Medema Mini Crosser M1 Service Manual page 91

Mini Crosser M1-4W
El-dele for S-180 styring
Electric parts for S-180 Controller
Pos. Del/part no.
1 E-130-5-007
2 M-127-03-006
3 M-127-03-022
4 M-127-03-024
5 M-127-5-015
6 M-127-5-019
7 M-127-5-040
8 M-127-5-041
9 M-127-5-042
10 M-127-5-045
11 M-127-5-049
12 M-127-5-056
13 SR-00066
14 SR-00070
15 SR-00232
16 SR-00978
17 SR-03969
18 SR-04803
19 SR-05219
20 T-127-05-003
21 T-127-05-004
22 T-127-1-008
23 T-127-3-010
24 T-127-3-090
25 T-127-5-006
26 T-127-5-008
27 T-127-5-014
28 T-127-5-045
29 T-127-5-109
Benævnelse
Mellemkabel, batteri
Brugerpanel komplet
Forlygte. komplet 4w
Forlygte. komplet 3w
Rød diode baglygte, klar linse
Gul diode blinklygte, klar linse
Hovedkabel, Solo styring
Kabel, blinklys for
Kabel, for reduceret hastighed
Kabel, baglys
Kabel batteri - styring S-180
Kabel for styring S-180
Sikring 5A
Pære 5W
Horn, signal til T-modeller (version 2)
Littelfuse MEGA 100A
Sikring 10A
S-Drive 180A Styring
Sealing kit for S-180
Potentiometer, CURTIS komplet, højre
Potentiometer, CURTIS komplet, venstre
Brugerpanel indækning
Silikonemåtte blink, horn
Nøgle + nøgleafbryder
Lys / katastrofe kontakt T
Print, blinklys og horn med kabel
Ladestik, incl kabel/stik T
Kabel blinklys T
Pot. med ledning, 100K
Part name
Cabel, between battery
User panel cover compl
Headlamp. complete 4w
Headlamp. complete 3w
Read LED rear light, Clear lens
Yellow LED light, Clear lens
Cable, Main for Solo controler
Cabel, fl ashing lights front
Cable, for reduced speed
Cable, rear light
Cable battery - Controler S-180
Cable for controler S-180
Fuse 5A
Lamp 5W
Horn, signal (version 2)
Littelfuse MEGA 100A
Fuse 10A
S-Drive 180A Controler
Sealing kit for S-180
Potentiometer, CURTIS complete,
right
Potentiometer, CURTIS complete, left
User panel cover
Silicone mat winker lamp,horn
Key + switch
Light / hassard
Print, Winker and horn with cable
Chargeplug with cabel T
Kabel blinker T
Speed limiting, 100K
medemagruppen
Antal/
quant.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
15 / 20
