HBDV7 Series
Direct Vent Gas Fireplace
Models:
HBDV300N/PV7, HBDV400N/PV7
HBDV300N/PSC7, HBDV400N/PSC7
WARNING
IF tHe INFoRMAtIoN IN tHeSe INStRuCtIoNS IS Not
FolloWeD exACtly, A FIRe oR exPloSIoN MAy
ReSult CAuSING PRoPeRty DAMAGe, PeRSoNAl
INjuRy oR loSS oF lIFe.
–
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
–
WHAt to Do IF you SMell GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
–
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WARNING: Improper installation, adjustment, alteration,
services or maintenance can cause injury or property
damage. Refer to this manual. For assistance or additional
information consult a qualified installer, service agency
or the gas supplier.
this appliance may be installed in an aftermarket*,
permanently located, manufactured home (uSA only) or
mobile home, where not prohibited by local codes.
this appliance is only for use with the type of gas
indicated on the rating plate. this appliance is not
convertible for use with other gases, unless a certified
kit is used.
* Aftermarket: Completion of sale, not for purpose of resale, from the
manufacturer.
548000
HBDV7 cover
Due to HIGH teMPeRAtuReS, tHe APPlIANCe
SHoulD Be loCAteD out oF tRAFFIC AND
AWAy FRoM FuRNItuRe AND DRAPeRIeS.
CHIlDReN AND ADultS SHoulD Be AleRteD
to t H e H A Z A R D S o F H I G H S u R FA C e
teMPeRAtuRe AND SHoulD StAy AWAy to
AVoID BuRNS oR ClotHING IGNItIoN.
youNG CHIlDReN SHoulD Be SuPeRVISeD
WHeN tHey ARe IN tHe SAMe RooM AS tHe
APPlIANCe.
ClotHING oR otHeR FlAMMABle MAteRIAl
SHoulD Not Be PlACeD oN oR NeAR tHe
APPlIANCe.
KeeP tHe RooM AReA CleAR AND FRee FRoM
CoMBuStIBle MAteRIAlS, GASolINe, AND
otHeR FlAMMABle VAPoRS AND lIquIDS.
INStAlleR: leave this manual with the appliance.
CoNSuMeR: Retain this manual for future refer-
ence.
54D8000 1/10 Rev. 3
Advertisement
Table of Contents
Related Manuals for Monessen Hearth HBDV300N/PV7
Summary of Contents for Monessen Hearth HBDV300N/PV7
- Page 1 HBDV7 Series Direct Vent Gas Fireplace Models: HBDV300N/PV7, HBDV400N/PV7 HBDV300N/PSC7, HBDV400N/PSC7 WARNING IF tHe INFoRMAtIoN IN tHeSe INStRuCtIoNS IS Not FolloWeD exACtly, A FIRe oR exPloSIoN MAy ReSult CAuSING PRoPeRty DAMAGe, PeRSoNAl INjuRy oR loSS oF lIFe. – Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
HBDV7 Series Direct Vent Gas Fireplace thank you and congratulations on your purchase of a PleASe ReAD tHe INStAllAtIoN AND oPeRAtIoN INStRuCtIoNS BeFoRe uSING tHe APPlIANCe! IMPoRtANt: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. Important Safety Information ... -
Page 3: Important Safety Information
IMPoRtANt SAFety INFoRMAtIoN INStAlleR Please leave these instructions with the appliance. • Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. • Any change to this fireplace or its controls can be dangerous. •... -
Page 4: Code Approval
HBDV7 Series Direct Vent Gas Fireplace 14. Do not use any solid fuels (wood, coal, paper, card- board, etc.) in this fireplace. Use only the gas type indicated on rating plate. 15. This appliance, when installed, must be electrically grounded in accordance with local codes or in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C.1. -
Page 5: Product Features
PRoDuCt FeAtuReS and GAS SPeCIFICAtIoNS PRoDuCt SPeCIFICAtIoNS • This appliance has been certified for use with either natural or propane gas. Refer to appropriate data plates. • This appliance is not for use with solid fuels. • The appliance is approved for bedroom or bedsitting room installations. -
Page 6: Fireplace & Framing Dimensions
HBDV7 Series Direct Vent Gas Fireplace Figure 2 - Fireplace and Framing Dimensions FIRePlACe DIMeNSIoNS and FRAMING DIMeNSIoNS Min. Rough Opening Depth P - Min. Rough Opening Width Min. Rough Opening Height HBDV300 HBDV400 33Z\zn” (840 mm) 37Z\zn” (941 mm) 9M\,” (759 mm) 3” 7” (686 mm) 9”... -
Page 7: Fireplace Location
PRe-INStAllAtIoN INFoRMAtIoN FIReBox FRAMING Firebox framing can be built before or after the appliance is set in place. Refer to Figure 2 for fireplace and framing dimensions. Construct firebox framing following Figure 2 for your specific installation requirements. The framing headers may rest on the top of the firebox standoffs. -
Page 8: Mantel Clearances
HBDV7 Series Direct Vent Gas Fireplace CleARANCeS to CoMBuStIBleS Follow these instructions carefully to ensure safe installation. Failure to follow instructions exactly can create a fire hazard. the appliance cannot be installed on a carpet, tile or other combustible material other than wood flooring. If installed on carpet or vinyl flooring, the appliance shall be installed on a metal, wood or noncombustible material panel extending full width and depth of the appliance. -
Page 9: Secure Fireplace To Floor Or Framing
SeCuRe FIRePlACe to FlooR or FRAMING The fireplace must be secured to the floor and/or to framing studs as shown in Figure 6. Use two () wood screws or masonry/ concrete screws to secure fireplace to the floor. Use four (4) screws to attach fireplace to framing. -
Page 10: Optional Top Vent Application
HBDV7 Series Direct Vent Gas Fireplace oPtIoNAl toP VeNt APPlICAtIoN The appliance is shipped as a rear vent unit. If the installa- tion layout requires the unit to be a top vent configuration the appliance can be converted by following the steps below. -
Page 11: Venting Installation
VeNtING INStAllAtIoN INFoRMAtIoN Read all instructions completely and thoroughly before attempting installation. Failure to do so could result in serious injury, property damage or loss of life. operation of improperly installed and maintained venting system could result in serious injury, property damage or loss of life. -
Page 12: General Venting Information - Termination Location
HBDV7 Series Direct Vent Gas Fireplace GeNeRAl VeNtING INFoRMAtIoN - teRMINAtIoN loCAtIoN D E L B Figure 11 - CFM145a Termination Locations V A = Clearance above grade, veranda, porch, deck, or balcony B = Clearance to window or door that may be opened C = Clearance to permanently closed window D = Vertical clearance to ventilated soffit located... -
Page 13: Termination Clearances
VeNtING INFoRMAtIoN Termination Clearances Termination clearances for buildings with combustible and noncombustible exteriors. Inside Corner Combustible 6" (152 mm) Noncombustible 2" (51 mm) Balcony - with no side wall Combustible & Noncombustible 12" (305 mm) *Note: Termination in an alcove space (spaces open only on one side and with an overhang) is permitted with the dimensions specified for vinyl or non-vinyl siding and soffits. -
Page 14: Twist Lock Pipes
HBDV7 Series Direct Vent Gas Fireplace tWISt loCK PIPeS When using twist lock pipe it is not necessary to use sealant on the joints. The only areas of the venting system that need to be sealed with high temperature silicone sealant are the sliding joints of any telescopic vent section used in the system. -
Page 15: Vent Pipe Clearances
VeNt INStAllAtIoN Horizontal sections of this vent system require a minimum of 3” clearances to combustibles at the top of the flue and 1” clearance at the sides and bottom until the flue penetrates the outside wall. A minimum 1” clearance all around the flue is acceptable at this point of penetration. -
Page 16: Rear Wall Vent Applications & Installation
HBDV7 Series Direct Vent Gas Fireplace ReAR WAll VeNt APPlICAtIoN When installed as a rear vent unit this appliance may be vented directly to a termination located on the rear wall behind the appliance. • Only MHSC venting components are approved to be used in these applications (Refer to ‘Venting Compo- nents’... -
Page 17: Top Vent Sidewall Applications & Installation
VeNt INStAllAtIoN Finish Wall Figure 19 - Side View of Final Unit Location ReAR WAll VeNt INStAllAtIoNS - FP2294 Flex VeNt PIPe Side View Vent Termination 1/25/00 djt Follow Steps 1 and on Page 16. Step 3 Install the 4” (10 mm) flex vent pipe to the appliance col- lars described in “General Information Assembling Vent Pipes”, Page 13. - Page 18 HBDV7 Series Direct Vent Gas Fireplace When installing the appliance as a rear vent unit, the 90° or 45° transition elbow attached directly to the rear of the unit is Not INCluDeD in the following cri- teria and calculations, and unless specifically men- tioned should be ignored when calculating venting layouts.
-
Page 19: Vertical Sidewall Installation
VeNtING INStAllAtIoN VeRtICAl SIDeWAll INStAllAtIoN - tWISt loCK PIPe Step 1 Locate vent opening on the wall. It may be necessary to first position the fireplace and measure to obtain hole lo- cation. Depending on whether the wall is combustible or noncombustible, cut opening to size. - Page 20 HBDV7 Series Direct Vent Gas Fireplace Step 7 Guide the vent terminations 4” and 7” collard into their respective vent pipes. Double check that the vent pipes overlap the collars by ” (51 mm). Secure the termina- tion to the wall with screws provided and caulk around the wall plate to weatherproof.
-
Page 21: Below Grade Installation
VeNtING INStAllAtIoN BeloW GRADe INStAllAtIoNS When it is not possible to meet the required vent terminal clearances of 1" above grade level, a snorkel kit is recom- mended. It allows installation depth down to 7" (178 mm) below grade level. The 7" (178 mm) is measured from the center of the horizontal vent pipe as it penetrates through the wall. -
Page 22: Vertical Through-The-Roof Installation
HBDV7 Series Direct Vent Gas Fireplace Max.Height 40’ (1.. m) Min. Height 8’ (.4 m) Max. 10’ (3 m) Support Straps Every 3’ (914 mm) Max. 10’ (3 m) Max.Height 40’ (1.. m) Min. Height 8’ (.4 m) Figure 35 - Support Straps for Horizontal Runs FP1183a... - Page 23 VeNtING INStAllAtIoN 10. Add additional vent lengths for proper height. Figure 11. Apply high temperature sealant to 4” and 7” collars of vertical vent termination and install. If there is a room above ceiling level, fire stop spacer must be installed on both the bottom ad the top side of the ceil- ing joists.
-
Page 24: Check Gas Type
HBDV7 Series Direct Vent Gas Fireplace CHeCK GAS tyPe Use proper gas type for the fireplace you are installing. If you have conflicting gas type, do not install fireplace. See dealer where you purchased the fireplace for proper fireplace for your gas type or conversion kit. - Page 25 FIRePlACe INStAllAtIoN only persons licensed to work with gas piping may make the necessary gas connections to this appliance. NOTE : The gas line connection may be made using 1/2" rigid tubing or an approved flex connector. Since some municipalities have additional local codes it is always best to consult your local authorities and the current edition of the National Fuel Gas Code ANSI.Z223.1, NFPA54.
-
Page 26: Millivolt Check Gas Pressure And Electrical Installation
HBDV7 Series Direct Vent Gas Fireplace MIllIVolt CHeCK GAS PReSSuRe and eleCtRICAl INStAllAtIoN 1. Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, StoP! Do not install the appliance. -
Page 27: Electrical Installation
eleCtRICAl INStAllAtIoN ReMote WAll MouNteD SWItCH A remote wall switch and up to fifteen (15) feet of 18 Ga. wire may be used with this appliance. Attach the wall switch in a junction box at the desired location on the wall. -
Page 28: Operating Instructions
HBDV7 Series Direct Vent Gas Fireplace FoR youR SAFety ReAD BeFoRe lIGHtING A. This appliance is equipped with a pilot which must be lit with built-in piezo ignitor while following these instructions exactly. B. BEFORE OPERATING smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor. -
Page 29: Lighting Pilot
oPeRAtING INStRuCtIoNS - MIllIVolt lIGHtING PIlot FoR tHe FIRSt tIMe APPRoVeD leAK teStING MetHoD You may check for gas leaks with the following methods only: • Soap and water solution • An approved leak testing spray • Electronic sniffer Never check for gas leak with open flame! Check for gas leaks in each of the following locations: •... -
Page 30: Lighting Burner
HBDV7 Series Direct Vent Gas Fireplace MAIN BuRNeR SWItCH The “ON/OFF/RS” switch for the main burner can be found behind door of the fireplace. This switch allows you to turn on and to turn off the main burner without using the gas valve knob. Make sure the button is in the “ON”... -
Page 31: Check Gas Pressure - Signature Command System
SIGNAtuRe CoMMAND - CHeCK GAS PReSSuRe and eleCtRICAl INStAllAtIoN 1. Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, StoP! Do not install the appliance. -
Page 32: Electrical Installation
HBDV7 Series Direct Vent Gas Fireplace juNCtIoN Box WIRING 1. This should be done before framing the fireplace. Wire the receptacle into an electrical circuit. Wire with minimum 60° C wire in accordance with prevailing codes. . Remove the external junction box cover by removing the screw from the side of the outside firebox wall. - Page 33 eleCtRICAl INStAllAtIoN To Junction Box in Fireplace Optional White Light Black Optional White Blower Black White Optional Black Aux. Green Input 300 Watt Max. Each Optional A/C Module Replaces 6V Adapter When Used 6V AC Adapter Note: Wall switch wires must be con- nected together if a wall switch is not being used. Figure 54 - Signature Command Wiring Diagram electrical connections should only be performed by a qualified, licensed electrician.
-
Page 34: Optional Fan/Blower System - Scs
HBDV7 Series Direct Vent Gas Fireplace electrical Grounding Instructions: this appliance is equipped with a three-prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle. the black and white wires on the AC box wiring harness are marked ‘Blower’, ‘light’... -
Page 35: Fk-1
oPtIoNAl FAN BloWeR SySteMS Blot AutoMAtIC tHeRMoStAt BloWeR WHITE Before installing the blower, wire the receptacle into an electrical circuit. This should be done before framing the fireplace. Wire with minimum 60° C wire in accordance with prevailing codes. FK-12 MANuAl BloWeR 1. -
Page 36: Operating Instructions - Scs
HBDV7 Series Direct Vent Gas Fireplace FoR youR SAFety ReAD BeFoRe lIGHtING A. This appliance is equipped with an ignition device which automatically lights the pilot. Refer to the instructions. B. BEFORE OPERATING smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor. -
Page 37: Operating Instructions
oPeRAtING INStRuCtIoNS - SIGNAtuRe CoMMAND oPeRAtING INStRuCtIoNS 1. StoP! Read the safety information above. . This appliance is equipped with an ignition device which automatically lights the burner. Do not try to light the burner by hand. 3. With five (5) minutes to clear out any gas. Then smell for gas, including near the floor. If you smell gas, StoP! Follow "B"... -
Page 38: Signature Command System Operation
HBDV7 Series Direct Vent Gas Fireplace FeAtuReS Command Center • Easy Access Function Operation and System Configuration • Operation Confirmation/Fault Diagnostic Indications (LED/ Buzzer) • ON/OFF/HI/Med/Low Operation • Optional Wall Mounting Control Board • Electronic Ignition • Pilot Lockout safety feature •... -
Page 39: System Configuration/Setup
SIGNAtuRe CoMMAND SySteM oPeRAtIoN INStRuCtIoNS SySteM CoNFIGuRAtIoN/SetuP All System configuration/setup is done on the Command Center. Note: When using On/Off wall switch, the switch must be in the ON position to perform all configuration set ups at the command center. Intermittent/Standing Pilot Setup (Default intermittent) 1. -
Page 40: Functions/Operation
HBDV7 Series Direct Vent Gas Fireplace FuNCtIoNS/oPeRAtIoN turning on the fireplace 1. Turn on the master switch and wait for a beep. . Press the ON button on the Command Center or turn on wall switch. Pilot will light and burner will come on High set- ting or last memory setting (See Turning Off Fireplace below). -
Page 41: Glass Frame Removal
GlASS ReMoVAl GlASS FRAMe ReMoVAl 1. Release two clamps on bottom of fireplace. Figure 59 . Tilt glass frame out and lift glass frame up until it clears three tabs on top of fireplace. 3. Set glass frame aside. Glass Frame Figure 59 - Remove Glass Frame each clamp has a quick spring force. -
Page 42: Placement Of Lava Rock, Rock Wool And Logs
HBDV7 Series Direct Vent Gas Fireplace PlACeMeNt oF lAVA RoCK, RoCK Wool AND loGS 1. Before starting, make sure the grate is hooked onto the rear bracket. . Sprinkle lava rocks around and in front of burner at bottom of firebox. 3. - Page 43 FINAl INStAllAtIoN 6. Place Right Log # by matching the two holes on the bottom of the log with the two pins located on top of the burner. When this log is in place it is positioned at an angle and the right side of the log is seated over the right tong of the grate.
- Page 44 HBDV7 Series Direct Vent Gas Fireplace 10a.For 400 models, place Left Front Log #6 toward the left by sitting the notch on this log on the left tong of the grate and set the tips of the log on the burner in front the large round holes.
-
Page 45: Universal Andirons
FINAl INStAllAtIoN INStAllING uNIVeRSAl ANDIRoNS Bolt bracket through lower slot into top andiron hole. Slide clip over horizontal fireplace grate bar. Figure 68 Adjust the screws and set the andirons over the cross bar of the grate between the two outer tongs on the right and left sides of the grate. -
Page 46: Cleaning And Maintenance
HBDV7 Series Direct Vent Gas Fireplace turn off gas before servicing fireplace. It is recommended that a qualified service technician perform these check-ups at the beginning of each heating season. BuRNeR, PIlot AND CoNtRol CoMPARt- MeNt Keep the control compartment, logs, and burner areas surrounding the logs clean by vacuuming or brushing at least twice a year. -
Page 47: Venting System
CleANING and MAINteNANCe VeNt SySteM The fireplace and venting system should be inspected before initial use and at least annually by a qualified field service person. Inspect the external vent cap on a regular basis to make sure that no debris is interfering with the airflow. -
Page 48: Troubleshooting
HBDV7 Series Direct Vent Gas Fireplace StANDING PIlot IGNItIoN SyMPtoM PoSSIBle CAuSe 1. Spark ignitor will A. Wire disconnected. not light pilot after repeated triggering of B. Defective ignitor. piezo. C. No gas or low gas pres- sure. D. No Propane/LPG in tank . - Page 49 tRouBleSHootING StANDING PIlot IGNItIoN SyMPtoM PoSSIBle CAuSe 4. Frequent pilot A. Pilot flame may be too high outage problem. or too low, causing pilot safety to drop out 5. The pilot and main A. Inner vent pipe leaking burner extinguish exhaust gases back into while in operation system...
-
Page 50: Signature Command System
HBDV7 Series Direct Vent Gas Fireplace SIGNAtuRe CoMMAND SySteM OPERATION Install batteries and/or plug in the AC board No beep in about 8 seconds Flip the master switch (rocker switch) to the ON position No beep Press the ON button on the Command Center no sound from the valve indicating pilot... -
Page 51: Replacement Parts
RePlACeMeNt PARtS FIReBox CoMPoNeNtS 54D8000 548000 HBDV DVBH parts HBDV7 Series Direct Vent Gas Fireplace... - Page 52 HBDV7 Series Direct Vent Gas Fireplace FIReBox CoMPoNeNtS Ref. Description Junction Box Assy. Black Louver (each) Glass Frame Assy. Andiron Kit (Contains ) Accessories/Field Installed Options Brass Louver Assy. (upper and lower) Pewter Louver Assy. (upper and lower) Speed Control Standard Firebrick Center - Cottage Clay Standard Firebrick Right - Cottage Clay Standard Firebrick Left - Cottage Clay...
-
Page 53: Standing Pilot Millivolt Control
RePlACeMeNt PARtS StANDING PIlot - MIllIVolt CoNtRol 54D8000 548000 HBDV DVBH millivolt parts HBDV7 Series Direct Vent Gas Fireplace 11,12,13,14,15... - Page 54 HBDV7 Series Direct Vent Gas Fireplace StANDING PIlot - MIllIVolt CoNtRol Ref. Description Gas Valve Assy. Pilot Assy. Replacement Thermocouple Replacement Ignitor & Wire Replacement Thermopile Burner Tube Flexhose w/ Shutoff Valve Rocker Switch Piezo Ignitor Injector Burner Assy. Venturi Wire Assy.
-
Page 55: Signature Command System
RePlACeMeNt PARtS SIGNAtuRe CoMMAND SySteM 54D8000 13,14,15,16,17 548000 HBDV7 SC parts HBDV7 Series Direct Vent Gas Fireplace... - Page 56 HBDV7 Series Direct Vent Gas Fireplace SIGNAtuRe CoMMAND SySteM Ref. Description 1. Gas Valve Assy. . Pilot Assembly 3. Control Box 4. Command Center 5. Burner Tube 6. Flexhose with Shutoff Valve 7. Injector 8a,b. Burner Assembly 9. Venturi 10. Wire Valve Control (not shown) 11.
-
Page 57: Logs
RePlACeMeNt PARtS loGS Ref. Description 1. Rear Log #1 . Right Log # 3. Left Log #3 4. Mid Top Log #4 5. Right Top Log #5 6. Left Front Log #6 7. Right Front Twig #7 54D8000 qty. 548000 HBDV DVBH logs parts HBDV7 Series Direct Vent Gas Fireplace HBDV300... -
Page 58: Vent Components
HBDV7 Series Direct Vent Gas Fireplace VeRtICAl VeNtING Vertical Vent Termination Kits Twist Lock Pipe 584B Vent components Starter Kit 2/25/99 djt Twist Lock Elbows Shields and Supports 584D Vent Components 584C 90 degree elbow Vent components 2/25/99 djt 45 degree elbow 10/20/99 twist lock 2/25/99 djt 584G... -
Page 59: Horizontal Venting Components
RePlACeMeNt PARtS HoRIZoNtAl VeNtING Horizontal Vent Termination Kits 584B Vent components Starter Kit 2/25/99 djt Twist Lock Pipe Twist Lock Elbows Shields and Supports 584D Vent Components 584C 90 degree elbow Vent components 2/25/99 djt 45 degree elbow 10/20/99 twist lock 584H 2/25/99 djt Venting components... - Page 60 HBDV7 Series Direct Vent Gas Fireplace 54D8000...
- Page 61 HBDV7 Series Direct Vent Gas Fireplace 54D8000...
-
Page 62: Massachusetts Residents Only
Massachusetts Residents only — Please read and follow these special requirements HBDV7 Series Direct Vent Gas Fireplace Note ReGARDING VeNteD PRoDuCtS This product must be installed by a licensed plumber or gas fitter when installed within the Commonwealth of Massachusetts. Any residence with a direct vent product must have a CO detector installed in the residence. -
Page 63: Limited Lifetime Warranty Policy
HBDV7 Series Direct Vent Gas Fireplace lIMIteD lIFetIMe WARRANty PolICy lIFetIMe WARRANty The following components are warranted for life to the original owner, subject to proof of purchase: Firebox, Combustion Chamber, Heat Exchanger, Grate and Stainless Steel Burners. FIVe yeAR WARRANty The following components are warranted five (5) years to the original owner, subject of proof of purchase: Ceramic Fiber Logs. -
Page 64: Efficiencies
Based on CSA P.4.1-09 efficiency Ratings Model enerGuide Ratings Fireplace efficiency (%) HBDV300NV7 63.5 HBDV300PV7 71.4 HBDV400NV7 67.3 HBDV400PV7 70.7 HBDV300NSC7 67.4 HBDV300PSC7 75.7 HBDV400NSC7 70.9 HBDV400PSC7 74.0 MHSC 149 Cleveland Drive • Paris, Kentucky 40361 www.mhsc.com...
