Touchpad Operation
GPS function is selected. It will be covered in more detail later in the manual. Touchpad Operation While the Treasure Commander TC2X offers a high level of performance under a wide range of conditions, all of its functions are controlled through the use of just seven (7) touchpads. - Page 11 GPS: This touchpad scrolls down when in a menu screen or activates the GPS function (described in a later section of the manual). DIS: This touchpad scrolls to the right when in a menu screen or returns the TC2X to the normal discriminating search mode after activating the SETTINGS or PINPOINT functions.
-
Page 12: Operating Modes
GROUND GRAB (Ground Balance): All soil contains minerals which can impact the ability for any metal detector to locate small or deeply buried targets. The TC2X has been designed to sense the actual ground mineralization present at the search location and automatically calibrate itself to reduce or eliminate the effect the mineralization would otherwise have on detection depth and sensitivity. - Page 13 NOTCH DISCRIMINATION allows you to only reject the pull tab segment while still accepting the other seven segments. The TC2X comes with three predefined programs along with one that can be customized to meet your specific needs. The Treasure Commander’s programs include: ...
-
Page 14: Identifying Targets Before You Dig
Identifying Targets Before You Dig The Treasure Commander TC2X provides you with two ways to identify targets before recovering them. The first is the indication on the LCD screen via the eight Metal Category segments. In addition to the visual indication, the audio response will vary based on the type of metal that has been located. -
Page 15: Getting Started The Right Way
Getting Started the Right Way Spending a little time getting familiar with the response of your Treasure Commander TC2X before you head out in search of treasure will make your time in the field more enjoyable and productive. The first activity you should try is to perform bench testing using a sample of targets. -
Page 16: Let's Find Something
Let's Find Something So you have spent some time getting familiar with your new Treasure Commander TC2X detector and are ready to head out and see what you can discover. Let's get started! 1. Extend the rods to the desired length. -
Page 17: Target Recovery
8. Carefully recover the target and be sure to replace the soil / grass before moving on to the next target. Target Recovery Once you have established the exact location of the target, the next step is to dig a small hole to recover it. -
Page 18: Care & Maintenance
Keep your search coil slightly off of the ground during the sweep, especially when using in gravel or hard, rocky dirt. Care & Maintenance Your Treasure Commander TC2X has been built to last but proper care and maintenance will ensure you receive years of trouble free operation. It is recommended that you observe the following tips. -
Page 19: Troubleshooting
Keep it Cool - Never keep your detector in an extremely hot environment such as the trunk of your vehicle in the summer for extended periods of time. Damage to the electronics and the LCD display screen can occur. ... -
Page 20: Treasure Commander Tc2X Specifications
Treasure Commander TC2X Specifications Licensed RealTree Xtra Camo Finish GPS Technology (GEO-X) allows saving and locating up to 10 locations Durable lightweight poly carbonate construction Large simple to use digital backlit interface 8 metal categories and adjustable discrimination ... -
Page 21: Warranty & Service Information
I Will Not litter and will pick up any trash that I dig up or find on the ground while treasure hunting. I Will leave gates as found. I Will Not contaminate wells, creeks, or other water supplies. ... - Page 22 L E A R N E V E R Y T H I N G A B O U T ME T A L D E T E C T I N G A T K E L L Y C O ’ S N E W O N L I N E L I B R A R Y G o o d f o r y o u r h e a l t h , f u n , f a mi l y o r i e n t e d h a s E v e r y me t a l d e t e c t o r u s e r h a s p o n d e r e d t h e s e ! e x t e n d e d t o a l mo s t t w e n t y !
- Page 23 Notes:...
- Page 24 Available From: Visit us at: www.kellycodetectors.com Call Us Toll Free At: 1-888-535-5926 1085 Belle Avenue, Winter Springs, FL 32708...
