Medema Mini Crosser M1 Service Manual page 71

Mini Crosser M1-3W
Skærme - grå metalic
Covers - grey metalic
Pos. Del/part no.
1 CR-00067
2 M-127-01-021
3 M-127-01-023
4 M-127-01-024
5 M-127-01-030
6 M-127-1-001
7 M-127-1-007
8 M-127-1-011
9 M-127-1-012
10 M-127-1-022
11 M-127-2-047
12 M-127-2-089
13 M-127-3-025
14 M-127-3-028
15 SR-00090
16 SR-00594
17 SR-01085
18 SR-03396
19 SR-03981
20 SR-04798
21 SR-05196
22 T-127-1-012
23 T-127-1-016
24 T-127-3-106
Benævnelse
Håndgreb M8x20 - Ø40
Fodmåtte med blindnitter, 3W
Batterikåbe lang model (Grey metallic)
Batterikåbe kort model (Grey metallic)
Skærm for styrstolpe, forand (Grey metal-
lic)
Fodpladekåbe 3w
Kåbe bagende
Inderskærm højre bag
Inderskærm venstre bag
Lygtekåbe 3W (Grey metallic)
Sidebumper 3/4w
Gummiemne centerrør
Dafacell 25x20x80 med klæb
Gummiprofi l med topvulst, EPDM, 3-5
mm
Refl eks orange
Refl ektor rød
Polyamid skive Ø8 - Ø24 - 2
Batterirem
Ø5 x 25 Blindnitte RH polyamid 6.6
Refl eks Ø60 Hella 8RA 002 014-041
4,8 x 12,7 Blindnitte med stor fl ange, Alu
Skærm f. styrestolpe bag
Afdækning ladestik gummi profi l
Prop gummi for hul ø19
Part name
Threaded knop M8x20 Ø40
Foot mat with blind rivets, 3W
Battery cover long, complete. (Grey
metallic)
Battery cover short, complete. (Grey
metallic)
Cover steering column front (Grey
metallic)
Footplate cover 3w
Cover rearend
Mudguard cover rear right
Mudguard cover rear left
Frontlight cover 3W (Grey metallic)
Bumper 3/4w
Rubberpart for centertube
Dafacell 25x20x80 with adhesive
Rubber profi le EPDM, 3-5 mm
Refl ector orange
Refl ector red
Polyamid washer Ø8 - Ø24 - 2
Battery band
Ø5 x 25 Blind rivets polyamid 6.6
Refl eks Ø60 Hella 8RA 002 014-041
4,8 x 12,7 Blind rivet with large
fl ange, alu
Cover steering column behind
Cower charge plug rubber profi le
Plug rubber for hole ø19
medemagruppen
Antal/
quant.
1
1
1
1
1
1
1
1
1
1
2
1
2
2
1
1
1
2
1
1
4
1
1
1
