description of
LED lights on
equipment

Optical Network Terminal (ONT) / Broadband Termination Unit (BTU)

As there are different models being used, your actual unit may differ from
visual below
Figure 1: Top view of the ONT / BTU
TEL2 TEL1 LAN4 LAN3 LAN2 LAN 1 LOS PON Power
13
