HBDV7 Series
Direct Vent Gas Fireplace
Models:
HBDV300N/PV7, HBDV400N/PV7
HBDV300N/PSC7, HBDV400N/PSC7
WARNING
IF tHe INFoRMAtIoN IN tHeSe INStRuCtIoNS IS
Not FolloWeD exACtly, A FIRe oR exPloSIoN
MAy ReSult CAuSING PRoPeRty DAMAGe,
PeRSoNAl INjuRy oR loSS oF lIFe.
–
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
–
WHAt to Do IF you SMell GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
–
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WARNING: Improper installation, adjustment,
alteration, services or maintenance can cause
injury or property damage. Refer to this manual.
For assistance or additional information consult
a qualified installer, service agency or the
gas supplier.
this appliance may be installed in an aftermarket*,
permanently located, manufactured home (uSA
only) or mobile home, where not prohibited by
local codes.
this appliance is only for use with the type of gas
indicated on the rating plate. this appliance is
not convertible for use with other gases, unless a
certified kit is used.
* Aftermarket: Completion of sale, not for purpose of resale, from
the manufacturer.
Homeowner's
Installation &
Operating
Instructions
Due to HIGH teMPeRAtuReS, tHe APPlIANCe
SHoulD Be loCAteD out oF tRAFFIC AND AWAy
FRoM FuRNItuRe AND DRAPeRIeS.
CHIlDReN AND ADultS SHoulD Be AleRteD to
tHe HAZARDS oF HIGH SuRFACe teMPeRAtuRe
AND SHoulD StAy AWAy to AVoID BuRNS oR
ClotHING IGNItIoN.
youNG CHIlDReN SHoulD Be SuPeRVISeD
WHeN tHey ARe IN tHe SAMe RooM AS tHe
APPlIANCe.
ClotHING oR otHeR FlAMMABle MAteRIAl
SHoulD Not Be PlACeD oN oR NeAR tHe
APPlIANCe.
KeeP tHe RooM AReA CleAR AND FRee FRoM
CoMBuStIBle MAteRIAlS, GASolINe, AND
otHeR FlAMMABle VAPoRS AND lIquIDS.
INStAlleR: leave this manual with the appliance.
CoNSuMeR: Retain this manual for future reference.
548000
HBDV7 cover
54D8000 7/11 Rev. 6
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Monessen Hearth HBDV300N
Summary of Contents for Monessen Hearth HBDV300N
-
Page 1: Operating Instructions
HBDV7 Series Direct Vent Gas Fireplace Models: HBDV300N/PV7, HBDV400N/PV7 HBDV300N/PSC7, HBDV400N/PSC7 WARNING IF tHe INFoRMAtIoN IN tHeSe INStRuCtIoNS IS Not FolloWeD exACtly, A FIRe oR exPloSIoN MAy ReSult CAuSING PRoPeRty DAMAGe, PeRSoNAl INjuRy oR loSS oF lIFe. – Do not store or use gasoline or other flammable Homeowner’s... -
Page 2: Table Of Contents
CoNteNtS HBDV7 Series Direct Vent Gas Fireplace thank you and congratulations on your purchase of a Monessen Fireplace. PleASe ReAD tHe INStAllAtIoN AND oPeRAtIoN INStRuCtIoNS BeFoRe uSING tHe APPlIANCe! IMPoRtANt: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: Important Safety Information
IMPoRtANt SAFety INFoRMAtIoN HBDV7 Series Direct Vent Gas Fireplace oWNeR INStAlleR Please retain these instructions for future reference. Please leave these instructions with the appliance. • Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. •... -
Page 4: Code Approval
IMPoRtANt SAFety INFoRMAtIoN HBDV7 Series Direct Vent Gas Fireplace 1. Do not use this fireplace to cook food or burn paper or IMPoRtANt: other objects. PleASe ReAD tHe FolloWING 13. Never place anything on top of fireplace. CAReFully 14. Do not use any solid fuels (wood, coal, paper, card- board, etc.) in this fireplace. -
Page 5: Product Features
PRoDuCt FeAtuReS and GAS SPeCIFICAtIoNS HBDV7 Series Direct Vent Gas Fireplace GAS SPeCIFICAtIoNS & oRIFICe SIZe PRoDuCt SPeCIFICAtIoNS • This appliance has been certified for use with either Max.Input Min. Input Orifice natural or propane gas. Refer to appropriate data Model Fuel BTU/h... -
Page 6: Fireplace & Framing Dimensions
FIRePlACe DIMeNSIoNS and FRAMING DIMeNSIoNS HBDV7 Series Direct Vent Gas Fireplace Min. Rough Opening Depth 1/2” or 5/8” P - Min. Rough Opening Width Insulation Board Min. Rough (Do not remove) Opening Height 1/2” 5/8" Figure 2 - 3 ” Fireplace and Framing Dimensions 8 ” HBDV300 HBDV400 33Z\zn” (840 mm) 37Z\zn” (941 mm) 9M\,”... -
Page 7: Fireplace Location
PRe-INStAllAtIoN INFoRMAtIoN HBDV7 Series Direct Vent Gas Fireplace FIReBox FRAMING Firebox framing can be built before or after the appliance is set in place. Refer to Figure 2 for fireplace and framing Do not fill spaces around firebox with dimensions. Construct firebox framing following Figure 2 insulation or other materials. -
Page 8: Clearances
CleARANCeS HBDV7 Series Direct Vent Gas Fireplace CleARANCeS to CoMBuStIBleS Follow these instructions carefully to ensure safe installation. Failure to follow instructions exactly can create a fire hazard. the appliance cannot be installed on a carpet, tile or other combustible material other than wood flooring. -
Page 9: Secure Fireplace To Floor Or Framing
SeCuRe FIRePlACe to FlooR or FRAMING HBDV7 Series Direct Vent Gas Fireplace The fireplace must be secured to the floor and/or to framing studs as shown in Figure 6. Use two () wood screws or masonry/ concrete screws to secure fireplace to the floor. Use four (4) screws to attach fireplace to framing. -
Page 10: Optional Top Vent Application
oPtIoNAl toP VeNt APPlICAtIoN HBDV7 Series Direct Vent Gas Fireplace oPtIoNAl toP VeNt APPlICAtIoN After conversion to top vent configuration, The appliance is shipped as a rear vent unit. If the installa- the 4” (102 mm) flue pipe should be tion layout requires the unit to be a top vent configuration concentric within the 6B\,”... -
Page 11: Venting Installation
VeNtING INStAllAtIoN INFoRMAtIoN HBDV7 Series Direct Vent Gas Fireplace Read all instructions completely and thoroughly before attempting installation. Failure to do so could result in serious injury, property damage or loss of life. operation of improperly installed and maintained venting system could result in serious injury, property damage or loss of life. -
Page 12: Termination Location
VeNtING INFoRMAtIoN HBDV7 Series Direct Vent Gas Fireplace GeNeRAl VeNtING INFoRMAtIoN - teRMINAtIoN loCAtIoN INSIDE CORNER DETAIL G V H A D E L C B B V Fixed B V Closed V Fixed Operable Closed F V B M V B ... -
Page 13: Termination Clearances
VeNtING INFoRMAtIoN HBDV7 Series Direct Vent Gas Fireplace Termination Clearances Termination clearances for buildings with combustible and noncombustible exteriors. Inside Corner Alcove Applications* Outside Corner Combustible 6" (152 mm) Combustible 6" (152 mm) Noncombustible 2" (51 mm) Noncombustible 2" (51 mm) Balcony - Balcony - with no side wall... -
Page 14: Vent Graph
VeNtING INFoRMAtIoN HBDV7 Series Direct Vent Gas Fireplace tWISt loCK PIPeS When using twist lock pipe it is not necessary to use sealant on the joints. To join twist lock pipes together, simply align the beads of the male end with the grooves of the female end, twisting the pipe until the flange on the female end contacts external flange on the male end. -
Page 15: Vent Pipe Clearances
VeNt INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace Horizontal sections of this vent system this fireplace must be vented to the require a minimum of 3” clearances to outside. the venting system must NeVeR combustibles at the top of the flue and 1” be attached to a chimney serving a clearance at the sides and bottom until separate solid fuel burning appliance. -
Page 16: Rear Wall Vent Applications & Installation
VeNtING INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace ReAR WAll VeNt APPlICAtIoN Vent opening for Combustible Walls 9B\,” When installed as a rear vent unit this appliance may be (44 mm) Min. vented directly to a termination located on the rear wall behind the appliance. -
Page 17: Top Vent Sidewall Applications & Installation
VeNt INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace Finish Wall Vent Rise Termination FP147 Figure 21 - There must be a 1/2" rise per foot length toP VeNt SIDeWAll APPlICAtIoN Figure 19 - FP94 Note: For all top vent installations where a 90° elbow is Side View of Final Unit Location the first pipe piece towards a sidewall termination (up and FP1472... - Page 18 VeNtING INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace • The maximum number of elbow degrees in a system is When installing the appliance as a rear vent unit, the 70°. Figure 27 90° or 45° transition elbow attached directly to the Example: Elbow 1 = 90°...
-
Page 19: Vertical Sidewall Installation
VeNtING INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace VeRtICAl SIDeWAll INStAllAtIoN - tWISt loCK PIPe Step 1 Locate vent opening on the wall. It may be necessary to first position the fireplace and measure to obtain hole lo- cation. Depending on whether the wall is combustible or noncombustible, cut opening to size. - Page 20 VeNtING INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace Step 7 Guide the vent terminations 4” and 7” collard into their respective vent pipes. Double check that the vent pipes overlap the collars by ” (51 mm). Secure the termina- 4” Flex Vent Pipe tion to the wall with screws provided and caulk around 12"...
-
Page 21: Below Grade Installation
VeNtING INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace BeloW GRADe INStAllAtIoNS 6. Slide the snorkel into the vent pipes and secure to the wall. When it is not possible to meet the required vent terminal 7. Level the soil so as to maintain a 4" clearance below clearances of 1"... -
Page 22: Vertical Through-The-Roof Installation
VeNtING INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace VeRtICAl tHRouGH-tHe-RooF INStAllAtIoN Note: For all top vent vertical through-the-roof instal- Max.Height 40’ (1.. m) lations, install the supplied cross-bar flue restrictor, part Min. Height #69D3006 onto the top edge of the firebox flue adapter. 8’... - Page 23 VeNtING INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace 10. Add additional vent lengths for proper height. Figure Horizontal Overhang 11. Apply high temperature sealant to 4” and 7” collars of vertical vent termination and install. 2 ft. 2 ft. Min. If there is a room above ceiling level, fire stop spacer must Min.
-
Page 24: Check Gas Type
FIRePlACe INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace CHeCK GAS tyPe Use proper gas type for the fireplace you are installing. If you have conflicting gas type, do not install fireplace. See dealer where you purchased the fireplace for proper fireplace for your gas type or conversion kit. - Page 25 FIRePlACe INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace A manual shutoff valve must be installed only persons licensed to work with gas upstream of the appliance. union tee and piping may make the necessary gas plugged 1/8” NPt pressure tapping point connections to this appliance.
-
Page 26: Check Gas Pressure (Millivolt)
MIllIVolt CHeCK GAS PReSSuRe and eleCtRICAl INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace 1. Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, StoP! Do not install the appliance. -
Page 27: Electrical Installation
eleCtRICAl INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace ReMote WAll MouNteD SWItCH A remote wall switch and up to fifteen (15) feet of 18 Ga. Do not connect wall switch to (110 V) wire may be used with this appliance. Attach the wall circuit. -
Page 28: Operating Instructions
oPeRAtING INStRuCtIoNS - MIllIVolt HBDV7 Series Direct Vent Gas Fireplace FoR youR SAFety ReAD BeFoRe lIGHtING If you do not follow these instruction exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with a pilot which must be lit with built-in piezo ignitor while following these instructions exactly. -
Page 29: Lighting Pilot
oPeRAtING INStRuCtIoNS - MIllIVolt HBDV7 Series Direct Vent Gas Fireplace lIGHtING PIlot FoR tHe FIRSt tIMe APPRoVeD leAK teStING MetHoD If using a soap and water You may check for gas leaks with the following methods solution to test for leaks, only: Do Not spray solution onto •... -
Page 30: Lighting Burner
oPeRAtING INStRuCtIoNS - MIllIVolt HBDV7 Series Direct Vent Gas Fireplace lIGHtING BuRNeR MAIN BuRNeR SWItCH The “ON/OFF/RS” switch for the main burner can be found behind door of the fireplace. This switch allows you to turn on and to turn off the main burner without using the gas valve knob. Make sure the button is in the “ON”... -
Page 31: Check Gas Pressure - Signature Command System
SIGNAtuRe CoMMAND - CHeCK GAS PReSSuRe and eleCtRICAl INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace 1. Check gas type. The gas supply must be the same as Pressure Inlet stated on the appliance’s rating decal. If the gas supply is different from the fireplace, StoP! Do not install the appliance. -
Page 32: Junction Box Wiring
eleCtRICAl INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace juNCtIoN Box WIRING 1. This should be done before framing the fireplace. Wire the receptacle into an electrical circuit. Wire with minimum 60° C wire in accordance with prevailing codes. . Remove the external junction box cover by removing the screw from the side of the outside firebox wall. - Page 33 eleCtRICAl INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace Optional To Junction Box AC Module in Fireplace Pilot Optional White Light Black Optional White Blower Black White Optional Black Aux. Green Connector Pin To Control Board Input 300 Watt Max. Each Optional A/C Module Replaces 6V Adapter When Used RF Receiver ON/OFF Button Control Board 6V AC Black / Thermopile Adapter Red / Thermopile Sensor Conversion NG/LP Ignitor / Sparker Plug-in Connector...
-
Page 34: Optional Fan/Blower System - Scs
HBDV7 Series Direct Vent Gas Fireplace oPtIoNAl FAN BloWeR SySteMS electrical Grounding Instructions: this electrical connections should only be appliance is equipped with a three-prong performed by a qualified licensed electrician. (grounding) plug for your protection against Main power supply must be turned off before shock hazard and should be plugged directly connecting the fan to the main electrical into a properly grounded three-prong... -
Page 35: Blot
oPtIoNAl FAN BloWeR SySteMS HBDV7 Series Direct Vent Gas Fireplace Blot AutoMAtIC tHeRMoStAt BloWeR 120VAC Receptacle Junction BLACK GREEN FP675 WHITE BLACK WHITE BLACK BLACK Speed Control Before installing the blower, wire the receptacle into an Figure 56 - electrical circuit. This should be done before framing the BLOT Blower Wiring Diagram fireplace. -
Page 36: Operating Instructions - Scs
oPeRAtING INStRuCtIoNS - SIGNAtuRe CoMMAND HBDV7 Series Direct Vent Gas Fireplace FoR youR SAFety ReAD BeFoRe lIGHtING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of lie. A. -
Page 37: Operating Instructions
oPeRAtING INStRuCtIoNS - SIGNAtuRe CoMMAND HBDV7 Series Direct Vent Gas Fireplace oPeRAtING INStRuCtIoNS 1. StoP! Read the safety information above. . This appliance is equipped with an ignition device which automatically lights the burner. Do not try to light the burner by hand. 3. -
Page 38: Signature Command System Operation
SIGNAtuRe CoMMAND SySteM oPeRAtIoN INStRuCtIoNS HBDV7 Series Direct Vent Gas Fireplace FeAtuReS To Thermopile Command Center RF Receiver ON/OFF To Sensor • Easy Access Function Operation and System Configuration To Sparker • Operation Confirmation/Fault Diagnostic Indications (LED/ Buzzer) NG/LP • ON/OFF/HI/Med/Low Operation Conversion •... -
Page 39: System Configuration/Setup
SIGNAtuRe CoMMAND SySteM oPeRAtIoN INStRuCtIoNS HBDV7 Series Direct Vent Gas Fireplace SySteM CoNFIGuRAtIoN/SetuP All System configuration/setup is done on the Command Center. Note: When using On/Off wall switch, the switch must be in the ON position to perform all configuration set ups at the command center. - Page 40 SIGNAtuRe CoMMAND SySteM oPeRAtIoN INStRuCtIoNS HBDV7 Series Direct Vent Gas Fireplace FuNCtIoNS/oPeRAtIoN turning on the fireplace 1. Turn on the master switch and wait for a beep. . Press the ON button on the Command Center or turn on wall switch. Pilot will light and burner will come on High set- ting or last memory setting (See Turning Off Fireplace below).
-
Page 41: Glass Frame Removal
GlASS ReMoVAl HBDV7 Series Direct Vent Gas Fireplace GlASS FRAMe ReMoVAl 1. Release two clamps on bottom of fireplace. Figure 59 . Tilt glass frame out and lift glass frame up until it clears three tabs on top of fireplace. 3. -
Page 42: Rockwool Placement
FINAl INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace PlACeMeNt oF lAVA RoCK, RoCK Wool AND loGS 1. Before starting, make sure the grate is hooked onto the rear bracket. . Sprinkle lava rocks around and in front of burner at bottom of firebox. - Page 43 FINAl INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace Right Log 6. Place Right Log # by matching the two holes on the bottom of the log with the two pins located on top of the burner. When this log is in place it is positioned at an angle and the right side of the log is seated over the right tong of the grate.
- Page 44 FINAl INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace 10a.For 400 models, place Left Front Log #6 toward the left by sitting the notch on this log on the left tong of the grate and set the tips of the log on the burner in front the large round holes.
-
Page 45: Universal Andirons
FINAl INStAllAtIoN HBDV7 Series Direct Vent Gas Fireplace INStAllING uNIVeRSAl ANDIRoNS Bolt bracket through lower slot into top andiron hole. Slide clip over horizontal fireplace grate bar. Figure 68 Adjust the screws and set the andirons over the cross bar of the grate between the two outer tongs on the right and left sides of the grate. -
Page 46: Cleaning And Maintenance
CleANING and MAINteNANCe HBDV7 Series Direct Vent Gas Fireplace Thermocouple turn off gas before servicing fireplace. It Thermopile is recommended that a qualified service Millivolt Control technician perform these check-ups at the Pilot beginning of each heating season. BuRNeR, PIlot AND CoNtRol CoMPARt- MeNt Keep the control compartment, logs, and burner areas FP1943... -
Page 47: Venting System
CleANING and MAINteNANCe HBDV7 Series Direct Vent Gas Fireplace VeNt SySteM The fireplace and venting system should be inspected before initial use and at least annually by a qualified field service person. Inspect the external vent cap on a regular basis to make sure that no debris is interfering with the airflow. -
Page 48: Troubleshooting
tRouBleSHootING HBDV7 Series Direct Vent Gas Fireplace StANDING PIlot IGNItIoN SyMPtoM PoSSIBle CAuSe ACtIoN 1. Spark ignitor will A. Wire disconnected. A. Open door and check to make sure wire is connected not light pilot after to ignitor. repeated triggering of B. -
Page 49: Troubleshooting
tRouBleSHootING HBDV7 Series Direct Vent Gas Fireplace StANDING PIlot IGNItIoN SyMPtoM PoSSIBle CAuSe ACtIoN 4. Frequent pilot A. Pilot flame may be too high A. Clean and adjust the pilot flame for maximum flame outage problem. or too low, causing pilot impingement on thermocouple. -
Page 50: Signature Command System
tRouBleSHootING HBDV7 Series Direct Vent Gas Fireplace SIGNAtuRe CoMMAND SySteM OPERATION FAULT ACTION DIAGNOSIS Using Battery polarity wrong? Re-install batteries battery? Make sure Command Install batteries and/or Battery voltage low? Change batteries Center and plug in the AC board No beep in about the control 8 seconds board are... -
Page 51: Replacement Parts
RePlACeMeNt PARtS HBDV7 Series Direct Vent Gas Fireplace FIReBox CoMPoNeNtS 548000 HBDV DVBH parts 54D8000... - Page 52 RePlACeMeNt PARtS HBDV7 Series Direct Vent Gas Fireplace FIReBox CoMPoNeNtS Ref. Description qty. HBDV300 HBDV400 Junction Box Assy. 6D18K 6D18K Black Louver (each) 54D046 6D0695 Glass Frame Assy. 54D5113 54D5034 Andiron Kit (Contains ) UAI9 UAI9 Accessories/Field Installed Options Brass Louver Assy. (upper and lower) L30BR L3BR Pewter Louver Assy.
-
Page 53: Standing Pilot Millivolt Control
RePlACeMeNt PARtS HBDV7 Series Direct Vent Gas Fireplace StANDING PIlot - MIllIVolt CoNtRol 11,12,13,14,15 548000 HBDV DVBH millivolt parts 54D8000... - Page 54 RePlACeMeNt PARtS HBDV7 Series Direct Vent Gas Fireplace StANDING PIlot - MIllIVolt CoNtRol Ref. Description qty. HBDV300NV7 HBDV300PV7 HBDV400NV7 HBDV400PV7 Gas Valve Assy. 37D0117 37D0118 37D0117 37D0118 Pilot Assy. 37D0018 37D0019 37D0018 37D0019 Replacement Thermocouple 37D1067 37D1067 37D1067 37D1067 Replacement Ignitor & Wire 37D1069 37D1069 37D1069...
-
Page 55: Signature Command System
RePlACeMeNt PARtS HBDV7 Series Direct Vent Gas Fireplace SIGNAtuRe CoMMAND SySteM 13,14,15,16,17 548000 HBDV7 SC parts 54D8000... - Page 56 RePlACeMeNt PARtS HBDV7 Series Direct Vent Gas Fireplace SIGNAtuRe CoMMAND SySteM Ref. Description qty. HBDV300NSC7 HBDV300PSC7 HBDV400NSC7 HBDV400PSC7 1. Gas Valve Assy. 80D0001 80D000 80D0001 80D000 . Pilot Assembly 80D0006 80D0007 80D0006 80D0007 3. Control Box 80D0018 80D0019 80D0018 80D0019 4.
-
Page 57: Logs
RePlACeMeNt PARtS HBDV7 Series Direct Vent Gas Fireplace loGS Ref. Description qty. HBDV300 HBDV400 548000 1. Rear Log #1 54D5119 54D503 . Right Log # 54D510 54D504 HBDV DVBH logs parts 3. Left Log #3 54D511 54D505 4. Mid Top Log #4 54D513 54D506 5. -
Page 58: Vertical Venting Components
RePlACeMeNt PARtS HBDV7 Series Direct Vent Gas Fireplace VeRtICAl VeNtING Description Model Number Vertical Vent Termination Kits Vertical Vent Termination w/ Storm Collar 7TDVSKV (flashing NOT included) Vertical Vent Termination w/ Storm Collar - 8 pack 7TDVSKV/8 (flashing NOT included) Vertical Vent Termination w/ 1/1 - 6/1 Flashing, Storm 7TDVSKVA Collar and Ceiling Support Kit... -
Page 59: Horizontal Venting Components
RePlACeMeNt PARtS HBDV7 Series Direct Vent Gas Fireplace HoRIZoNtAl VeNtING Description Model Number Horizontal Vent Termination Kits Up and Out Side Wall Termination Kit, includes 1” to 16” 7TBLSCTK Adjustable Termination Pipe, 90° Elbow, Firestops and Cool Touch Termination w/Siding Shield, Additional 1” Section Provided for Min. -
Page 60: Venting Components
VeNtING CoMPoNeNtS HBDV7 Series Direct Vent Gas Fireplace VeNt CoMPoNeNtS FoR 4" x 6B\," (Simpson Duravent, Selkirk) 4" x 6Z\x" (Metal-Fab) Current Simpson Simpson Duravent Duravent qty./ or MHSC or MHSC Selkirk Metal-Fab Item Box Description Part no. Part no. Part no. - Page 61 HBDV7 Series Direct Vent Gas Fireplace 54D8000...
-
Page 62: Massachusetts Residents Only
Massachusetts Residents only — Please read and follow these special requirements HBDV7 Series Direct Vent Gas Fireplace . Approved Carbon Monoxide Detectors. Each carbon Note ReGARDING VeNteD PRoDuCtS monoxide detector as required in accordance with the above This product must be installed by a licensed plumber or gas fitter provisions shall comply with NFPA 70 and be ANSI/UL 034 when installed within the Commonwealth of Massachusetts. -
Page 63: Warranty
HBDV7 Series Direct Vent Gas Fireplace lIMIteD lIFetIMe WARRANty PolICy lIFetIMe WARRANty The following components are warranted for life to the original owner, subject to proof of purchase: Firebox, Combustion Chamber, Heat Exchanger, Grate and Stainless Steel Burners. FIVe yeAR WARRANty The following components are warranted five (5) years to the original owner, subject of proof of purchase: Ceramic Fiber Logs. -
Page 64: Efficiencies
Based on CSA P.4.1-09 efficiency Ratings Model enerGuide Ratings Fireplace efficiency (%) HBDV300NV7 63.5 HBDV400NV7 67.3 HBDV300NSC7 67.4 HBDV400NSC7 70.9 Recherchez dans la brochure HBDV300PV7 71.4 les caractéristique de rendement HBDV400PV7 70.7 énergétique de foyer au gaz HBDV300PSC7 75.7 Énerguide HBDV400PSC7 74.0 Based on CSA P.4.1-09 Selon CSA P.4.1-09 MHSC 149 Cleveland Drive •...
