Led Status Indication; Residential Wifi Modem - Maxis Modem Manual

Table 1: LED status indication 1
LED
LAN1 - LAN4
POWER
PON
LOS
(PON - Passive Optical Network, LOS of Signal, LAN-Local Area Network)
Table 2: LED status indication 2
No
PON
1 Off
2 Blinking
3 On
4 Off
5 Blinking
(PON - Passive Optical Network, LOS - Loss of Signal)

Residential WiFi modem

As there are different models being used, your actual unit may differ from
visual below.
Model
TG784nv3
Figure 2: Top view of the Residential WiFi modem
14
Status Description
On Ethernet connection is normal.
Blinking Data is being transmitted through the Ethernet port.
Off Ethernet connection is not set up.
Green The device is powered on.
Off The device is powered off.
Refer to table 2
Refer to table 2
Status
LOS
Off
Off
Off
Blinking
Blinking
Service Broadband Internet
Description
For a successful connection, the "PON" has to
be On and the "LOS" has to be Off. Otherwise,
please contact our Customer Service.
Wireless WPS Ethernet Voice 1 Voice 2
